Image preview - the first page of the document
![Panel_LG-Philips_LCD_LP133WX2-TLG6_0_[DS]](/pics/5eaf69c9bc9f5.gif)
>> Download Panel_LG-Philips_LCD_LP133WX2-TLG6_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 13.3" WXGA TFT LCD
Customer General SUPPLIER LG.Philips LCD Co., Ltd.
MODEL *MODEL LP133WX2
Suffix TLG6/C6/C4
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
K. J. Kwon / S.Manager
/
REVIEWED BY
/
S. W. Paeng / Manager
/ PREPARED BY
H. H. Lee / Engineer
Please return 1 copy for your confirmation with Product Engineering Dept.
your signature and comments. LG. Philips LCD Co., Ltd
Ver. 0.0 03. Jun., 2008 1 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 8
3-4 SIGNAL TIMING WAVEFORMS 11
3-5 COLOR INPUT DATA REFERNECE 12
3-6 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 18
6 RELIABLITY 21
7 INTERNATIONAL STANDARDS
7-1 SAFETY 22
7-2 EMC 22
8 PACKING
8-1 DESIGNATION OF LOT MARK 23
8-2 PACKING FORM 23
9 PRECAUTIONS 24
A APPENDIX. Enhanced Extended Display Identification Data 26
Ver. 0.0 03. Jun., 2008 2 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 03. Jun.. 2008 - First draft -
Ver. 0.0 03. Jun., 2008 3 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
1. General Description
The LP133WX2 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 13.3 inches diagonally measured active display area with WXGA
resolution(1280 horizontal by 800 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144 colors.
The LP133WX2 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP133WX2 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the LP133WX2
characteristics provide an excellent flat display for office automation products such as Notebook PC.
'
General Features
Active Screen Size 13.3 inches diagonal
Outline Dimension 297.15 (H) 192.15 (V) 3.6(D, Max.) mm
Pixel Pitch 0.2235 mm 0.2235 mm
Pixel Format 1280 horiz. by 800 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 275 cd/m2(Typ., @ILED=19mA)
Power Consumption Logic : 0.76W(typ.@Mosaic), Back Light : 3.2W(typ.@ ILED= 19mA)
Weight 315(Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Hard Coating(Glare), Anti reflection treatment of the front Polarizer (Haze 0%)
Ver. 0.0 03. Jun., 2008 4 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 0.0 03. Jun., 2008 5 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP133WX2 requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input which powers the LED BL.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VCC 3.0 3.3 3.6 VDC
Power Supply Input Current ICC Mosaic - 230 265 mA 1
Power Consumption Pc - 0.76 0.875 Watt 1
Differential Impedance Zm 90 100 110 Ohm 2
LED Backlight :
Operating Voltage VLED - 27.9 30.6 V 3
Operating Current per string ILED 5 19 20 mA 4
Power Consumption PBL - 3.2 3.5 Watt 5
Life Time 10,000 - - Hrs 6
Note)
1. The specified current and power consumption are under the Vcc = 3.3V , 25 , fv = 1.2Hz condition
whereas Mosaic pattern is displayed and fv is the frame frequency.
2. This impedance value is needed to proper display and measured form LVDS Tx to the mating connector.
3. The typical operating current is for the typical surface luminance (LWH) in optical characteristics.
4. Define the brightness of the lamp after being lighted for 5 minutes as 100%, Ts is the time required for
the brightness of the center of the lamp to be not less than 95%.
5. The life time is determined as the time at which brightness of lamp is 50% compare to that of initial value
at the typical lamp current.
6. The life time is determined as the time at which brightness of LED is 50% compare to that of initial value
at the typical LED current.
Ver. 0.0 03. Jun., 2008 6 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WX2
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs two interface connections, a 30 pin connector is used for the module electronics interface
and the other connector is used for the integral backlight system.
The electronics interface connector is a model 20347-330E-12 manufactured by I-PEX.
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
SiliconWorks, SW0618V
