Image preview - the first page of the document

>> Download Panel_LG-Philips_LCD_LP141WP1-TLC3_0_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

SPECIFICATION
FOR
APPROVAL

( ) Preliminary Specification
( ) Final Specification

Title 14.1" WXGA+ TFT LCD

Customer DELL SUPPLIER LG Display Co., Ltd.

MODEL *MODEL LP141WP1
Suffix TLC3
*When you obtain standard approval,
please use the above model name without suffix

APPROVED BY SIGNATURE
APPROVED BY SIGNATURE

G. J. Kwon / G.Manager
/ REVIEWED BY

/
G. J. Han / Manager
PREPARED BY
/
C. Y. Kim / Engineer

J. M. Shin / Engineer

Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd

Ver. 0.0 Apr. 14, 2008 1 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

Contents
No ITEM Page
COVER 1

CONTENTS 2

RECORD OF REVISIONS 3

1 GENERAL DESCRIPTION 4

2 ABSOLUTE MAXIMUM RATINGS 5

3 ELECTRICAL SPECIFICATIONS

3-1 ELECTRICAL CHARACTREISTICS 6

3-2 INTERFACE CONNECTIONS 8

3-3 LVDS SIGNAL TIMING SPECIFICATIONS 9

3-4 SIGNAL TIMING SPECIFICATIONS 11

3-5 SIGNAL TIMING WAVEFORMS 11

3-6 COLOR INPUT DATA REFERNECE 12

3-7 POWER SEQUENCE 13

4 OPTICAL SFECIFICATIONS 14

5 MECHANICAL CHARACTERISTICS 17

6 RELIABLITY 24

7 INTERNATIONAL STANDARDS

7-1 SAFETY 25

7-2 EMC 25

8 PACKING

8-1 DESIGNATION OF LOT MARK 26

8-2 PACKING FORM 26

9 PRECAUTIONS 27

A APPENDIX. Enhanced Extended Display Identification Data 29

Ver. 0.0 Apr. 14, 2008 2 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

RECORD OF REVISIONS

EDID
Revision No Revision Date Page Description
ver
0.0 Nov. 10. 2007 - First Draft (Preliminary Specification) 0.0
0.1 Apr. 14. 2008 4 Define Power Consumption
Apr. 14. 2008 6 Define Power Supply Input Current and Power Consumption
Apr. 14. 2008 8 Revise Lamp Wire Color
Apr. 14. 2008 11 Change Signal Timing Specifications by WWAN Solution.
Apr. 14. 2008 20 Correct Mounting hole location.
Apr. 14. 2008 20 Added 2D Label Informations.
Apr. 14. 2008 29~31 Revise EDID Informations.

Ver. 0.0 Apr. 14, 2008 3 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

1. General Description
The LP141WP1 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp (CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element. It is a
transmissive type display operating in the normally white mode. This TFT-LCD has 15.4 inches diagonally
measured active display area with WXGA resolution(900 vertical by 1440 horizontal pixel array). Each pixel
is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or
the brightness of the sub-pixel color is determined with a 6-bit gray scale signal for each dot, thus,
presenting a palette of more than 262,144 colors.
The LP141WP1 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP141WP1 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP141WP1 characteristics provide an excellent flat display for office automation products such as Notebook
PC.

General Features
Active Screen Size 14.1 inches diagonal
Outline Dimension 320.0 (H) 206.0 (V) 5.5(D, max) mm
Pixel Pitch 0.2109 mm 0.2109 mm
Pixel Format 1440 horiz. by 900 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 235 cd/m2(Typ.) , 5 point
Power Consumption Total 5.49 Watt(Typ.) @ LCM circuit 1.39 Watt(Typ.), B/L input 4.1 Watt(Typ.)
Weight 435g (Max.), 425g(Typ.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-glare treatment of the front polarizer
RoHS Comply Yes

Ver. 0.0 Apr. 14, 2008 4 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.

Table 1. ABSOLUTE MAXIMUM RATINGS

Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC

Operating Temperature TOP 0 50 qC 1

Storage Temperature HST -20 60 qC 1

Operating Ambient Humidity HOP 10 90 %RH 1

Storage Humidity HST 10 90 %RH 1

Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.

90% 80%

60 60%

Wet Bulb 50
Humidity[(%)RH]

Temperature [ ] Storage

40 40%

30 Operation
20
20%
10
0
10%

-20 0 10 20 30 40 50 60 70 80

Dry Bulb Temperature [ ]

Ver. 0.0 Apr. 14, 2008 5 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

3. Electrical Specifications
3-1. Electrical Characteristics
The LP141WP1 requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input which powers the CCFL, is typically generated by an
inverter. The inverter is an external unit to the LCD.

Table 2. ELECTRICAL CHARACTERISTICS

Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VCC 3.0 3.3 3.6 VDC
Power Supply Input Current ICC 385 445 mA 1
Power Consumption Pc - 1.27 1.47 Watt 1
Differential Impedance Zm 90 100 110 Ohm 2
LAMP :
640 655 880
Operating Voltage VBL VRMS
(7.0mA) (6.3mA) (2.0mA)
Operating Current IBL 2.0 6.3 7.0 mARMS 3
Power Consumption PBL - 4.1 4.5
Operating Frequency fBL 50 65 80 kHz
Discharge Stabilization Time Ts - - 3 Min 4
Life Time 15,000 - - Hrs 5

Established Starting Voltage
at 25 Vs 1180 VRMS
at 0 1415 VRMS

Note)
1. The specified current and power consumption are under the Vcc = 3.3V , 25 , fv = 60Hz condition
whereas Mosaic pattern is displayed and fv is the frame frequency.

2. This impedance value is needed to proper display and measured form LVDS Tx to the mating connector.
3. The typical operating current is for the typical surface luminance (LWH) in optical characteristics.
4. Define the brightness of the lamp after being lighted for 5 minutes as 100%, Ts is the time required for
the brightness of the center of the lamp to be not less than 95%.
5. The life time is determined as the time at which brightness of lamp is 50% compare to that of initial value
at the typical lamp current.

Ver. 0.0 Apr. 14, 2008 6 / 31

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

LP141WP1
Liquid Crystal Display
Product Specification

Note)
6. The output of the inverter must have symmetrical(negative and positive) voltage waveform and
symmetrical current waveform.(Asymmetrical ratio is less than 10%) Please do not use the inverter
which has asymmetrical voltage and asymmetrical current and spike wave.
Lamp frequency may produce interface with horizontal synchronous frequency and as a result this may
cause beat on the display. Therefore lamp frequency shall be as away possible from the
horizontal synchronous frequency and from its harmonics in order to prevent interference.
7. It is defined the brightness of the lamp after being lighted for 5 minutes as 100%.
TS is the time required for the brightness of the center of the lamp to be not less than 95%.
8. The lamp power consumption shown above does not include loss of external inverter.
The applied lamp current is a typical one.
9. Requirements for a system inverter design, which is intended to have a better display performance, a
better power efficiency and a more reliable lamp, are following.
It shall help increase the lamp lifetime and reduce leakage current.
a. The asymmetry rate of the inverter waveform should be less than 10%.
b. The distortion rate of the waveform should be within 2 10%.
* Inverter output waveform had better be more similar to ideal sine wave.

* Asymmetry rate:
Ip
| I p
