Image preview - the first page of the document
![Panel_HannStar_HSD190MGW1-A04_0_[DS]](/pics/5c8edbf945e49.gif)
>> Download Panel_HannStar_HSD190MGW1-A04_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 1 / 27
Document No. Revision
To :
Date : Aug.20, 2008
HannStar Product Information
(Preliminary)
Model : HSD190MGW1
- A04
Note:
1.Please contact Hannstar Display Corp. before designing your product based on this module specification.
2.The information contained herein is presented merely to indicate the characteristics and performance of
our products. No responsibility is assumed by Hannstar for any intellectual property claims or other
problems that may result from application based on the module described herein.
3.The mark " ** " of Model means sub-model code.
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be disclosed,
distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 2 / 27
Document No. Revision
Record of Revisions
Rev. Date Sub-Model. Description of change
0 20 Aug., 2008 A04 Product information for HSD190MGW1-A04 was first issued.
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be disclosed,
distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 3 / 27
Document No. Revision
Contents
1.0 General Descriptions ...............................................p.4
2.0 Absolute Maximum Ratings ................................ p.5
3.0 Optical Characteristics ...................................... p.7
4.0 Block Diagram ....................................................... p.11
5.0 I/O Connection Pin Assignment ................................. p.14
6.0 Electrical Characteristics ........................................ p.15
7.0 Outline Dimension .................................................. p.21
8.0 Lot Mark ............................................................... p.24
9.0 Package Specification .............................................. p.25
10.0 General Precaution ................................................. p.26
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be disclosed,
distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 4 / 27
Document No. Revision
1.0 GENERAL DESCRIPTIONS
1.1 Introduction
HannStar Display model HSD190MGW1-A04 is a color active matrix thin film transistor
(TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.
This model is composed of a TFT LCD panel, the voltage reference, common voltage,
DC-DC converter, column, and row driver circuit. This TFT LCD has a 19-inch diagonally
measured active display area with WXGA+ resolution (900 vertical by 1440 horizontal
pixel array).
1.2 Features
19" WXGA+ TN(Twisted Nematic) mode TFT LCD panel
High speed response time
4 CCFLs Backlight system
Supported WXGA+ (V:900 lines, H:1440 pixels) resolution
Supported to 75Hz refresh rate
LCD Timing Controller
RoHS compliance
1.3 General information
Item Specification Unit
Outline dimension 428 278 18.5 (typ.) mm
Display area 408.24 (H) x255.15 (V) mm
Number of Pixel 1440(H) x 900(V) Pixels
Pixel pitch 0.2835(H) x 0.2835(V) mm
Pixel arrangement RGB Vertical stripe
Display color 16.2M (6-bit+FRC)
Display mode Normally white
Surface treatment Antiglare, Hard-Coating (3H)
Weight 2200 G
Back-light 4-CCFLs, Top & bottom edge side
Input signal 2-ch LVDS
Logic system (2.7) W
Power consumption
B/L system 22 W
Optimum viewing direction 6 o'clock
1.4 Applications
Desktop and Multi-function monitors
Display terminals for AV applications
Monitors for industrial applications
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be disclosed,
distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 5 / 27
Document No. Revision
1.5 Mechanical Information
Item Min. Typ. Max. Unit
Horizontal(H) 427.5 428.0 428.5 mm
Module Size Vertical(V) 277.5 278.0 278.5 mm
Depth(D) 18.0 18.5 19.0 mm
Weight (without inverter) 2000 2200 2400 g
Torque of customer screw hole -- -- 3.0 Kgf*Cm
2.0 ABSOLUTE MAXIMUM RATINGS
2.1 Absolute Rating of Environment
Item Symbol Min. Max. Unit Note
o
Storage temperature TSTG -20 60 C
o
Operating temperature TOPR 0 50 C (1)
Vibration(non-operating) VNOP -- 1.5 G (2)
Shock(non-operating) SNOP -- 50 G (3)
Storage humidity HSTG 10 90 %RH (3)
Operating humidity HOP 10 80 %RH (4)
Low pressure(operating) PLOP 697 -- HPa (5)
Low pressure(non-operating) PLNOP 116 -- HPa (6)
Note (1)Storage /Operating temperature
Humidity (%)
100
90
80
Operating Range
60
40
20
Storage Range
10
0
-40 -20 0 20 40 50 60 65
Temperature (oC)
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be disclosed,
distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
H a n n Sta r Di sp l a y C o rp .
Document Title HSD190MGW1- A04 Product Information Page No. 6 / 27
Document No. Revision
(2) 10-300Hz sine wave, X,Y,Z each directions, 10min/cycle.
