Image preview - the first page of the document
![Panel_LG-Philips_LCD_LC420WUF-SSA1_0_[DS]](/pics/5eaf650c6d469.gif)
>> Download Panel_LG-Philips_LCD_LC420WUF-SSA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC420WUF
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 42.0" WUXGA TFT LCD
BUYER General SUPPLIER LG.Philips LCD Co., Ltd.
MODEL *MODEL LC420WUF
SUFFIX SSA1 (RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE 6,*1$785(
APPROVED BY $33529(' %<
DATE '$7(
/ 6 & :RQ 6HQLRU 0DQDJHU
5(9,(:(' %<
/ ' 6 .LP 0DQDJHU
35(3$5(' %<
/ . 6 0RRQ (QJLQHHU
Please return 1 copy for your confirmation with 79 3URGXFW 'HYHORSPHQW 'HSW
your signature and comments. /* 3KLOLSV /&' &R /WG
Ver. 1.0 1 /36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420WUF
Product Specification
CONTENTS
Number ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 7
3-2 INTERFACE CONNECTIONS 10
3-3 SIGNAL TIMING SPECIFICATIONS 13
3-4 SIGNAL TIMING WAVEFORMS 14
3-5 COLOR DATA REFERENCE 15
3-6 POWER SEQUENCE 16
4 OPTICAL SPECIFICATIONS 17
5 MECHANICAL CHARACTERISTICS 21
6 RELIABILITY 24
7 INTERNATIONAL STANDARDS 25
7-1 SAFETY 25
7-2 EMC 25
8 PACKING 26
8-1 DESIGNATION OF LOT MARK 26
8-2 PACKING FORM 26
9 PRECAUTIONS 27
9-1 MOUNTING PRECAUTIONS 27
9-2 OPERATING PRECAUTIONS 27
9-3 ELECTROSTATIC DISCHARGE CONTROL 28
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 28
9-5 STORAGE 28
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 28
Ver. 1.0 2 /36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420WUF
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
1.0 Mar.14.2008 - Final Specification
Ver. 1.0 3 /36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420WUF
Product Specification
1. General Description
The LC420WUF is a Color Active Matrix Liquid Crystal Display with an Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 42 inch diagonally measured
active dis pla y area wi th W UXGA resolution (1080 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for
each dot, thus presenting a palette of more than 1.06Billion (10bit(D)) of colors.
It has been designed to apply the 10-bit 4 port LVDS interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
Mini-LVDS(RGB)
SDRAM EEPROM
CN2 Source Driver Circuit
LVDS (41pin)
MEM RGB SDA
2Port SCL S1 S1920
CTRL
LVDS 3,4 G1
Gate Driver Circuit
CN1 Timing Controller
(51pin)
+12.0V LVDS 1,2
LVDS TFT - LCD Panel
