Image preview - the first page of the document
![Panel_LG-Philips_LCD_LM157E1-A2_0_[DS]](/pics/5eaf673605c1c.gif)
>> Download Panel_LG-Philips_LCD_LM157E1-A2_0_[DS] documenatation <<
Text preview - extract from the document
LM157E2-A2
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 15.7" SXGA TFT LCD
BUYER DID(Gateway) SUPPLIER LG.Philips LCD Co., Ltd.
MODEL *MODEL LM157E2
SUFFIX A2
* When you obtain standard approval ,
please use the above model name without suffix.
SIGNATURE DATE APPROVED BY DATE
/ S.H. Kang / G.Manager
REVIEWED BY
B.K. Kim / Manager
/ J.T. Kim / Manager
PREPARED BY
S.H.Kim / Engineer
/ K.K.Jang / Manager
Please return 1 copy for your confirmation Product Engineering Dept.
with your signature and comments. LG.Philips LCD Co., Ltd.
The preliminary document is subject to change without prior notice.
Ver 1.0 SEP 30, 2000 Page 1/24
LM157E2-
A2
Product Specification
CONTENTS
NO. ITEM Page
- COVER 1
- CONTENTS 2
- RECORD OF REVISION 3
1 GENERAL DESCRIPTION 4
2 MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 6
3-2 INTERFACE CONNECTION 7
3-3 SIGNAL TIMING SPECIFICATIONS 9
3-4 SIGNAL TIMING WAVE FORMS 10
3-5 COLOR INPUT DATA REFERENCE 11
3-6 POWER SEQUENCE 12
4 OPTICAL SPECIFICATIONS 13
5 MECHANICAL CHARACTERISTICS 15
6 RELIABILITY 18
7 INTERNATIONAL STANDARDS 19
7-1 SAFETY 19
7-2 EMC 19
8 PACKING 20
8-1 DESIGNATION OF LOT MARK 20
8-2 PACKING FORM 20
9 PRECAUTIONS 21
APPENDIX 23
A-1 OPTICAL CHARACTERISTIC MEASUREMENT EQUIPMENT AND METHOD 23
A-2 LUMINANCE 23
A-3 RESPONSE TIME 23
A-4 VIEWING ANGLE 24
Ver 1.0 SEP 30, 2000 Page 2/24
LM157E2-
A2
Product Specification
RECORDS OF REVISIONS
Version No Date Page DESCRIPTION
1.0 SEP.30, 2000 - Final Specification
Ver 1.0 SEP 30, 2000 Page 3/24
LM157E2-
A2
Product Specification
1. General Description
The LM157E2-A2 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode
Fluorescent Lamp(CCFL) back light system. The matrix employs a-Si Thin Film Transistor as the active
element. It is a transmissive type display operating in the normally white mode. This TFT-LCD has a 15.7
inch diagonally measured active display area with SXGA resolution(1024 vertical by 1280 horizontal pixel
array). Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal
for each dot, thus, presenting a palette of more than 16,777,216 colors.
The LM157E2-A2 has been designed to apply the interface method that enables low power, high speed
low EMI. FPD Link must be used as a LVDS(Low Voltage Differential Signaling) chip.
The LM157E2-A2 is intended to support applications where thin thickness and low power consumption
are critical factors and graphic displays are important. In combination with the vertical arrangement of the
sub-pixels, the LM157E2-A2 characteristics provide an excellent flat panel display for office automation
products such as monitors.
RGB
Column Driver
S1 S1280
G1
LVDS
Pair#1
Row
Timing Control
LVDS Driver TFT-LCD
Pair #2 & LVDS 1Chip
circuiit (1280 x RGB x 1024
G1024
Power
Block
CN2 Backlight 2EA
General Features
The following are general feature of the model LM157E1-A2 LCD;
Active screen size 15.7 inches(39.832cm) diagonal
