Image preview - the first page of the document



>> Download Panel_LG-Philips_LCD_LP171W02-A4_0_[DS] documenatation <<

Text preview - extract from the document

   Global LCD Panel Exchange Center                    www.panelook.com




                                                                                                                                LM171W02-A4
                                                                                                                         Liquid Crystal Display
                                                     Product Specification

         1. General Description
           The LM171W02-A4 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode
         Fluorescent Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
         It is a transmissive type display operating in the normally white mode. This TFT-LCD has a 17.1 inch
         diagonally measured active display area with WXGA resolution(900 vertical by 1440 horizontal pixel array)
         Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
         Gray scale or the brightness of the sub-pixel color is determined with a 6-bit gray scale signal for each dot,
         thus, presenting a palette of more than    #    colors.
         The LM171W02-A4 has been designed to apply the 8Bit TMDS interface method.The LM171W02-A4 is
         intended to support displays where high brightness, wide viewing angle, high color saturation, and high color
         depth are very important.



                                                                                                              Source Driver Circuit
          RGB, Dclk, DE
                                                 Timing Control                                              S1                S1440
          Hsync, Vsync
                         CN1                          Block
           (TMDS 1port) (30pin)
                                                                                                       G1
                                                                                Gate Driver circuit

            VCC(+3.3V)
                                                                                                                    TFT-LCD Panel
                                            Power Circuit Block                                                   (1440
