Image preview - the first page of the document
![Panel_HannStar_HSD121PHW2-A00_0_[DS]](/pics/5c8edb663f8ba.gif)
>> Download Panel_HannStar_HSD121PHW2-A00_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 1/25
Document No. DC110-000643 Revision 1.2
TO : Road Well
Date : May., 19, 2009
HannStar Product Information
(Preliminary)
Model: HSD121PHW2
-A**
Note: (1) The information contained herein is tentative and may be changed without prior
notices
(2) Please contact HannStar Display Corp. before designing your product based on
this module specification.
(3) The information contained herein is presented merely to indicate the characteristics and
performance of our products. No responsibility is assumed by HannStar for any
intellectual property claims or other problems that may result from application based on
the module described herein.
(4) The mark " ** " of Model means sub-model code.
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be
disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 2/25
Document No. DC110-000643 Revision 1.2
Record of Revisions
Rev. Date Sub-Model Description of change
1.2 May, 06, 2009 A** Preliminary Specification was first released.
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be
disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 3/25
Document No. DC110-000643 Revision 1.2
Contents
1.0 General description ....................................... p.4
2.0 Absolute maximum ratings.................................. p.5
3.0 Optical characteristics...................................... p.6
4.0 Block diagram ............................................. p.10
5.0 Interface pin connection ................................. p.12
6.0 Electrical characteristics ................................. p.14
7.0 Reliability test items ....................................... p.21
8.0 Outline dimension .......................................... p.22
9.0 Lot mark ...................................................... p.24
10.0 Package specification .................................... p.25
11.0 General precaution .......................................... p.26
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be
disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 4/25
Document No. DC110-000643 Revision 1.2
1.0 GENERAL DESCRIPTION
1.1 Introduction
HannStar Display model HSD121PHW2-A is a color active matrix thin film
transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a
switching device. This model is composed of a TFT LCD panel, a driving circuit
and a back light system. This TFT LCD has a 16 (16:9) inch diagonally measured
active display area with HD (1366 horizontal by 768 vertical pixel) resolution.
1.2 Features
12.1 (16:9 diagonal) inch configuration
One channel LVDS interface
262K color by 6 bit R.G.B signal input
RoHS Compliance
Halogen Free
Color Engine
DBC
1.3 Applications
NB
1.4 General information
Item Specification Unit
Outline Dimension 289(Typ) x 176(Typ) x 3.6 (Max.) mm
Display area 268.01(H) x 150.68(V) mm
Number of Pixel 1366 RGB (H) x 768(V) pixels
Pixel pitch 0.1962(H) x 0.1962(V) mm
Pixel arrangement RGB Vertical stripe
Display mode Normally white
NTSC 50 %
Surface treatment Glare, Hard-Coating (3H)
Weight (230) (Typ.) g
Back-light White LED
Power
Logic System (0.95) (Typ.) W
Consumption
1.5 Mechanical Information
Item Min. Typ. Max. Unit
Horizontal (H) 288.5 289 289.5 mm
Module
Vertical (V) 165.5 176 176.5 mm
Size
Depth (D) (3.6) mm
Weight (230) (240) g
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be
disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 5/25
Document No. DC110-000643 Revision 1.2
2.0 ABSOLUTE MAXIMUM RATINGS
2.1 Electrical Absolute Rating
2.1.1 TFT LCD Module
Item Symbol Min. Max. Unit Note
Logic Supply voltage VDD -0.3 6.0 V
2.1.2 Environment Absolute Rating
Item Symbol Min. Max. Unit Note
Operating Temperature Topa 0 50
Storage Temperature Tstg -20 60
The information contained in this document is the exclusive property of HannStar Display Corporation. It shall not be
disclosed, distributed or reproduced in whole or in part without written permission of HannStar Display Corporation.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HannStar Display Corp.
Document Title HSD121PHW2-A Preliminary Specification For Road Well Page No. 6/25
Document No. DC110-000643 Revision 1.2
3.0 OPTICAL CHARACTERISTICS
3.1 Optical specification
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast CR (400) (500) (1)(2)(4)
Rising Tr (3) (6)
Response time msec (1)(3)
Falling Tf (9) (18)
White luminance (1)(4)(5)
YL (160) (200) cd/m2
(5 point) (IL=180mA)
=0
Rx (TBD)
Red Normal
RY viewing (TBD)
Gx angle (TBD)
Green
Color GY (TBD)
chromaticity (TBD)
Bx
(CIE1931) Blue
BY (TBD)
Wx 0.283 0.313 0.343
White
Wy 0.299 0.329 0.359
L (40) (45)
Hor.
R (40) (45)
Viewing angle CR>10 (1)(4)
U (10) (15)
Ver.
D (30) (35)
=0
Brightness uniformity BUNI 80 % (6)
(5point)
=0
Brightness Uniformity BUNI 70 % (6)
(13 points)
3.2 Measuring Condition
Measuring surrounding dark room
LED Current IL 180mA
Ambient temperature 25◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
