Image preview - the first page of the document
![Panel_CMO_V370H3-PH3_0_[DS]](/pics/5c8ed7206bfaa.gif)
>> Download Panel_CMO_V370H3-PH3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Oct. 26, 2009
Model No.: V370H3-PH3
Approval
TFT LCD Approval Specification
MODEL NO.:V370H3-PH3
Customer:
Approved by:
Note:
TV Head Division
Approved By
Chao-Chun Chung
QA Dept. Product Development Div.
Reviewed By
Hsin-Nan Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
Josh Chi Chloe Chen
1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Nov. 16, 2009
Model No.: V370H3-PH3
Approval
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 CHARACTERISTICS
1.3 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)
2.3 ELECTRICAL ABSOLUTE RATINGS (OPEN CELL)
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD OPEN CELL
4. BLOCK DIAGRAM ------------------------------------------------------- 9
4.1 TFT LCD OPEN CELL
5. INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 10
5.1 TFT LCD MODULE
5.2 LVDS INTERFACE
5.3COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 15
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 19
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 22
8.1 OPEN CELL LABEL
8.2 CARTON LABEL
9. PACKAGING ------------------------------------------------------- 23
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 25
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
11. MECHANICAL DRAWING ------------------------------------------------------- 26
2
Version2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Nov. 16, 2009
Model No.: V370H3-PH3
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 2.0 Nov.16, 2009 All All Approval Specification was first issued.
3
Version2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Nov. 16, 2009
Model No.: V370H3-PH3
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V370H3-PH3 is a 37" TFT Liquid Crystal Display module. This module supports 1920* 1080 FHDTV format and
can display 1.073G colors (8bit+Hi-FRC/color).
1.2 CHARACTERISTICS
CHARACTERISTICS ITEMS SPECIFICATIONS
Screen Diagonal [in] 37
Pixels [lines] 1920*1080
Active Area [mm] 819.36 (H) x 460.89 (V) (37.01" diagonal)
Sub -Pixel Pitch [mm] 0.14225 (H) x 0.42675 (V)
Pixel Arrangement RGB vertical stripe
Weight [g] TYP. 1648
Physical Size [mm] Reference 2D Drawing
Display Mode Transmissive mode / Normally black
Contrast Ratio 4500:1 Typ.
(Typical value measured at CMO's module)
Glass thickness (Array/CF) [mm] 0.7 / 0.7
Viewing Angle (CR20) +88/-88(H),+88/-88(V) Typ.
(Typical value measured at CMO's module)
Color Chromaticity R=(0.643, 0.324)
G=(0.292, 0.602)
B=(0.147, 0.058)
W=(0.280, 0.290)
(Typical value measured at CMO's module)
Cell Transparency [ ] 4.2%Typ.
(Typical value measured at CMO's module)
Polarizer (CF side) Super Wide View Glare & Hard coating (3H)
834.2(W) x 475.8(H)..
Polarizer (TFT side) Super Wide View, 834.2(W) x 475.8(H)..
1.3 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Weight - 1630 - g -
I/F connector mounting The mounting inclination of the connector makes
(2)
