Image preview - the first page of the document
![Panel_CMO_V315B1-L04_0_[DS]](/pics/5c8ed61471d6b.gif)
>> Download Panel_CMO_V315B1-L04_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 16 2006
Model No.: V315B1 - L04
Approval
TFT LCD Approval Specification
MODEL NO.: V315B1 - L04
Customer:
Approved by:
Note:
LCD TV Head Division
AVP
TVHD / PDD
QRA Dept.
DDIII DDII DDI
Approval Approval Approval Approval
LCD TV Marketing and Product Management Division
Product Manager
1
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 16 2006
Model No.: V315B1 - L04
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT UNIT
2.3 ENVIROMENT TEST CONDITION
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 8
3.1 TFT LCD MODULE
3.2 BACKLIGHT INVERTER UNIT
3.2.1 CCFL(Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.2.2 INVERTER CHARACTERISTICS
3.2.3 INVERTER INTERFACE CHARACTERISTICS
4. BLOCK DIAGRAM ------------------------------------------------------- 13
4.1 TFT LCD MODULE
5. INTERFACE PIN CONNECTION ------------------------------------------------------- 14
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 21
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 24
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 27
8.1 CMO MODULE LABEL
9. PACKAGING ------------------------------------------------------- 28
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 30
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. REGULATORY STANDARDS ------------------------------------------------------- 30
11.1 SAFETY
11.2 EMC
12. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 31
2
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 16 2006
Model No.: V315B1 - L04
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Oct. 16'06 All All Approval Specification was first issued.
3
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 16 2006
Model No.: V315B1 - L04
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315B1- L04 is a 31.5" TFT Liquid Crystal Display module with 16-CCFL Backlight unit and 1ch-LVDS
interface. This module supports 1366 x 768 WXGA format and can display true 16.7M colors ( 8-bit colors).
The inverter module for backlight is built-in.
1.2 FEATURES
-High brightness (500 nits)
- Ultra-high contrast ratio (1500:1)
- Faster response time (gray to gray average 6.5ms)
- High color saturation (CIE 1976 NTSC 85%)
- Ultra wide viewing angle : 176(H)/176(V) (CR>20) with Super MVA technology
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- 180 degree rotation display (option)
- Color reproduction (nature color)
- Low color shift function
- RoHS compliance
1.3 APPLICATION
- TFT LCD TVs
- Multi-Media Display
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 697.6845 (H) x 392.256 (V) (31.51" diagonal) mm
(1)
Bezel Opening Area 703.8 (H) x 398.4 (V) mm
Driver Element a-si TFT active matrix -
Pixel Number 1366 x R.G.B. x 768 pixel
Pixel Pitch (Sub Pixel) 1.53225 (H) x 0.51075 (V) mm
Pixel Arrangement RGB vertical stripe -
Display Colors 16.7M color
Display Operation Mode Transmissive mode / Normally black -
Surface Treatment Anti-Glare coating (Haze 25%),Hard coating (3H) -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 759.3 760 760.7 mm (1)
Vertical(V) 449.4 450 450.6 mm (1)
Module Size Depth(D) 34.1 34.6 35.1 mm To rear surface
Depth(D) 43.65 44.65 45.65 mm To pcb cover
Depth(D) 49.4 50.4 51.4 mm To inverter cover
Weight 6550 6650 6750 g
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
4
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 16 2006
Model No.: V315B1 - L04
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
