Image preview - the first page of the document
![Panel_CMO_V420H1-L07_1_[DS]](/pics/5c8ed74377739.gif)
>> Download Panel_CMO_V420H1-L07_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
TFT LCD Approval Specification
MODEL NO.: V420H1 - L07
Customer: SONY
Approved by:
Note:
TV Head Division.
Approved By
LY Chen
QA Dept. Product Development Div.
Reviewed By
Tomy Chen WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
Wang-Yang Li Trina Lee
1
Version 2.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
- CONTENTS -
1. GENERAL DESCRIPTION -------------------------------------------------------4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
2.2.2 BACKLIGHT INVERTER UNIT
3. ELECTRICAL CHARACTERISTICS --------------------------------------------------------8
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
3.2.1 CCFL (Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.2.2 INVERTER CHARACTERISTICS
3.2.3 INVERTER INTERFACE CHARACTERISTICS
4. BLOCK DIAGRAM --------------------------------------------------------14
4.1 TFT LCD MODULE
5. V420H1-L07 LCD INPUT TERMINAL PIN ASSIGNMENT ---------------------------------------------------------15
5.1 TFT LCD MODULE INPUT
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING -------------------------------------------------------25
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS -------------------------------------------------------28
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS -------------------------------------------------------32
8.1 ASSEMBLY AND HANDLING PRECAUTIONS
8.2 SAFETY PRECAUTIONS
9.DEFINITION OF LABELS -------------------------------------------------------33
9.1 CMO MODULE LABEL
10. PACKAGING ------------------------------------------------------34
10.1 PACKING SPECIFICATION.
10.2 PACKING METHOD
11.MECHANICAL CHARACTERISTICS --------------------------------------------------------36
2
Version 2.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
REVISION HISTORY
Version Date Page Section Description
Ver 0.0 July, 20,2006 All All Tentative Specification was first issued.
Ver.1.0 Sept.08, 2006 All All Preliminary. Spec. was first issued.
Ver.1.1 Nov,01, 2006 8 3.1 IRUSH Rush Current.
28 7.2 CR Color Chromaticity.
29 7.2 Note(2)
36 11 Mechanical Characteristics
Ver 2.0 Dec, 21, 2006 5 1.5 Weight
7 2.3 Note(3)
8 3.1 Power Supply Current(White)
10 3.2.2 Input Ripple Noise(Max.)=912 mVP-P
12~13 3.2.3 INVERTER INTERFACE CHARACTERISTICS(Status Signal, VBL
Rising Time, VBL Falling Time ,PWM Delay Time, Note (1) )
14 4.1 TFT LCD MODULE (CN 23~ 27)
18 5.3 Inverter Unit (Pin 11~ 14) ;Note(1)~(3);
28 7.2 Color Chromaticity (R,G,B)
36~38 11 MECHANICAL CHARACTERISTICS
Ver 2.1 Mar, 27, 2007 8 3.1 IRUSH (Max) 5.0 A
34~35 10 PACKAGING
Ver 2.2 May, 17, 2007 4 1.2 contrast ratio 2000:1
28 7.2 contrast ratio 2000:1
Ver 2.3 June, 27, 2007 35 10.2 Figure 10-2
Ver 2.4 Dec, 27, 2007 5 1.5 Weight
25 6.1 INPUT SIGNAL TIMING SPECIFICATIONS
Ver 2.5 May, 06, 2008 35~37 11 MECHANICAL CHARACTERISTICS
Aug, 05, 2008 32 9.1 Modify Label from "MADE IN TAIWAN" to "MADE IN CHINA"
Aug, 05, 2008 33 10.1 Add "Desiccant"
3
Version 2.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V420H1-L07 is a 42" TFT Liquid Crystal Display module with 20-CCFL Backlight unit and 2ch-LVDS
interface. This module supports 1920 x 1080 HDTV format and can display true 16.7M colors (8-bit/color).
The inverter module for backlight is built-in.
1.2 FEATURES
- High brightness (500 nits)
- High contrast ratio (2000:1)
- Fast response time ( )
- High color saturation (NTSC 72%)
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Optimized response time for 60 Hz frame rate
- Ultra wide viewing angle : Super MVA technology
- 180 degree rotation display option
- RoHS compliance
1.3 APPLICATION
- Standard Living Room TVs.
- Public Display Application.
- Home Theater Application.
- MFM Application.
1.4 GENERAL SPECIFICATIONS
Item Specification Unit Note
Active Area 930.24(H) x 523.26 (V) (42.02" diagonal) mm
(1)
Bezel Opening Area 938.3 (H) x 531.3 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.1615 (H) x 0.4845 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Display Operation Mode Transmissive mode / Normally black - -
Anti-Glare coating (Haze 25%)
Surface Treatment - (2)
Hard coating (3H)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and
back outlines.
Note (2) The spec of the surface treatment is temporarily for this phase. CMO reserves the rights to
change this feature.
4
Version 2.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 982.3 983.0 984.0 mm
Module Size Vertical (V) 575.3 576.0 577.0 mm (1), (2)
Depth (D) 51.3 52.3 53.3 mm
Weight 12500 13000 13500 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
5
Version 2.5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Aug 05, 2008
Model No.:V420H1-L07
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
