Image preview - the first page of the document
![Panel_LG-Philips_LCD_LM240WU2-SLB2_0_[DS]](/pics/5eaf69323f607.gif)
>> Download Panel_LG-Philips_LCD_LM240WU2-SLB2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 24.0" WUXGA TFT LCD
BUYER APPLE SUPPLIER LG.Philips LCD Co., Ltd.
MODEL *MODEL LM240WU2
SUFFIX SLB1/SLB2/SLB3
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ Hans Kim / G.Manager
REVIEWED BY
/ S.Y Park / Manager
PREPARED BY
/ Harry Kim / Engineer
Please return 1 copy for your confirmation with MNT Products Engineering Dept.
your signature and comments. LG. Philips LCD Co., Ltd
Ver. 1.0 Jan. 01. 17. 2008 1 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 8
3-3 SIGNAL TIMING SPECIFICATIONS 11
3-4 SIGNAL TIMING WAVEFORMS 12
3-5 COLOR INPUT DATA REFERNECE 13
3-6 POWER SEQUENCE 14
4 OPTICAL SFECIFICATIONS 16
5 MECHANICAL CHARACTERISTICS 22
6 RELIABLITY 25
7 INTERNATIONAL STANDARDS 26
7-1 SAFETY 26
7-2 EMC 26
8 PACKING 27
8-1 DESIGNATION OF LOT MARK 27
8-2 PACKING FORM 27
9 PRECAUTIONS 28
10 EDID DATA FOR LM240WU2-SLA1 30
Ver. 1.0 Jan. 01. 17. 2008 2 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
Revision
Revision Date Page Description
No
1.0 Jan. 17. 2008 - Final Specification
Ver. 1.0 Jan. 01. 17. 2008 3 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
1. General Description
LM240WU2 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 24inch diagonally measured
active display area with WUXGA resolution (1200 vertical by 1920 horizontal pixel array)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus, presenting a palette of more than 16,7M(True) colors.
It has been designed to apply the 8Bit 2 port LVDS interface.
It is intended to support displays where high brightness, super wide viewing angle,
high color saturation, and high color are important.
RGB Source Driver Circuit
S1 S1920
LVDS
G1
2port
Gate Driver Circuit
CN1 Timing
(30pin)
Controller
+12.0V
TFT - LCD Panel
(1920 RGB 1200 pixels)
G1200
+12.0V
Power Circuit
Block
+24.0V Back light Assembly
CN2 Inverter 2pin x 7CNs (High) (Direct Light Type_14CCFL)
GND (14Pin)
Block
4pin x 1CNs (Low)
General Features
Active Screen Size 24.0 inches(60.96cm) diagonal
Outline Dimension 546.4(H) x 350.0(V) x 28.9(D) mm(Typ.)
Pixel Pitch 0.270 mm x 0.270 mm
Pixel Format 1920 horiz. By 1200 vert. Pixels RGB stripes arrangement
Color Depth 8-bit, 16,777,216 colors
Luminance, White 400 cd/m2 ( 5 points Avg.)
Viewing Angle(CR>10) View Angle Free (R/L 178(Typ.), U/D 178(Typ.))
Total 71.95 Watt (Typ.) (5.95 Watt @VLCD, 66 Watt @400cd) for SLB1/SLB3
Power Consumption
Total 70.92 Watt (Typ.) (4.92 Watt @VLCD, 66 Watt @400cd) for SLB2
Weight 2650g (typ.)
Display Operating Mode Transmissive mode, normally black
Surface Treatment Hard coating(2H), Glare(Low Reflection treatment of the front polarizer)
Ver. 1.0 Jan. 01. 17. 2008 4 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VLCD -0.3 21 Vdc at 25 r 2 C
Operating Temperature TOP 0 50 C
Storage Temperature TST -20 60 C
1
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
Ver. 1.0 Jan. 01. 17. 2008 5 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and
liquid crystal. The second input power for the CCFL, is typically generated by an inverter. The inverter is an
external unit to the LCDs.
Table 2-1. ELECTRICAL CHARACTERISTICS
For SLB1/SLB3
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 11.4 12.0 12.6 Vdc
Permissive Power Input Ripple VdRF 400 mVp-p
- 495 570 mA 1
Power Supply Input Current ILCD
- 675 878 mA 2
Power Consumption PLCD - 5.95 6.84 Watt 1
Rush current IRUSH - - 3.0 A 3
For SLB2
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 11.4 12.0 12.6 Vdc
Permissive Power Input Ripple VdRF 400 mVp-p
- 410 472 mA 1
Power Supply Input Current ILCD
- 580 667 mA 2
Power Consumption PLCD - 4.92 5.66 Watt 1
Rush current IRUSH - - 3.0 A 3
Note :
1. The specified current and power consumption are under the VLCD=12.0V, 25 r 2 C,fV=60Hz condition
whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current is specified at the maximum current pattern.
3. The duration of rush current is about 2ms and rising time of power Input is 1ms(min.).
White : 255Gray
Black : 0Gray Maximum current pattern
Mosaic Pattern(8 x 6) White Pattern
Ver. 1.0 Jan. 01. 17. 2008 6 / 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM240WU2
Liquid Crystal Display
Product Specification
Table 2-2. INVERTER ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Condition Unit Notes
Min. Typ. Max.
Inverter :
Input Voltage VDDB 21.6 24.0 26.4 V 1
Input Current IDDB Vin=24V, Vbr = max - 2.75 3.02 A 2
Input Power PB Vin=24V, Vbr = max - 66 72.6 Watt 2
Lamp ON = High 2.0 - 5.0 V
B/L on/off control VON/OFF
Lamp OFF =Low 0.0 - 0.8 V
Lamp Voltage Vout Vin=24V, Vbr=max 750 950 1150 Vrms
Io(Min) Vin=24V, Vbr=min 2.5 - - mArms
Lamp Current
Io(Max) Vin=24V, Vbr=max 3.7 4.2 4.7 mArms
Brightness Adj VBR Vin=24V 0 - 3.3 V
Frequency Fo Vbr=max 40 44 48 KHz
Burst Frequency Fb Vin=24V, Vbr=min - 180 - Hz
Open Lamp No load
Vopen 1300 - - Vrms
Voltage Vin=21.6V, Vbr=max
Asymmetry Ratio Vin=24V - - 10.0 % 3
Distortion Ratio Vin=24V 1.27 - 1.55 3
No load
Striking Time Ts 1.0 - 2.0 Sec
Vin=21.6V, Vbr=max
Efficiency Vin=24V Vbr=max 80 %
LAMP :
Life time 50,000 Hrs 4
Notes :
1. The input voltage ripple is limited below 400mVp-p.
2.The specified current and power consumption are under the typical supply Input voltage, 24V.
3. Voltage and current is measured for Asymmetry ratio and Distortion ratio.
