Image preview - the first page of the document
![Panel_LG-Philips_LCD_LM151X4-A3_0_[DS]](/pics/5eaf67203231b.gif)
>> Download Panel_LG-Philips_LCD_LM151X4-A3_0_[DS] documenatation <<
Text preview - extract from the document
LM151X4-A3
2525
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 15.1" XGA TFT LCD
BUYER SUPPLIER LG.Philips LCD Co., Ltd.
MODEL MODEL LM151X4-A3
SIGNATURE DATE APPROVED BY DATE
/ S.H.Kang / G.Manager
REVIEWED BY
/ G. T. Kim/S.Engineer
PREPARED BY
/ S. G. Hong/S.Engineer
Please return 1 copy for your confirmation Product Engineering Dept.
with your signature and comments. LG.Philips LCD Co., Ltd.
Alpha Point Ltd.
P.O. Box 41 Tel.: +358-9-34 64 34 1
http://www.alpha.fi 00751 Helsinki, Finland Fax: +358-9-34 64 34 2
00-10-31 Ver 0.0 JUN 1, 2000 Page 1/24
LM151X4-A3
2525
Liquid Crystal Display
Product Specification
CONTENTS
NO. ITEM Page
- COVER 1
- CONTENTS 2
- RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 SIGNAL TIMING SPECIFICATIONS 9
3-4 SIGNAL TIMING WAVEFORMS 10
3-5 COLOR INPUT DATA REFERENCE 11
3-6 POWER SEQUENCE 12
3-7 Vcc DIP CONDITION 13
4 OPTICAL SPECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 17
6 RELIABILITY 20
7 INTERNATIONAL STANDARDS 21
7-1 SAFETY 21
7-2 EMC 21
8 PACKING 22
8-1 DESIGNATION OF LOT MARK 22
8-2 PACKING FORM 22
9 PRECAUTIONS 24
Alpha Point Ltd.
P.O. Box 41 Tel.: +358-9-34 64 34 1
http://www.alpha.fi 00751 Helsinki, Finland Fax: +358-9-34 64 34 2
00-10-31 Ver 0.0 JUN 1, 2000 Page 2/24
LM151X4-A3
2525
Liquid Crystal Display
Product Specification
RECORDS OF REVISIONS
Version No Date Page DESCRIPTION
0.0 JUN. 1, 2000 First draft.
Alpha Point Ltd.
P.O. Box 41 Tel.: +358-9-34 64 34 1
http://www.alpha.fi 00751 Helsinki, Finland Fax: +358-9-34 64 34 2
00-10-31 Ver 0.0 JUN 1, 2000 Page 3/24
LM151X4-A3
2525
Liquid Crystal Display
Product Specification
1. General Description
The LM151X4-A3 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element. It is a
transmissive type display operating in the normally white mode. This TFT-LCD has a 15.1 inchs diagonally
measured active display area with XGA resolution(768 vertical by 1024 horizontal pixel array). Each pixel is
divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the
brightness of the sub-pixel color is determined with a 6-bit gray scale signal for each dot, thus, presenting a
palette of more than 262,144 colors.
The LM151X4-A3 has been designed to apply the TTL interface method.
The LM151X4-A3 LCD is intended to support applications where high brightness, wide viewing angle, high
color saturation, and high color depth are very important. In combination with the vertical arrangement of
the sub-pixels, the LM151X4-A3 characteristics provide an excellent flat panel display for office automation
products such as monitors.
Timing
Control Column driver circuit
Block Row Driver circuit
CN1
TFT-LCD
