Image preview - the first page of the document
![Panel_IVO_M133NWF2_R0_0_[DS]](/pics/5e96bfb2211a3.gif)
>> Download Panel_IVO_M133NWF2_R0_0_[DS] documenatation <<
Text preview - extract from the document
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 1/31
Document No. Issue date 2013/10/24 Revision 00
Product Information
To:
Product Name: M133NWF2 R0
Document Issue Date: 2013/10/24
Customer InfoVision Optoelectronics
SIGNATURE SIGNATURE
QA
PREPARED BY
FAE
Please return 1 copy for your confirmation
with your signature and comments.
Note: 1. Please contact IVO Corp. before designing your product based on this product.
2. The information contained herein is presented merely to indicate the characteristics and
performance of our products. No responsibility is assumed by IVO for any intellectual property
claims or other problems that may result from application based on the module described herein.
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 2/31
Document No. Issue date 2013/10/24 Revision 00
Revision Date Page Old Description New Description Remark
00 2013/10/24 all -- First issue.
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 3/31
Document No. Issue date 2013/10/24 Revision 00
Contents
1.0 General Descriptions ........................................................................................................... 4
2.0 Absolute Maximum Ratings ............................................................................................... 6
3.0 Pixel Format Image .............................................................................................................. 8
4.0 Optical Characteristics ........................................................................................................ 9
5.0 Backlight Characteristics ................................................................................................. 13
6.0 Electrical Characteristics .................................................................................................. 14
7.0 Interface Timings ................................................................................................................ 17
8.0 Power Consumption .......................................................................................................... 18
9.0 Power ON/OFF Sequence ................................................................................................. 20
10.0 Mechanical Characteristics .............................................................................................. 21
11.0 Package Specification ....................................................................................................... 24
12.0 Lot Mark................................................................................................................................ 25
13.0 General Precaution ............................................................................................................ 26
14.0 EDID Data Structure ........................................................................................................... 28
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 4/31
Document No. Issue date 2013/10/24 Revision 00
1.0 General Descriptions
1.1 Introduction
The M133NWF2 R0 is a color active matrix thin film transistor (TFT) liquid crystal
display (LCD) that uses amorphous silicon TFT as a switching device. It is composed of
a TFT LCD panel, a timing controller, voltage reference, common voltage, column driver,
and row driver circuit. This TFT LCD has a 13.3-inch diagonally measured active display
area with FHD resolution (1,920 horizontal by 1,080 vertical pixels array).
1.2 Features
13.3" TFT-LCD Panel
LED Backlight System
Supported FHD Resolution
Compatible with ROHS Standard
Supported eDP 1.2 Electrical Interface
1.3 Product Summary
Items Specifications Unit Remark
Screen Diagonal 13.3 Inch -
Active Area 293.76(H) x 165.24(V) mm -
Pixels (H x V) 1,920 (RGB) x 1,080 - -
Pixel Pitch 0.153(H) x 0.153(V) mm -
Pixel Arrangement R.G.B. Vertical Stripe - -
Display Mode Normally Black - -
White Luminance 250 (Typ.) cd/m2 5 Points Average
Contrast Ratio 800 (Typ.) - -
NTSC 72 (Typ.) % -
Response Time 25 (Typ.) ms -
Input Voltage +3.3 (Typ.) V -
Power Consumption 4.0 (Max.) W -
Weight 320 (Max.) g -
Outline Dimension
305.348(Typ.)x178.562(Typ.)x5.2(Max.) mm -
(H x V x D)
Electrical Interface (Logic) eDP1.2 - -
Support Color 16.7M - -
Surface Treatment HC, Hardness 3H - -
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 5/31
Document No. Issue date 2013/10/24 Revision 00
1.4 Functional Block Diagram
Figure 1 shows the functional block diagram of the LCD module.
Figure 1 Block Diagram
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 6/31
Document No. Issue date 2013/10/24 Revision 00
2.0 Absolute Maximum Ratings
Table 1 Electrical Absolute Rating
Item Symbol Min. Max. Unit Note
Logic Supply Voltage VDD -0.3 3.6 V
Logic Input Signal Voltage - -0.3 2.4 V
Supply VLED Voltage VLED -0.3 24.8 V (1),(2)
LED Forward Voltage VF 2.7 3.1 V
LED Forward Current IF - - mA
Note (1) Permanent damage may occur to the LCD module if beyond this specification. Functional
operation should be restricted to the conditions described under normal operating conditions.
(2)Operating temperature is 25, humidity is 55%.
Table 2 Absolute Ratings of Environment
Item Symbol Min. Max. Unit Conditions
Operating Temperature TOP 0 60
Operating Humidity HOP 10 80 %RH
(1),(2),(3)
Storage Temperature TST -20 60
Storage Humidity HST 10 90 %RH
Vibration(non-operating) Vnop - 1.5 G (4)
Shock(non-operating) Snop - 220G G (5)
Note (1) Maximum Wet-Bulb should be 39 . No condensation.
(2) When you apply the LCD module for OA system. Please make sure to keep the
temperature of LCD module is less than 60
(3) Storage /Operating temperature:
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 7/31
Document No. Issue date 2013/10/24 Revision 00
Figure 2 Absolute Ratings of Environment of the LCD Module
(4) 10-500Hz, random vibration, 30min for X, Y, Z axis.
(5) 2ms, half sine wave, one time for X, Y, Z axis.
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 8/31
Document No. Issue date 2013/10/24 Revision 00
3.0 Pixel Format Image
Figure 3 shows the relationship of the input signals and LCD pixel format image.
Figure 3 Pixel Format
R+G+B Dots=1 Pixel
_____________________________________________________________________
All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.
InfoVision Optoelectronics ( Kunshan ) Co.,LTD.
Document Title M133NWF2 R0 Product Information Page No. 9/31
Document No. Issue date 2013/10/24 Revision 00
4.0 Optical Characteristics
The optical characteristics are measured under stable conditions as following notes.
Table 3 Optical Characteristics
Item Conditions Min. Typ. Max. Unit Note
x+ 80 85 -
Horizontal
Viewing Angle x- 80 85 -
degree (1),(2)
CR>10 y+ 80 85 -
Vertical
y- 80 85 -
Contrast Ratio Center 500 800 - - (1), (3)
Response Time Rising + Falling - 25 50 ms (1), (4)
Red x 0.640 -
Red y 0.330 -
(1)
Green x Typ. 0.300 Typ. -
Color Viewing
Green y -0.03 0.612 +0.03 -
Chromaticity Normal
Blue x 0.150 -
(CIE1931) Angle (x =
Blue y 0.060 -
