Image preview - the first page of the document
![Panel_CMO_V546H1-LH1_0_[DS]](/pics/5c8ed85fe35c9.gif)
>> Download Panel_CMO_V546H1-LH1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan 9, 2009
Model No.: V546H1-LH1
Approval
TFT LCD Approval Specification
MODEL NO.: V546H1- LH1
Customer:
Approved by:
Note:
TVHD
Approved By
LY Chen
QA Dept. Product Development Div.
Reviewed By
Kc_Ko WT Lin
LCD TV Marketing and Product Management Div.
Prepared By
WY Li Trina Lee
1
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan 9, 2009
Model No.: V546H1-LH1
Approval
CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 FEATURES
1.3 APPLICATION
1.4 GENERAL SPECIFICATIONS
1.5 MECHANICAL SPECIFICATIONS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
2.2 PACKAGE STORAGE
2.3 ELECTRICAL ABSOLUTE RATINGS
2.3.1 TFT LCD MODULE
2.3.2 BACKLIGHT UNIT
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 7
3.1 TFT LCD MODULE
3.2 BACKLIGHT UNIT
3.2.1 CCFL(Cold Cathode Fluorescent Lamp) CHARACTERISTICS
3.2.2 BALANCE BOARD CHARACTERISTICS
4. BLOCK DIAGRAM ------------------------------------------------------- 12
4.1 TFT LCD MODULE
5. .INPUT TERMINAL PIN ASSIGNMENT ------------------------------------------------------- 13
5.1 TFT LCD MODULE
5.2 BACKLIGHT UNIT
5.3 BALANCE BOARD UNIT
5.4 BLOCK DIAGRAM OF INTERFACE
5.5 LVDS INTERFACE
5.6 COLOR DATA INPUT ASSIGNMENT
6. INTERFACE TIMING ------------------------------------------------------- 20
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
6.2 INPUT SIGNAL TIMING SPECIFICATIONS (FRC T-CON)
6.3 POWER ON/OFF SEQUENCE
7. OPTICAL CHARACTERISTICS ------------------------------------------------------- 23
7.1 TEST CONDITIONS
7.2 OPTICAL SPECIFICATIONS
8. DEFINITION OF LABELS ------------------------------------------------------- 27
8.1 CMO MODULE LABEL
9. PACKAGING ------------------------------------------------------- 28
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
10. PRECAUTIONS ------------------------------------------------------- 30
10.1 ASSEMBLY AND HANDLING PRECAUTIONS
10.2 SAFETY PRECAUTIONS
10.3 SAFETY STANDARDS
11. MECHANICAL CHARACTERISTICS ------------------------------------------------------- 31
2
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan 9, 2009
Model No.: V546H1-LH1
Approval
REVISION HISTORY
Page
Version Date Section Description
(New)
Ver 1.0 Nov. 12,'08 All All Preliminary Specification was first issued.
Ver 2.0 Jan, 01, `09 7 3.1 Updated Power Supply current spec
9 3.2.1 Updated CCFL characteristics
9 3.2.2 Updated Input High Voltage
11 3.2.2 Add Backlight unit diagram
20 6.1 Updated Input Signal Time Specifications
20-21 6.2 Updated Internal Signal Timing Specifications
22 6.3 Updated Power on/off sequence
23 7.2 Updated Contrast Ratio spec
28 9.1 Updated Packing Specifications
28-29 9.2 Updated Packing Method
31-32 11 Updated Mechanical Characteristic
3
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan 9, 2009
Model No.: V546H1-LH1
Approval
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V546H1-LH1 is a 54.6" TFT Liquid Crystal Display module with 22-CCFL Backlight unit and 2-ch LVDS
interface. This module supports 1920 x 1080 HDTV format and can display true 1.07G colors (10bit/color).
The inverter module for backlight is built-in.
1.2 FEATURES
- High brightness (500nits)
- High contrast ratio (4000:1)
- Fast response time (Gray to Gray average 4.5ms)
- High color saturation (72% NTSC)
- Full HDTV (1920 x 1080 pixels) resolution, true HDTV format
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Optimized response time for 120 Hz frame rate
- Ultra wide viewing angle: Super MVA technology
1.3 APPLICATION
- Standard Living Room TVs.
- Public Display Application.
- Home Theater Application.
- MFM Application.
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 1209.6 (H) x 680.4 (V) (55" diagonal) mm
(1)
Bezel Opening Area 1267.6 (H) x 738.4 (V) mm
Driver Element a-si TFT active matrix - -
Pixel Number 1920x R.G.B. x 1080 pixel -
Pixel Pitch(Sub Pixel) 0.21(H) x 0.63(V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 1.073G color -
Display Operation Mode Transmissive mode / Normally black - -
Anti-Glare coating (Super Clear)
Surface Treatment - (2)
Hardness (3H)
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and
back outlines.
Note (2) The spec of the surface treatment is temporary for this phase. CMO reserves the rights to
change this feature.
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal (H) 1266.1 1267.6 1269.1 mm
Module Size Vertical (V) 737.2 738.4 739.6 mm (1), (2)
Depth (D) 38.5 40 41.5 mm
Weight - 19853 - g -
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Note (2) Module Depth does not include connectors.
4
Version 2.0
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Issued Date: Jan 9, 2009
Model No.: V546H1-LH1
Approval
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Value
Item Symbol Unit Note
Min. Max.
