Image preview - the first page of the document
![Panel_CMO_V315B5-P02_0_[DS]](/pics/5c8ed66d8ee3f.gif)
>> Download Panel_CMO_V315B5-P02_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan,14, 2010
Model No.: V315B5-P02
Approval
TFT LCD Approval Specification
MODEL NO.: V315B5-P02
Customer:
Approved by:
Note:
TV Product Marketing & Management Div
Approved By
Chao-Chun Chung
QRA Dept. Product Development Div.
Reviewed By
Hsin-nan Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
CY Chang Wen-kai Tsai
1
Version2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan,14, 2010
Model No.: V315B5-P02
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 CHARACTERISTICS
1.3 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CMO MODULE V315B5-L02)
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)
2.3 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD OPEN CELL
4. BLOCK DIAGRAM ------------------------------------------------------- 9
4.1 TFT LCD OPEN CELL
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 10
5.1 TFT LCD OPEN CELL
5.2 BLOCK DIAGRAM OF INTERFACE
5.3 LVDS INTERFACE
5.4 COLOR DATA INPUT ASSIGNMENT
5.5 PATTERN FOR Vcom ADJUSTMENT
6. INTERFACE TIMING ------------------------------------------------------- 16
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 20
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 23
8.1 OPEN CELL LABEL
8.2 CARTON LABEL
9. PACKAGING ------------------------------------------------------- 25
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 27
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. MECHANICAL DRAWING ------------------------------------------------------- 28
2
Version2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan,14, 2010
Model No.: V315B5-P02
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Dec.,10, 09' All All Approval Specification was first issued.
Ver 2.1 Jan.,14, 10' P4 EE Modified 1. GENERAL DESCRIPTION
P7-P8 Modified 3.1 TFT LCD OPEN CELL
Modified 5.5 PATTERN FOR Vcom ADJUSTMENT
P15
3
Version2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan,14, 2010
Model No.: V315B5-P02
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V315B5- P02 is a 31.5" TFT Liquid Crystal Display module. This module supports 1366 x 768 WXGA
format and can display true 16.7M (8-bit/color) colors.
1.2 CHARACTERISTICS
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in]
Pixels [lines]
Active Area [mm]
31.5
1366 768
697.6845 (H) x 392.256 (V) (31.5" diagonal)
Sub -Pixel Pitch [mm] 0.17025 (H) x 0.51075 (V)
Pixel Arrangement RGB vertical stripe
Weight [g] TYP. 1150
Physical Size [mm] 716.1(W) x 410(H) x 1.8(D) Typ.
Display Mode Transmissive mode / Normally black
Contrast Ratio (3000:1) Typ.
(Typical value measured at CMO's module)
Glass thickness (Array/CF) [mm] 0.7 / 0.7
Viewing Angle (CR>20) +88/-88(H),+88/-88(V) Typ.
(Typical value measured at CMO's module)
Color Chromaticity R=0.658, 0.327
G=0.276, 0.597
B=0.131, 0.121
W=0.305, 0.358
(Typical value measured by C source)
Cell Transparency [ ] 5.0%Typ.
(Typical value measured at CMO's module)
Polarizer (CF side) Super Wide View Anti-glare coating, 709.7(H) x 405(W)
Hardness:3H
Polarizer (TFT side) Super Wide View, 709.7(H) x 405(W).
1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight 1150 g -
I/F connector mounting The mounting inclination of the connector makes
(2)
