Image preview - the first page of the document
![Panel_CMO_V520H1-L08_1_[DS]](/pics/5c8ed84e880e6.gif)
>> Download Panel_CMO_V520H1-L08_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
TFT LCD Approval Specification
MODEL NO.: V520H1 - L08
Customer:
Approved by:
Note:
TV Head Division
Approved By
LY Chen
QRA Dept. Product Development Div.
Reviewed By
Tomy Chen WT Lin
LCD TV Marketing and Product
Prepared By Management Div.
Ken Wu Sabrina Lin
1
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
- CONTENTS -
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 6
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 PACKAGE STORAGE
2.3 ELECTRICAL ABSOLUTE RATINGS
2.3.1 TFT LCD MODULE
2.3.2 BACKLIGHT INVERTER UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 8
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
3.2.1 CCFL (Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.2.2 INVERTER CHARACTERISTICS
3.2.3 INVERTER INTERFACE CHARACTERISTICS
4. BLOCK DIAGRAM -------------------------------------------------------14
4.1 TFT LCD MODULE
5. INPUT TERMINAL PIN ASSIGNMENT ---------------------------------------------------------15
5.1 TFT LCD MODULE INPUT
5.2 BACKLIGHT UNIT
5.3 INVERTER UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 23
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 26
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. PRECAUTIONS ------------------------------------------------------- 30
8.1 ASSEMBLY AND HANDLING PRECAUTIONS
8.2 SAFETY PRECAUTIONS
8.3 SAFETY STANDARDS
9. REGULATORY STANDARD -------------------------------------------------------30
9.1 SAFETY
10. PACKAGING -------------------------------------------------------31
10.1 PACKING SPECIFICATIONS
10.2 PACKING METHOD
11. MECHANICAL CHARACTERISTICS ------------------------------------------------------33
2
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
REVISION HISTORY
Version Date Page Section Description
Ver 2.0 Oct.25, 2007 All All Approval Specification was first issued.
Ver 2.1 Mar.25,2008 P4 1.4 Modified Surface Treatment
Ver 2.1 Mar.25,2008 P10 3.2.1 Modified CCFL CHARACTERISTICS
Ver 2.1 Mar.25,2008 P10 3.2.2 Modified INVERTER CHARACTERISTICS
Ver 2.1 Mar.25,2008 P26 7.2 Modified OPTICAL SPECIFICATIONS
3
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V520H1-L08 is a 52" TFT Liquid Crystal Display module with 28-CCFL Backlight unit and 2ch-LVDS
interface. This module supports 1920 x 1080 HDTV format and can display true 16.7M colors (8-bit/color).
The inverter module for backlight is built-in.
1.2 FEATURES
- High brightness (500 nits)
- High contrast ratio (1500:1)
- Fast response time (Gray to gray average 6.5 ms)
- High color saturation (NTSC 72%)
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Optimized response time for 50/60 Hz frame rate
- Ultra wide viewing angle : Super MVA technology
- RoHS compliance
1.3 APPLICATION
- Standard Living Room TVs.
- Public Display Application.
- Home Theater Application.
- MFM Application.
1.4 GENERAL SPECIFICATIONS
Item Specification Unit Note
Active Area 1152 x 648 (52.037") mm
(1)
Bezel Opening Area 1166.0x662.0 mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.2 (H) x 0.6 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.7M color -
Display Operation Mode Transmissive mode / Normally black - -
Glare coating(Reflection ratio<1.5%)
Surface Treatment - (2)
Hard coating (3H)
Note (1) Please refer to the attached drawings in chapter 11 for more information about the front and
back outlines.
Note (2) The spec of the surface treatment is temporarily for this phase. CMO reserves the rights to
change this feature.
4
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 1224.5 1226 1227.5 mm
Vertical (V) 718.0 719.2 720.4 mm
Module Size (1), (2)
To inv cover 56.0 57.5 59.0 mm
Depth (D)
To rear plate 38.5 40 41.5 mm
Weight 19600 g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
5
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issue Date: Mar.25.2008
Model No.:V520H1-L08
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -20 +60 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
