INNOLUX DISPLAY CORPORATION
BT140GW01 V.2 LCD MODULE SPECIFICATION
( ) Tentative Specification
( ) Preliminary Specification
() Final Specification
Customer Checked & Approved by
Samsung
Approved by Checked by Prepared by
MKT PD PM
Monica Huang
Date: 2009/10/28
Innolux Display Corporation
No.160 Kesyue Rd., Chu-Nan Site, Hsinchu Science Park,
Chu- Nan 350, Miao- Li Count y, Taiw an
Tel: 886-37-586000 Fax: 886-37-586060
Version: 4
InnoLux copyright
All rights reserved,
Copying forbidden.
Record of Revision
Version Revise Date Page Content
0 2009/08/04 All First Edition issued
1 2009/08/21 2 Add LED usage information: 48EA
Add LED circuit block information
2 2009/09/24 3/12/13 Update LED Data
3 2009/09/28 4 Update General Block Diagram
12 Update EN/PWM level
4 2009/10/28 17 Update Thermal Shock Criteria
SPEC NO. B T 1 4 0 G W 0 1 V. 2
PAGE 1/25
Contents: Page
1. General Specifications 2
2. Electrical Specifications
2-1 Pin Assignment 3
2-2 Absolute Maximum Ratings 5
2-3 Electrical Characteristics 6
3. Optical Specifications 12
4. Reliability Test Items 16
5. Safety 17
6. Displa y Quality 17
7. Handling Precaution 17
8. Label Definition 18
9. Packing Form 20
10. Mechanical Draw ings 21
Appendix 23
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
SPEC NO. B T 1 4 0 G W 0 1 V. 2
PAGE 2/25
1. General Specifications
NO. Item Specification Unit
1 Display resolution (pixel) 1366(H) X 768(V), HD resolution
2 Active area 309.40(H) X 173.95(V) mm
3 Screen size 14.0 inches diagonal Inches
4 Pixel pitch 0.2265(H) X 0.2265(V) mm
5 Color configuration Stripe
6 Overall dimension 324(W) X 192.5(H) X 5.2(D) (max) mm
7 Weight 350Max. Grams
8 Surface treatment Glare, 3H
9 Input color signal 6 bit LVDS
10 Display colors 262K (6 bit)
11 Optimum viewing direction 6 o'clock
12 Backlight W-LED
13 LED usage 48EA
14 RoHS RoHS compliance
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
SPEC NO. B T 1 4 0 G W 0 1 V. 2
PAGE 3/25
2. Electrical Specifications
2-1 Pin Assignment
a. Panel connector
Connector Part No.: GS13401-1110P-7F (Foxconn)or equivalent
User's connector Part No: 20453-040T-12 (I-PEX) or equivalent
Pin No Symbol Description Remark
1 NC No connection (Reserve)
2 VCC Power Supply (+3.3V)
3 VCC Power Supply (+3.3V)
4 VEDID DDC Power +3.3V
5 NC No connection (Reserve)
6 Clk EDID DDC Clock
7 DATA EDID DDC Data
8 Rxin0- Differential Data Input
R0~R5,G0
9 Rxin0+ Differential Data Input
10 GND Ground
11 Rxin1- Differential Data Input
G1~G5,B0,B1
12 Rxin1+ Differential Data Input
13 GND Ground
14 Rxin2- Differential Data Input
B2~B5,DE,Hsync,Vsync
15 Rxin2+ Differential Data Input
16 GND Ground
17 CLK- Differential Clock Input
18 CLK+ Differential Clock Input
19 NC No connection (Reserve)
20 NC No connection (Reserve)
21 NC No connection (Reserve)
22 NC No connection (Reserve)
23 NC No connection (Reserve)
24 NC No connection (Reserve)
25 NC No connection (Reserve)
26 NC No connection (Reserve)
27 NC No connection (Reserve)
28 NC No connection (Reserve)
29 NC No connection (Reserve)
30 NC No connection (Reserve)
31 LED_GND LED Ground
32 LED_GND LED Ground
33 LED_GND LED Ground
34 NC No connection (Reserve)
35 LED_PWM PWM dimming signal input ( 3.3V)
36 LED_EN LED enable pin (3.3V)
37 NC No connection (Reserve)
38 V_LED LED power supply 7.5V~21V
39 V_LED LED power supply 7.5V~21V
40 V_LED LED power supply 7.5V~21V
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
SPEC NO. B T 1 4 0 G W 0 1 V. 2
PAGE 4/25
b. General Block Diagram
FPC
GS13401-1110P-7F (Foxconn)
VR DC/DC Pin1
T-CON LED
Driver
Connector plug in direction
Pin1
ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR
TRANSFORMED TO ANY OTHER FORMS WITHOUT PERMISSION FROM INNOLUX DISPLAY CORPORATION.
SPEC NO. B T 1 4 0 G W 0 1 V. 2
PAGE 5/25
2-2. Absolute Maximum Ratings
Values Unit
Parameter Symbol Remark
Min. Max.
