Image preview - the first page of the document
Panel_HITACHI_TX31D38VM2BAA_1_[DS]


>> Download Panel_HITACHI_TX31D38VM2BAA_1_[DS] documenatation <<

Text preview - extract from the document
   Global LCD Panel Exchange Center           www.panelook.com




                                  KAOHSIUNG HITACHI ELECTRONICS CO., LTD.



       FOR MESSRS:                                                                  DATE: Mar. 30th 2012


                       CUSTOMER'S ACCEPTANCE SPECIFICATIONS

                                          TX31D38VM2BAA

                                                  Contents
        No.                     ITEM                            SHEET No.                    PAGE
         1     COVER                                7B64PS 2701- TX31D38VM2BAA-1         1-1/1
         2     RECORD OF REVISION                   7B64PS 2702- TX31D38VM2BAA-1         2-1/1
         3     GENERAL DATA                         7B64PS 2703- TX31D38VM2BAA-1         3-1/1
         4     ABSOLUTE MAXIMUM RATINGS             7B64PS 2704- TX31D38VM2BAA-1         4-1/1
         5     ELECTRICAL CHARACTERISTICS           7B64PS 2705- TX31D38VM2BAA-1         5-1/1~2/2
         6     OPTICAL CHARACTERISTICS              7B64PS 2706- TX31D38VM2BAA-1         6-1/2~2/2
         7     BLOCK DIAGRAME                       7B64PS 2707- TX31D38VM2BAA-1         7-1/1
         8     RELIABILITY TESTS                    7B64PS 2708- TX31D38VM2BAA-1         8-1/1
         9     LCD INTERFACE                        7B64PS 2709- TX31D38VM2BAA-1         9-1/7~7/7
         10    OUTLINE DIMENSIONS                   7B64PS 2710- TX31D38VM2BAA-1         10-1/2~2/2
         11    APPEARANCE STANDARD                  7B64PS 2711- TX31D38VM2BAA-1         11-1/3~3/3
         12    PRECAUTIONS                          7B64PS 2712- TX31D38VM2BAA-1         12-1/2~2/2
         13    DESIGNATION OF LOT MARK              7B64PS 2713- TX31D38VM2BAA-1         13-1/1~1/1




       ACCEPTED BY:                                            PROPOSED BY:



         KAOHSIUNG HITACHI        SHEET
        ELECTRONICS CO., LTD.      NO.           7B64PS 2701-TX31D38VM2BAA-1                PAGE      1-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com


       2. RECORD OF REVISION
         DATE           SHEET No.                                SUMMARY




         KAOHSIUNG HITACHI       SHEET
        ELECTRONICS CO., LTD.     NO.            7B64PS 2702-TX31D38VM2BAA-1               PAGE     2-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                www.panelook.com


       3. GENERAL DATA
       3.1 DISPLAY FEATURES
       This module is a 12.3" HSXGA of 8:3 format amorphous silicon TFT. The pixel format is vertical stripe
       and sub pixels are arranged as R (red), G (green), B (blue) sequentially. This display is RoHS
       compliant, COG (chip on glass) technology and LED backlight are applied on this display.

         Part Name                         TX31D38VM2BAA

         Module Dimensions                 320(W) mm x 130(H) mm x (12.8)(D) mm typ.

         LCD Active Area                   293.76(W) mm x 110.16(H) mm

         Pixel Pitch                       0.2295(W) mm x 0.2295(H) mm

         Resolution                        1280 x 3(RGB)(W) x 480(H) dots

         Color Pixel Arrangement           R, G, B Vertical stripe

         LCD Type                          Transmissive Color TFT; Normally White

         Display Type                      Active Matrix

         Number of Colors                  262k Colors

         Backlight                         LED (Lifetime: 70 Khrs)

         Weight                            586 g

         Interface                         LVDS; 20 pins

         Power Supply Voltage              3.3V for LCD; 12V for Backlight

         Power Consumption                 1.848 W for LCD; 10.08 W for backlight
                                           12 o'clock (without image inversion and least brightness change)
         Viewing Direction
                                           6 o'clock (contrast peak located at)




         KAOHSIUNG HITACHI         SHEET
        ELECTRONICS CO., LTD.       NO.              7B64PS 2703-TX31D38VM2BAA-1                      PAGE    3-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                 www.panelook.com


       4. ABSOLUTE MAXIMUM RATINGS
                        Item                     Symbol         Min.          Max.       Unit    Remarks
                   Supply Voltage                 VDD             0           4.0         V         -
                Input Voltage of Logic             VI           -0.3       VDD+0.3        V      Note 1
                                                                                         $
               Operating Temperature               Top           -30           80            C   Note 2
                                                                                         $
                Storage Temperature                Tst           -40           90            C   Note 2
               Backlight Input Voltage           VLED             -            15         V      Note 3


       Note 1: It shall be applied to pixel data signal, clock signal and control Pin.
       Note 2: The maximum rating is defined as above based on the chamber temperature, which might be
               different from ambient temperature after assembling the panel into the application. Moreover,
               some temperature-related phenomenon as below needed to be noticed:
              - Background color, contrast and response time would be different in temperatures other than
                25 $ C .
              - Operating under high temperature will shorten LED lifetime.
       Note 3: Do not operate at or near the maximum rating listed for extended periods of time. Exposure to
               such conditions may adversely impact product reliability and result in failures not covered by
               warranty.




         KAOHSIUNG HITACHI           SHEET
        ELECTRONICS CO., LTD.         NO.                7B64PS 2704-TX31D38VM2BAA-1              PAGE     4-1/1

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                  www.panelook.com


       5. ELECTRICAL CHARACTERISTICS
       5.1 LCD CHARACTERISTICS                                                              Ta   25 $ C , VSS   0V
              Item                Symbol           Condition         Min.    Typ.    Max.        Unit      Remarks
      Power Supply Voltage         VDD                    -          3.0     3.3      3.6         V             -
        Differential Input                               VIH          -       -      +100
        Voltage for LVDS             VI                                                          mV        Note 1
       Receiver Threshold                                VIL         -100     -        -
                                                   VDD-VSS
      Power Supply Current          IDD                               -      560     680         mA        Note 2,3
                                                     =3.3V
        Vsync Frequency                fv                 -           -      60       66         Hz
        Hsync Frequency                fH                 -           -      31.8    33.3        KHz       Note 4
        DCLK Frequency              f CLK                 -           -      43.2     48         MHz


       Note 1: VCM=+1.2V
               VCM is common mode voltage of LVDS transmitter/receiver.
               The input terminal of LVDS transmitter is terminated with 100.

                             IN+
                                                LVDS
                                 100
                             IN-               Receiver


       Note 2: An all black check pattern is used when measuring IDD, f v is set to 60Hz.

                             DC Ampere Meter
                                                               TFT-LCM
                                                   IDD
                                                               VDD
                                   VDD
                                                               VSS


       Note 3: 1.0A fuse is applied in the module for IDD. For display activation and protection purpose, power
               supply is recommended larger than 2.5A to start the display and break fuse once any short
               circuit occurred.
       Note 4: For LVDS transmitter input.




         KAOHSIUNG HITACHI             SHEET
        ELECTRONICS CO., LTD.           NO.                   7B64PS 2705-TX31D38VM2BAA-1               PAGE        5-1/2

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                  www.panelook.com


       5.2 BACKLIGHT CHARACTERISTICS                                                                Ta     25 $ C
                Item            Symbol            Condition             Min.   Typ.   Max.   Unit    Remarks
          LED Input Voltage     VLED                  -                 11.5   12     12.5    V          Note1
         LED Forward Current                     0V; 0% duty             -     840    890
                                ILED                                                         mA       Note 2
            (Dim Control)                     3.3VDC; 100% duty          -     70     120
             LED lifetime         -                840 mA                -     70K     -     hrs      Note 3


       Note 1: As Fig. 5.1 shown, LED current is constant, 840 mA, controlled by the LED driver when
              applying 12V VLED.
       Note 2: Dimming function can be obtained by applying DC voltage or PWM signal from the display
               interface CN1. The recommended PWM signal is 1K ~ 10K Hz with 3.3V amplitude.
       Note 3: The estimated lifetime is specified as the time to reduce 50% brightness by applying 840 mA at
               25 $ C .




                                                              Fig 5.1




         KAOHSIUNG HITACHI            SHEET
        ELECTRONICS CO., LTD.          NO.                7B64PS 2705-TX31D38VM2BAA-1               PAGE         5-2/2

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                                    www.panelook.com


       6. OPTICAL CHARACTERISTICS
       The optical characteristics are measured based on the conditions as below:
       - Supplying the signals and voltages defined in the section of electrical characteristics.
       - The backlight unit needs to be turned on for 30 minutes.
       - The ambient temperature is 25 $ C .
       - In the dark room around 500~1000 lx, the equipment has been set for the measurements as shown in
         Fig 6.1.
                                                                           Ta = 25 $C, fv = 60 Hz, VDD = 3.3V

                  Item               Symbol                    Condition            Min.         Typ.          Max.         Unit         Remarks
                                                                                                                                   2
        Brightness of White                -                                        800          1000             -         cd/m          Note 1
                                                           I       0$ ,T    0$ ,
       Brightness Uniformity               -                                        70            -               -          %            Note 2
                                                           ILED= 840 mA
          Contrast Ratio               CR                                           400          800              -          -            Note 3
          Response Time
           (Rising + Falling)        Tr  Tf                I       0$ ,T    0$       -            25              -         ms            Note 4
            NTSC Ratio                     -               I       0$ ,T    0$       -            60              -          %                -
                                                               $
                                       Tx              I   0 , CR t 10               60           80              -
                                      T xc             I           $
                                                           180 , CR t 10             60           80              -
          Viewing Angle                                                                                                    Degree         Note 5
                                       Ty              I   90 $ , CR t 10            40           60              -
                                      T yc             I   270 $ , CR t 10           60           80              -
                                           X                                        0.55         0.60          0.65
                          Red
                                           Y                                        0.31         0.36          0.41
                                           X                                        0.31         0.36          0.41
                         Green
          Color                            Y                                        0.55         0.60          0.65
                                                           I       0$ ,T    0$                                               -            Note 6
       Chromaticity                        X                                        0.10         0.15          0.20
                          Blue
                                           Y                                        0.05         0.10          0.15
                                           X                                        0.27         0.32          0.37
                         White
                                           Y                                        0.30         0.35          0.40

       Note 1: The brightness is measured from center point of the panel, P5 in Fig. 6.2, for the typical value.
       Note 2: The brightness uniformity is calculated by the equation as below:
                                                               Min. Brightness
                         Brightness uniformity =                                    X100%
                                                               Max. Brightness

       , which is based on the brightness values of the 9 points measured by BM-7 as shown in Fig. 6.2.

                                                                                           320           640          960
                                 Photo detector: BM-7
                                                                                    80      1              2           3


               Field 1          Distance        500 mm                             240      4              5           6



                                     LCD panel                                     400      7              8           9


                                                                                                       Fig. 6.2
                      Fig. 6.1


         KAOHSIUNG HITACHI                     SHEET
        ELECTRONICS CO., LTD.                   NO.                        7B64PS 2706-TX31D38VM2BAA-1                                 PAGE       6-1/2

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                               www.panelook.com


       Note 3: The contrast ratio is measured from the center point of the panel, P5, and defined as the
               following equation:

                                                                      Brightness of White
                                                             CR
                                                                      Brightness of Black

       Note 4: The definition of response time is shown in Fig. 6.3. The rising time is the period from 90%
               brightness to 10% brightness when the data is from white to black. Oppositely, Falling time is
               the period from 10% brightness rising to 90% brightness.



                                                         White                         Black                             White


                                                                      Tr    Rising time         Falling time             Tf
                                     100 %
                                        90
                                Brightness




                                              10
                                               0
                                                                                    Fig . 6.3

       Note 5: The definition of viewing angle is shown in Fig. 6.4. Angle I is used to represent viewing
               directions, for instance, I 270 $ means 6 o'clock, and I 0 $ means 3 o'clock. Moreover,
               angle T is used to represent viewing angles from axis Z toward plane XY.
               The viewing direction of this display is 12 o'clock, which means that a photograph with gray
               scale would not be reversed in color and the brightness change would be less from this
               direction. However, the best contrast peak would be located at 6 o'clock.

                                                                               z
                                                                                    T = Viewing angle
                                                          I 90$
                                                                  y
                                                   12 o'clock
                                                                                                           I (x, y ,0)
                                                                                                                          $
                                             x'      $
                                                                                                                   x I 0
                                             I 180                                                                   3 o'clock
                                              9 o'clock


                                                                                                y' I     270$
                                                                                                       6 o'clock
                                                                               z'
                                                                            Fig. 6.4

       Note 6: The color chromaticity is measured from the center point of the panel, P5, as shown in Fig. 6.2.




         KAOHSIUNG HITACHI                    SHEET
        ELECTRONICS CO., LTD.                  NO.                         7B64PS      2706-TX31D38VM2BAA-1                      PAGE   6-2/2

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center                             www.panelook.com


       8. RELIABILITY TESTS
                Test Item                                                            Condition
                                          1) Operating
            High Temperature                                                                              500 hrs
                                          2) 80 $ C
                                          1) Operating
            Low Temperature                                                                               500 hrs
                                          2) -30 $ C
                                          1) Storage
            High Temperature                                                                              500 hrs
                                          2) 90 $ C
                                          1) Storage
            Low Temperature                                                                               500 hrs
                                          2) -40 $ C
                                          1) Operating
               Heat Cycle                 2)



◦ Jabse Service Manual Search 2026 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
