Image preview - the first page of the document
![Panel_INNOLUX_N133BGE-E31_0_[DS]](/pics/5e96beff2d115.gif)
>> Download Panel_INNOLUX_N133BGE-E31_0_[DS] documenatation <<
Text preview - extract from the document
PRODUCT SPECIFICATION
Doc. Number:
Tentative Specification
Preliminary Specification
Approval Specification
MODEL NO.: N133BGE
SUFFIX: E31
Customer:
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your
signature and comments.
Approved By Checked By Prepared By
2013-04-03 2013-03-25 2013-03-21
16:22:19 CST 14:29:09 CST 09:06:05 CST
Version 0.0 18 April 2013 1 / 38 The
copyright belongs to InnoLux. Any unauthorized use is prohibited.
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ......................................................................................................... 4
1.1 OVERVIEW ................................................................................................................................................4
1.2 GENERAL SPECIFICATI0NS ...................................................................................................................4
2. MECHANICAL SPECIFICATIONS ............................................................................................. 4
2.1 CONNECTOR TYPE..................................................................................................................................5
3. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 5
3.1 ABSOLUTE RATINGS OF ENVIRONMENT.............................................................................................5
3.2 ELECTRICAL ABSOLUTE RATINGS.......................................................................................................6
3.2.1 TFT LCD MODULE ............................................................................................................................6
4. ELECTRICAL SPECIFICATIONS............................................................................................... 7
4.1 FUNCTION BLOCK DIAGRAM ................................................................................................................7
4.2. INTERFACE CONNECTIONS ..................................................................................................................8
4.3.1 LCD ELETRONICS SPECIFICATION..............................................................................................10
4.3.2 LED CONVERTER SPECIFICATION ..............................................................................................12
4.3.3 BACKLIGHT UNIT............................................................................................................................14
4.4 LVDS INPUT SIGNAL TIMING SPECIFICATIONS.................................................................................15
4.4.1 LVDS DC SPECIFICATIONS ...........................................................................................................15
4.4.2 COLOR DATA INPUT ASSIGNMENT ..............................................................................................16
4.5 DISPLAY TIMING SPECIFICATIONS .....................................................................................................17
4.6 POWER ON/OFF SEQUENCE................................................................................................................18
5. OPTICAL CHARACTERISTICS ............................................................................................... 20
5.1 TEST CONDITIONS ................................................................................................................................20
5.2 OPTICAL SPECIFICATIONS ..................................................................................................................20
6. RELIABILITY TEST ITEM ........................................................................................................ 23
7. PACKING .................................................................................................................................. 24
7.1 MODULE LABEL.....................................................................................................................................24
7.2 CARTON ..................................................................................................................................................25
7.3 PALLET....................................................................................................................................................26
8. PRECAUTIONS ........................................................................................................................ 27
8.1 HANDLING PRECAUTIONS...................................................................................................................27
8.2 STORAGE PRECAUTIONS ....................................................................................................................27
8.3 OPERATION PRECAUTIONS.................................................................................................................27
Appendix. EDID DATA STRUCTURE ..........................................................................................................28
Appendix. OUTLINE DRAWING ..................................................................................................................31
Appendix. SYSTEM COVER DESIGN GUIDANCE .....................................................................................33
Version 0.0 18 April 2013 2 / 38 The
copyright belongs to InnoLux. Any unauthorized use is prohibited.
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page Description
0.0 Mar.13, 2013 All Tentative spec Ver. 0.0 was first issued.
Version 0.0 18 April 2013 3 / 38 The
copyright belongs to InnoLux. Any unauthorized use is prohibited.
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
N133BGE-E31 is a 13.3" (13.3" diagonal) TFT Liquid Crystal Display module with LED Backlight unit
and 30 pins eDP interface. This module supports 1366 x 768 HD mode and can display 262,144 colors.
The optimum viewing angle is at 6 o'clock direction.
1.2 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Screen Size 13.3 diagonal
Driver Element a-si TFT active matrix - -
Pixel Number 1366 x R.G.B. x 768 pixel -
Pixel Pitch 0.2148 (H) x 0.2148 (V) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 262,144 color -
Transmissive Mode Normally white - -
Surface Treatment Hard coating (3H), Anti - Glare - -
Luminance, White 200 Cd/m2
Power Consumption Total (2.95W) (Max.) @ cell (0.75W) (Max.), BL (2.2W) (Max.) (1)
Backlight Unit LEDs X 9 strings X 3 pallel
Power Consumption 3.0 typ./ 3.2 max @ Black Pattern Watt
RoHs Compliance yes
Note (1) The specified power consumption is under the conditions at VCCS = 3.3 V, Ta = 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
