Image preview - the first page of the document
![Panel_LG_Display_LM190E0C-SLA1_0_[DS]](/pics/5eafcb9d1429c.gif)
>> Download Panel_LG_Display_LM190E0C-SLA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 19.0" SXGA TFT LCD
BUYER General SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LM190E0C
SUFFIX SLA1
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE DATE APPROVED BY DATE
C. K. Lee / G.Manager
/
REVIEWED BY
B. C. Kim / Manager [C]
/ Y. H. Hwang / Manager [M]
J. K. Lee / Manager [P]
PREPARED BY
/
M. L. Yoon / Engineer
Please return 1 copy for your confirmation Product Engineering Dept.
With your signature and comments. LG Display Co., Ltd
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
1) ELECTRICAL CHARACTERISTICS 6
2) INTERFACE CONNECTIONS 8
3) LVDS characteristics 11
4) SIGNAL TIMING SPECIFICATIONS 14
5) SIGNAL TIMING WAVEFORMS 15
6) COLOR INPUT DATA REFERNECE 16
7) POWER SEQUENCE 17
8) POWER DIP CONDITION 18
4 OPTICAL SFECIFICATIONS 19
5 MECHANICAL CHARACTERISTICS 25
6 RELIABILITY 28
7 INTERNATIONAL STANDARDS 29
1) SAFETY 29
2) EMC 29
3) ENVIRONMENT 29
8 PACKING 30
1) DESIGNATION OF LOT MARK 30
2) PACKING FORM 30
9 PRECAUTIONS 31
1) MOUNTING PRECAUTIONS 31
2) OPERATING PRECAUTIONS 31
3) ELECTROSTATIC DISCHARGE CONTROL 32
4) PRECAUTIONS FOR STRONG LIGHT EXPOSURE 32
5) STROAGE 32
6) HANDLING PRECAUTIONS FOR PROTECTION FILM 32
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Record of revisions
Revision Revision
Page Description
No Date
0.0 Apr. 24. 2013. - First Draft(Preliminary)
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
1. General description
LM190E0C-SLA1 is a Color Active Matrix Liquid Crystal Display with a Light Emitting Diode (LED) backlight
system. The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display
operating in the normally black mode. It has a 19.0 inch diagonally measured active display area with SXGA
resolution (1024 vertical by 1280 horizontal pixel array) Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 8-bit gray scale signal for each dot, thus, presenting a palette of more than 16,7M colors with
Advanced-FRC(Frame Rate Control). It has been designed to apply the interface method that enables low
power, high speed, low EMI. FPD Link or compatible must be used as a LVDS(Low Voltage Differential
Signaling) chip. It is intended to support applications where thin thickness, wide viewing angle, low power are
critical factors and graphic displays are important. In combination with the vertical arrangement of the sub-
pixels, the LM190E0C-SLA1 characteristics provide an excellent flat panel display for office automation
products such as monitors.
FIG. 1 Block diagram RGB
Source driver circuit
S1 S1280
LVDS G1
Gate Driver Circuit
pair #1 Timing
LVDS
controller
pair #2 TFT-LCD Panel
CN1 (1280 RGB 1024 pixels)
(30Pin)
G1024
+5V
VLCD Power circuit
block
Backlight assembly (W LED)
VLED 2ch
General features
Active screen size 19.0 inches (481.92mm) diagonal
Outline Dimension 396.0(H) x 324.0(V) x 9.9(D) mm(Typ.)
Pixel Pitch 0.098*RGB(H)mm x 0.294(V)mm
Pixel Format 1280 horizontal By 1024 vertical Pixels. RGB stripe arrangement
Interface LVDS 2Port
Color depth 16.7M colors
Luminance, white 250 cd/m2 (Center 1Point, typ)
Viewing Angle (CR>10) R/L 178(Typ.), U/D 178(Typ.)
Power Consumption Target total TBD W(Typ.), (TBD W@VLCD , 7.2 W_w/o driver)
Weight TBD g(typ.)
Display operating mode Transmissive mode, normally Black
Surface treatments Hard coating (3H), Anti-glare treatment of the front polarizer
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
2. Absolute maximum ratings
The following are maximum values which, if exceeded, may cause faulty operation or
damage to the unit.
Table 1. Absolute maximum ratings
Values
Parameter Symbol Units Notes
Min Max
Power Supply Input Voltage VLCD -0.3 +6.0 Vdc At 25
Operating Temperature TOP 0 50 C
Storage Temperature TST -20 60 C
1,2,3
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
LCM Surface Temperature
TSurface 0 65 1, 4
(Operation)
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
2. Maximum Storage Humidity is up to 40 , 90% RH only for 4 corner light leakage Mura.
3. Storage condition is guaranteed under packing condition
4. LCM Surface Temperature should be Min. 0 and Max. 65 under the VLCD=5.0V,
fV=60Hz, 25 ambient Temp. no humidity control and LED string current is typical value.
FIG. 2 Temperature and relative humidity
90%
60
60%
50 Storage
Wet Bulb
Temperature [ ]
Humidity
[(%)RH]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3. Electrical specifications
3-1. Electrical characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input power for the LED/Backlight, is typically
generated by an LED Driver. The LED driver is an external unit to the LCDs.
Table 2. Electrical characteristics
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Input Voltage Ripple VRF - - 0.2 V 3
ILCD-MOSAIC - TBD - mA 1
Power Supply Input Current
ILCD-Black - TBD - mA 2
Power Consumption PLCD - TBD - Watt 1
Inrush current IRUSH - - 3.0 A 4
Note :
1. The specified current and power consumption are under the VLCD=5.0V, 25 r 2 C,fV=60Hz
condition whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current is specified at the maximum current pattern.
3. Permissive power ripple should be measured under VLCD=5.0V, maximum frame rate (fV) at 25 C.
Additionally, we recommend the bandwidth configuration of oscilloscope is to be under 20MHz.
4. The duration of rush current is about 5ms and rising time of power Input is 500us r 20%.
FIG.3 pattern for Electrical characteristics
power consumption measurement power input ripple
White : 255Gray
Black : 0Gray
Mosaic Pattern(8 x 6) Black
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Table 3. LED array ELECTRICAL CHARACTERISTICS
Values
Note
Parameter Symbol Condition Unit
s
Min. Typ. Max.
LED String Current Is - 80 85 mA 1,2,5
LED String Voltage Vs 42 45 48 V 1,5
Power Consumption PBar 7.2 7.7 Watt 1,2,4
LED Life Time LED_LT 30,000 - - Hrs 3
Notes) The LED Bar consists of 30 LED packages, 2 strings (parallel) x 15 packages (serial)
LED driver design guide
: The design of the LED driver must have specifications for the LED in LCD Assembly.
The performance of the LED in LCM, for example life time or brightness, is extremely
influenced by the characteristics of the LED driver.
So all the parameters of an LED driver should be carefully designed and output current
should be Constant current control.
Please control feedback current of each string individually to compensate the current
variation among the strings of LEDs.
When you design or order the LED driver, please make sure unwanted lighting caused by
the mismatch of the LED and the LED driver (no lighting, flicker, etc) never occurs.
When you confirm it, the LCD module should be operated in the same condition as
installed in your instrument.
Notes :
1. The specified values are for a single LED bar.
2. The specified current is defined as the input current for a single LED string with 100% duty cycle.
3. The LED life time is defined as the time when brightness of LED packages become 50% or less
than the initial value under the conditions at Ta = 25 r 2 C and LED string current is typical value.
4. The power consumption shown above does not include loss of external driver.
The typical power consumption is calculated as PBar = Vs(Typ.) x Is(Typ.) x No. of strings.
The maximum power consumption is calculated as PBar = Vs(Max.) x Is(Typ.) x No. of strings.
5. LED operating conditions must not exceed Max. ratings.
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-2. Interface connections
3-2-1. LCD Module
LCD connector(CN1) : IS100-L30O-C23(UJU)
Mating connector : FI-X30H and FI-X30HL (JAE) or Equivalent
Table 4. Module connector(CN1) pin configuration
Pin No Symbol Description
1 RXO0- Minus signal of 1st channel 0 (LVDS)
2 RXO0+ Plus signal of 1st channel 0 (LVDS)
3 RXO1- Minus signal of 1st channel 1 (LVDS)
4 RXO1+ Plus signal of 1st channel 1 (LVDS)
5 RXO2- Minus signal of 1st channel 2 (LVDS)
6 RXO2+ Plus signal of 1st channel 2 (LVDS) First Pixel data
7 GND Ground
8 RXOC- Minus signal of 1st clock channel (LVDS)
9 RXOC+ Plus signal of 1st clock channel (LVDS)
10 RXO3- Minus signal of 1st channel 3 (LVDS)
11 RXO3+ Plus signal of 1st channel 3 (LVDS)
12 RXE0- Minus signal of 2nd channel 0 (LVDS)
13 RXE0+ Plus signal of 2nd channel 0 (LVDS)
14 GND Ground
15 RXE1- Minus signal of 2nd channel 1 (LVDS)
16 RXE1+ Plus signal of 2nd channel 1 (LVDS)
17 GND Ground Second Pixel data
18 RXE2- Minus signal of 2nd channel 2 (LVDS)
19 RXE2+ Plus signal of 2nd channel 2 (LVDS)
20 RXEC- Minus signal of 2nd clock channel (LVDS)
21 RXEC+ Plus signal of 2nd clock channel (LVDS)
22 RXE3- Minus signal of 2nd channel 3 (LVDS)
23 RXE3+ Plus signal of 2nd channel 3 (LVDS)
24 GND Ground
25 NC No Connection (I2C Serial interface for LCM)
26 NC No Connection (I2C Serial interface for LCM)
27 ITLC Interlace mode selection
28 VLCD Power Supply (5.0V)
29 VLCD Power Supply (5.0V)
30 VLCD Power Supply (5.0V)
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
FIG. 4 Connector diagram
IS100-L30O-C23(UJU)
#
#30
#11 #30
1'st signal pairs
2'nd signal pairs
ITLC Power(+5V)
Rear view of LCM
Note:
1. NC: No Connection.
2. All GND(ground) pins should be connected together and to Vss which should also
be connected to the LCD's metal frame.
3. 3. All VLCD (power input) pins should be connected together.
4. Input Level of LVDS signal is based on the IEA 664 Standard.
5. ITLC is Interlace mode selection pin. (Low : Normal Mode, High : Interlace mode)
If you don't use this pin, it should be connected to GND.
(Low level Input Voltage : GND ~ 0.4V, High level Input Voltage : 1.6 ~ 3.6V,
Absolute maximum ratings : - 0.5 ~ 4V)
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-2-2. BACKLIGHT CONNECTOR PIN CONFIGURATION(CN2)
The LED interface connector is a model SM06B-SHJH(HF) wire-locking type manufactured by JST.
The mating connector is a SHJP-06V-S(HF) or SHJP-06V-A-K(HF) and Equivalent.
The pin configuration for the connector is shown in the table below.
Table 5. LED connector pin configuration
Pin Symbol Description Notes
1 FB1 Channel1 Current Feedback
2 NC No connection
3 VLED LED Power Supply
4 VLED LED Power Supply
5 NC No connection
6 FB2 Channel2 Current Feedback
#1
Rear view of LCM
#6
[ Figure 5 ] Backlight connector view
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-3. LVDS characteristics
3-3-1. DC Specification
Description Symbol Min Max Unit Notes
LVDS Differential Voltage |VID| 200 600 mV -
LVDS Common mode Voltage VCM 0.6 1.8 V -
LVDS Input Voltage Range VIN 0.3 2.1 V -
3-3-2. AC Specification
Tclk
LVDS Clock
LVDS Data
t SKEW (Fclk = 1/Tclk )
1) 85 MHz > Fclk 65 MHz : - 400 ~ +400
t SKEW 2) 65 MHz > Fclk 25 MHz : - 600 ~ +600
< Clock skew margin between channel >
Description Symbol Min Max Unit Notes
tSKEW - 400 + 400 ps 85MHz > Fclk 65MHz
LVDS Clock to Data Skew Margin
tSKEW - 600 + 600 ps 65MHz > Fclk 25MHz
LVDS Clock to Clock Skew Margin
tSKEW_EO - 1/7 + 1/7 Tclk -
(Even to Odd)
Maximum deviation
FDEV - 3 % -
of input clock frequency during SSC
Maximum modulation frequency
FMOD - 200 KHz -
of input clock during SSC
Note :
This SSC specification is based on T-CON operation. According to various system, the
condition for optimum SSC can be varied. We recommend the SSC condition should be
adjusted in order to prevent any kinds of failure symptoms.
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
< Clock skew margin between clock (Even/Odd) >
3-3-3. LVDS Data format
Tclk
Tclk*4/7 Tclk*3/7
RCLK +
Tclk*1/7 MSB R7
R6
-
RXinO0+/ OR3 OR2 OR1 OR0 OG0 OR5 OR4 OR3 OR2 OR1 OR0 OG0 OR5 OR4
R5
RXinO1+/
- OG4 OG3 OG2 OG1 OB1 OB0 OG5 OG4 OG3 OG2 OG1 OB1 OB0 OG5 R4
R3
-
RXinO2+/ OB5 OB4 OB3 OB2 DE VSYNC HSYNC OB5 OB4 OB3 OB2 DE VSYNC HSYNC
R2
RXinO3+/
- OG7 OG6 OR7 OR6 X OB7 OB6 OG7 OG6 OR7 OR6 X OB7 OB6 R1
LSB R0
-
RXinE0+/ ER3 ER2 ER1 ER0 EG0 ER5 ER4 ER3 ER2 ER1 ER0 EG0 ER5 ER4
* ODD = 1 Pixel
st
EG4 EG3 EG2 EG1 EB1 EB0 EG5 EG4 EG3 EG2 EG1 EB1 EB0 EG5 nd
EVEN = 2 Pixel
RXinE1+/
-
-
RXinE2+/ EB5 EB4 EB3 EB2 DE VSYNC HSYNC EB5 EB4 EB3 EB2 DE VSYNC HSYNC
RXinE3+/
- EG7 EG6 ER7 ER6 X EB7 EB6 EG7 EG6 ER7 ER6 X EB7 EB6
Previous(N-
1)th Cycle Current(Nth) Cycle Next(N+1)th Cycle
< LVDS Data Format >
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Table 6. Required signal assignment for Flat Link(NS:DS90CF383) transmitter
Pin # Pin Name Require Signal Pin # Pin Name Require Signal
1 VCC Power Supply for TTL Input 29 GND Ground pin for TTL
2 D5 TTL Input (R7) 30 D26 TTL Input (DE)
3 D6 TTL Input (R5) 31 TX CLKIN TTL Level clock Input
4 D7 TTL Input (G0) 32 PWR DWN Power Down Input
5 GND Ground pin for TTL 33 PLL GND Ground pin for PLL
6 D8 TTL Input (G1) 34 PLL VCC Power Supply for PLL
7 D9 TTL Input (G2) 35 PLL GND Ground pin for PLL
8 D10 TTL Input (G6) 36 LVDS GND Ground pin for LVDS
9 VCC Power Supply for TTL Input 37 TxOUT3 Positive LVDS differential data output 3
10 D11 TTL Input (G7) 38 TxOUT3 Negative LVDS differential data output 3
11 D12 TTL Input (G3) 39 TX CLKOUT Positive LVDS differential clock output
12 D13 TTL Input (G4) 40 TX CLKOUT Negative LVDS differential clock output
13 GND Ground pin for TTL 41 TX OUT2 Positive LVDS differential data output 2
14 D14 TTL Input (G5) 42 TX OUT2 Negative LVDS differential data output 2
15 D15 TTL Input (B0) 43 LVDS GND Ground pin for LVDS
16 D16 TTL Input (B6) 44 LVDS VCC Power Supply for LVDS
17 VCC Power Supply for TTL Input 45 TX OUT1 Positive LVDS differential data output 1
18 D17 TTL Input (B7) 46 TX OUT1 Negative LVDS differential data output 1
19 D18 TTL Input (B1) 47 TX OUT0 Positive LVDS differential data output 0
20 D19 TTL Input (B2) 48 TX OUT0 Negative LVDS differential data output 0
21 GND Ground pin for TTL Input 49 LVDS GND Ground pin for LVDS
22 D20 TTL Input (B3) 50 D27 TTL Input (R6)
23 D21 TTL Input (B4) 51 D0 TTL Input (R0)
24 D22 TTL Input (B5) 52 D1 TTL Input (R1)
25 D23 TTL Input (RSVD) 53 GND Ground pin for TTL
26 VCC Power Supply for TTL Input 54 D2 TTL Input (R2)
27 D24 TTL Input (HSYNC) 55 D3 TTL Input (R3)
28 D25 TTL Input (VSYNC) 56 D4 TTL Input (R4)
Notes : 1. Refer to LVDS Transmitter Data Sheet for detail descriptions.
2. 7 means MSB and 0 means LSB at R,G,B pixel data
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-4. Signal timing specifications
This is the signal timing required at the input of the User connector. All of the interface signal
timing should be satisfied with the following specifications for it's proper operation.
Table 7. Timing table
Parameter Symbol Min. Typ. Max. Unit Notes
Period tCLK 14.8 18.5 22.2 ns Pixel
frequency
DCLK MH
Frequency fCLK 45.0 54.0 67.5 : Typ.108MHz
z
Horizontal Valid tHV 640 640 640
H Period Total tHP 704 844 960 tCLK
Horizontal Blank tHB 64 204 320
Horizontal
Hsync Frequency fH 53.3 64.0 80.0 kHz
Width tWH 16 56 80
Horizontal Back Porch tHBP 32 124 200 tCLK
Horizontal Front Porch tHFP 16 24 40
Vertical Valid tVV 1024 1024 1024
V Period Total tVP 1032 1066 1536 tHP
Vertical Blank tVB 8 42 512
Vertical Vsync Frequency fV 50 60 75 Hz
Width tVVV 2 3 250
Vertical Back Porch tVBP 5 38 250 tHP
Vertical Front Porch tVFP 1 1 12
Note: Hsync period and Hsync width-active should be even number times of tCLK. If the value is odd number
times of tCLK, display control signal can be asynchronous. In order to operate this LCM a Hsync,
Vsyn, and DE(data enable) signals should be used.
1. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rates.
2. Vsync and Hsync should be keep the above specification.
3. Hsync Period, Hsync Width, and Horizontal Back Porch should be any times of of character
number(4).
4. The polarity of Hsync, Vsync is not restricted.
5. The Max frequency of 1280X1024 resolution is 67.5Mhz
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-5. Signal timing waveforms
1. DCLK , DE, DATA waveforms
tCLK
Dclk
tSD tHD Valid
Invalid Invalid
Data
tSI tHI
DE(Data Enable)
2. Horizontal waveform
tHP
tHV
DE(Data Enable) DE
3. Vertical waveform
tVP
tVV
DE(Data Enable) DE
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-6. Color input data reference
The brightness of each primary color (red,green and blue) is based on the 8bit gray scale data
input for the color ; the higher the binary input, the brighter the color. The table below
provides a reference for color versus data input.
Table 8. Color data reference
Input Color Data
Red Green Blue
Color
MSB LSB MSB LSB MSB LSB
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red (255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green (255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Basic Blue (255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Red(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(001) 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(002) 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Red
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Red(253) 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(254) 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(255) Bright 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
Green(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Green
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Green(253) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0
Green(254) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
Green(255)Bright 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Blue(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Blue(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Blue(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Blue
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Blue(253) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1
Blue(254) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
Blue(255) Bright 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-7. Power sequence
90% 90%
VLCD 10% 10%
Power Supply For LCD
0V
T1 T2 T5 T7
Valid data
Interface Signal (Tx)
0V
T3 T4
LED on
Power for LED OFF OFF
Table 9. Power sequence
Values
Parameter Units
Min Typ Max
T1 0.5 - 10 ms
T2 0.01 - 50 ms
T3 500 - - ms
T4 200 - - ms
T5 0.01 - 50 ms
T7 1 - - s
Notes :
1. Please VLCD power on only after connecting interface cable to LCD.
2. Please avoid floating state of interface signal at invalid period.
3. When the interface signal is invalid, be sure to pull down the power supply for
LCD VLCD to 0V.
4. LED power must be turn on after power supply for LCD an interface signal are valid.
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
3-8. VLCD Power dip condition
FIG. 6 Power dip condition
VLCD
4.5V
3.5V
GND(ground)
td
1) Dip condition
3.5V VLCD 4.5V , td 20ms
2) VLCD 3.5V
VLCD-dip conditions should also follow the Power On/Off conditions for supply voltage.
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
4. Optical specification
Optical characteristics are determined after the unit has been `ON' for 30 minutes in a dark
environment at 25 C.
Table 10. Optical characteristics Ta= 25 C, VLCD=5.0V, fV=60Hz fCLK=54.0MHz, IBL=80 mA
Values
Parameter Symbol Units Notes
Min Typ Max
1
Contrast Ratio CR 700 1000 -
(PR-880)
2
Surface Luminance, white LWH 200 250 - cd/m2
(PR-880)
3
Luminance Variation G WHITE 9P 75 - - %
(PR-880)
4
Response Time Gray To Gray TGTG_AVR - 14 28 ms
(RD-80S)
Color Gamut - 72 - % (PR-650)
Rx TBD
RED
Ry TBD
Gx TBD
GREEN
Gy Typ TBD Typ
Color Coordinates
(PR-650)
[CIE1931] -0.03 +0.03
Bx TBD
BLUE
By TBD
Wx 0.313
WHITE
Wy 0.329
Viewing Angle (CR>10)
x axis, right(I=0 ) Tr 85 89 Degree
5
x axis, left (I=180 ) Tl 85 89
(PR-880)
y axis, up (I=90 ) Tu 85 89
y axis, down (I=270 ) Td 85 89
Gray Scale 1.9 2.2 2.5
Luminance uniformity - 6
Angular dependence LR - - 1.73
(TCO 5.1) (PR-880)
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
The values specified are at an approximate distance 50cm from the LCD surface at a viewing
angle of ) and T equal to 0 .
FIG. 7 presents additional information concerning the measurement equipment and method.
FIG. 7 Optical characteristic measurement equipment and method
LCD Module
Optical
Stage(x,y) Pritchard 880
or equivalent
50cm
Notes :
1. Contrast ratio(CR) is defined mathematically as :It is measured at center point(1)
Surface luminance with all white pixels
Contrast ratio = ---------------------------------------------------------
Surface luminance with all black pixels
2. Surface luminance is the luminance value at center 1 point(1) across
the LCD surface 50cm from the surface with all pixels displaying white.
For more information see FIG 8.
3. The variation in surface luminance , G WHITE is defined as
Minimum (P1,P2 .....P9)
G WHITE = --------------------------------------------- *100
Maximum (P1,P2 .....P9)
For more information see Figure 8.
FIG. 8 Luminance measuring point
H H
H/2 H/10 H/2
2 3 4 V/2
V/2
V
V 5 6
1
V/10 7 8 9
Active Area H : 376.320 mm
V : 301.056 mm
@ H,V : Active Area
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Notes :
4. Response time is the time required for the display to transition from black to white
(Decay Time, TrD) and from white to black (Rise Time, TrR)
The sampling rate is 2,500 sample/sec. For additional information see FIG. 9.
The response time is defined as the following figure and shall be measured by
switching the input signal for each gray to gray.
FIG. 9 Response time (measurement equipment : RD-80S)
TrR TrD
100
90
Optical
white black white
response
[%] 10
0
The Gray to Gray response time is defined as the following figure and shall be measured by
switching the input signal for "Gray To Gray ".
- Gray step : 5 Step
- TGTG_AVR is the total average time at rising time and falling time for "Gray To Gray ".
- if system use ODC ( Over Driving Circuit) function, Gray to Gary response time may be
5ms~8ms GtG
* it depends on Overshoot rate.
Table. 11 GTG Gray Table
Rising Time
Gray to Gray
G255 G191 G127 G63 G0
Falling Time G255
G191
G127
G63
G0
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Notes :
5. Viewing angle is the angle at which the contrast ratio is greater than 10 or 5. The angles are
determined for the horizontal or x axis and the vertical or y axis with respect to the z axis
which is normal to the LCD surface. For more information see FIG. 10 .
FIG. 10 Viewing angle
Normal
E Y
I = 90q, Up
I = 180q, Left
T
I
I = 0q, Right
I = 270q, Down
Ver. 0.0 April. 24, 2013
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM190E0C
Liquid Crystal Display
Product Specification
Notes :
6. Luminance Uniformity - angular ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
