Image preview - the first page of the document
![Panel_LG_Display_LM195WD2-SLA1_0_[DS]](/pics/5eafcd276dc30.gif)
>> Download Panel_LG_Display_LM195WD2-SLA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 19.5" HD+ TFT LCD
BUYER SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LM195WD2
SUFFIX SLA1
*When you obtain standard approval,
please use the above model name without suffix
SIGNATUR SIGNATUR
APPROVED BY APPROVED BY
E DATE E DATE
/
B. C. Kim / G. Manager
REVIEWED BY
S. H . Kim /Manager [C]
/
Y. H. Hwang /Manager [M]
M. S. Kang /Manager [P]
REPARED BY
/
T. K. Kim / Engineer
Please return 1 copy for your confirmation IT/Mobile Development Division 1
with your signature and comments. LG Display Co. Ltd
Ver. 0.0 Dec. 21. 2012 1 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
1) ELECTRICAL CHARACTERISTICS 6
2) INTERFACE CONNECTIONS 8
3) LVDS characteristics 11
4) SIGNAL TIMING SPECIFICATIONS 14
5) SIGNAL TIMING WAVEFORMS 15
6) COLOR INPUT DATA REFERNECE 16
7) POWER SEQUENCE 18
8) POWER DIP CONDITION 19
4 OPTICAL SFECIFICATIONS 19
5 MECHANICAL CHARACTERISTICS 25
6 RELIABILITY 28
7 INTERNATIONAL STANDARDS 29
1) SAFETY 29
2) EMC 29
3) ENVIRONMENT 29
8 PACKING 30
1) DESIGNATION OF LOT MARK 30
2) PACKING FORM 30
9 PRECAUTIONS 31
1) MOUNTING PRECAUTIONS 31
2) OPERATING PRECAUTIONS 31
3) ELECTROSTATIC DISCHARGE CONTROL 32
4) PRECAUTIONS FOR STRONG LIGHT EXPOSURE 32
5) STROAGE 32
6) HANDLING PRECAUTIONS FOR PROTECTION FILM 32
Ver. 0.0 Dec. 21. 2012 2 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
Record of revisions
Revision Revision
Page Description
No Date
0.0 Dec. 21. 2012 - First Draft (Preliminary)
Ver. 0.0 Dec. 21. 2012 3 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
1. General description
LM195WD2-SLA1 is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting
Diode(LED) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 19.5 inch diagonally
measured active display area with HD+ resolution (900 vertical by 1600 horizontal pixel array)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with
a 8-bit gray scale signal for each dot, thus, presenting a palette of more than 16.7M colors with
Advanced-FRC(Frame Rate Control). It has been designed to apply the interface method that
enables low power, high speed, low EMI. FPD Link or compatible must be used as a LVDS(Low
Voltage Differential Signaling) chip. It is intended to support applications where thin thickness,
wide viewing angle, low power are critical factors and graphic displays are important. In
combination with the vertical arrangement of the sub-pixels, the LM195WD2-SLA1 characteristics
provide an excellent flat panel display for office automation products such as monitors.
RGB
FIG. 1 Block diagram
Source driver circuit
S1 S1600
LVDS G1
pair #1 Timing
LVDS
controller
pair #2 TFT-LCD Panel
(1600 RGB 900 pixels)
CN1
G900
+5V Power circuit
VLCD block
VLED 2ch Backlight assembly (White LED)
General features
Active screen size 19.5 inches (494.11mm) diagonal
Outline Dimension 452.0(H) x 263.0(V) x 10.5(D) mm(Typ.)
Pixel Pitch 0.2712*RGB(H)mm x 0.2626(V)mm
Pixel Format 1600 horizontal By 900 vertical Pixels. RGB stripe arrangement
Interface LVDS 2Port
Color depth 16.7M colors
Luminance, white 250 cd/m2 (Center 1Point, typ)
Viewing Angle (CR>10) R/L 178(Typ.), U/D 178(Typ.)
Power Consumption Total TBD W(Typ.), (TBD W@VLCD , TBD W@IBL = 120 mA)
Weight TBD g (Typ.)
Display operating mode Transmissive mode, normally Black
Surface treatments Hard coating (3H), Anti-glare treatment of the front polarizer
Ver. 0.0 Dec. 21. 2012 4 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
2. Absolute maximum ratings
The following are maximum values which, if exceeded,
may cause faulty operation or damage to the unit.
Table 1. Absolute maximum ratings
Values
Parameter Symbol Units Notes
Min Max
Power Supply Input Voltage VLCD -0.3 +6.0 Vdc At 25
Operating Temperature TOP 0 50 C
Storage Temperature TST -20 60 C
1,2,3
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
LCM Surface Temperature
TSurface 0 65 1, 4
(Operation)
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
2. Maximum Storage Humidity is up to 40 , 90% RH only for 4 corner light leakage Mura.
3. Storage condition is guaranteed under packing condition.
4. LCM Surface Temperature should be Min. 0 and Max. 65 under the VLCD=5.0V,
fV=60Hz, 25 ambient Temp. no humidity control and LED string current is typical value.
FIG. 2 Temperature and relative humidity
90%
60
60%
50 Storage
Wet Bulb
Temperature [ ]
Humidity
[(%)RH]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 0.0 Dec. 21. 2012 5 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3. Electrical specifications
3-1. Electrical characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input power for the LED/Backlight, is typically
generated by an LED Driver. The LED driver is an external unit to the LCDs.
Table 2. Electrical characteristics
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.4 V 2
ILCD-MOSAIC - TBD TBD mA 1,3
Power Supply Input Current ILCD-white - TBD TBD mA 1,4
ILCD-L80 - TBD TBD mA 1
Power Consumption PLCD - TBD TBD Watt 1,3
Inrush current IRUSH - - 3.0 A 1,5
Note :
1. The specified characteristics perform under the VLCD=5.0V, 25 r 2 C, fV=60Hz condition.
fV is the frame frequency.
2. Permissive Power Ripple should be measured under VLCD=5.0V, 25 r 2 C,
fV =75Hz condition and At that time,
we recommend the bandwidth configuration of oscilloscope is to be under 20MHz. (See FIG.3)
3. Mosaic pattern(8 x 6) is displayed.
4. Input current is specified at the maximum current pattern.
5. The duration of Inrush current is about 5ms and rising time of power Input is 500us r 20%.
FIG.3 pattern for Electrical characteristics
power consumption power input ripple Energy star 5.0
White : 255Gray White : 255Gray (80%)
Black : 0Gray Black : 0Gray (20%)
Mosaic Pattern(8 x 6) Full White Pattern L80 Pattern
Ver. 0.0 Dec. 21. 2012 6 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
Table 3. LED array ELECTRICAL CHARACTERISTICS
Values Note
Parameter Symbol Condition Unit
Min. Typ. Max. s
LED String Current Is - 120 125 mA 1,2,5
LED String Voltage Vs TBD (37.2) TBD V 1,5
Power - (8.9) TBD Watt 1,2,4
PBar
Consumption
LED Life Time LED_LT 30,000 - - Hrs 3
Notes) The LED Bar consists of 24 LED packages, 2 strings (parallel) x 12 packages (serial)
LED driver design guide
: The design of the LED driver must have specifications for the LED in LCD Assembly.
The performance of the LED in LCM, for example life time or brightness, is extremely
influenced by the characteristics of the LED driver.
So all the parameters of an LED driver should be carefully designed and output current
should be Constant current control.
Please control feedback current of each string individually to compensate the current
variation among the strings of LEDs.
When you design or order the LED driver, please make sure unwanted lighting caused by
the mismatch of the LED and the LED driver (no lighting, flicker, etc) never occurs.
When you confirm it, the LCD module should be operated in the same condition as
installed in your instrument.
Notes :
1. The specified values are for a single LED bar.
2. The specified current is defined as the input current for a single LED string with 100% duty cycle.
3. The LED life time is defined as the time when brightness of LED packages become 50% or less
than the initial value under the conditions at Ta = 25 r 2 C and LED string current is typical value.
4. The power consumption shown above does not include loss of external driver.
The typical power consumption is calculated as PBar = Vs(Typ.) x Is(Typ.) x No. of strings.
The maximum power consumption is calculated as PBar = Vs(Max.) x Is(Typ.) x No. of strings.
5. LED operating conditions must not exceed Max. ratings.
Ver. 0.0 Dec. 21. 2012 7 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-2. Interface connections
3-2-1. LCD Module
LCD connector(CN1) : GT103-30S-HF15-E2500 (LSM) , UJU(IS100-L30O-C23)
Mating connector : FI-X30H and FI-X30HL (JAE) or Equivalent
Table 4. Module connector(CN1) pin configuration
Pin No Symbol Description
1 RXO0- Minus signal of 1st channel 0 (LVDS)
2 RXO0+ Plus signal of 1st channel 0 (LVDS)
3 RXO1- Minus signal of 1st channel 1 (LVDS)
4 RXO1+ Plus signal of 1st channel 1 (LVDS)
5 RXO2- Minus signal of 1st channel 2 (LVDS)
6 RXO2+ Plus signal of 1st channel 2 (LVDS)
7 GND Ground(AGP)
8 RXOC- Minus signal of 1st clock channel (LVDS)
9 RXOC+ Plus signal of 1st clock channel (LVDS)
10 RXO3- Minus signal of 1st channel 3 (LVDS)
11 RXO3+ Plus signal of 1st channel 3 (LVDS)
12 RXE0- Minus signal of 2nd channel 0 (LVDS)
13 RXE0+ Plus signal of 2nd channel 0 (LVDS)
14 GND Ground
15 RXE1- Minus signal of 2nd channel 1 (LVDS)
16 RXE1+ Plus signal of 2nd channel 1 (LVDS)
17 GND Ground
18 RXE2- Minus signal of 2nd channel 2 (LVDS)
19 RXE2+ Plus signal of 2nd channel 2 (LVDS)
20 RXEC- Minus signal of 2nd clock channel (LVDS)
21 RXEC+ Plus signal of 2nd clock channel (LVDS)
22 RXE3- Minus signal of 2nd channel 3 (LVDS)
23 RXE3+ Plus signal of 2nd channel 3 (LVDS)
24 GND Ground
25 NC No Connection (For LCD internal use only.)
26 NC No Connection (For LCD internal use only.)
27 PWM_OUT Reference signal for inverter control
28 VLCD Power Supply (5.0V)
29 VLCD Power Supply (5.0V)
30 VLCD Power Supply (5.0V)
Ver. 0.0 Dec. 21. 2012 8 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
FIG. 4 Connector diagram
IS100-L300-C23(UJU)
#
#30
#11 #30
1'st signal pairs
2'nd signal pairs
Power(+5V)
PWM_OUT
Rear view of LCM
Note:
1. NC: No Connection.
2. All GND(ground) pins should be connected together and to Vss which should also
be connected to the LCD's metal frame.
3. All VLCD (power input) pins should be connected together.
4. Input Level of LVDS signal is based on the IEA 664 Standard.
5. PWM_OUT is a reference signal for inverter control.
This PWM signal is synchronized with vertical frequency.
Its frequency is 5 times of vertical frequency, and its duty ratio is 50%.
If the system don't use this pin, do not connect.
Ver. 0.0 Dec. 21. 2012 9 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-2-2. LED Interface
The LED interface connector is a model GT108-6P-H26-E3500, wire-locking type manufactured by LSM.
The mating connector is a SHJP-06V-S(HF) or SHJP-06V-A-K(HF) and Equivalent.
The pin configuration for the connector is shown in the table below.
Table 5. BACKLIGHT CONNECTOR PIN CONFIGURATION(CN2)
Pin Symbol Description Notes
1 FB1 Channel1 Current Feedback
2 NC No connection
3 VLED LED Power Supply
4 VLED LED Power Supply
5 NC No connection
6 FB2 Channel2 Current Feedback
FIG. 5 Backlight connector view
#1
Rear view of LCM
#6
Ver. 0.0 Dec. 21. 2012 10 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-3. LVDS characteristics
3-3-1. LVDS Data format
Tclk
Tclk*4/7 Tclk*3/7
RCLK +
Tclk*1/7 MSB R7
R6
-
RXinO0+/ OR3 OR2 OR1 OR0 OG0 OR5 OR4 OR3 OR2 OR1 OR0 OG0 OR5 OR4
R5
RXinO1+/
- OG4 OG3 OG2 OG1 OB1 OB0 OG5 OG4 OG3 OG2 OG1 OB1 OB0 OG5 R4
R3
-
RXinO2+/ OB5 OB4 OB3 OB2 DE VSYNC HSYNC OB5 OB4 OB3 OB2 DE VSYNC HSYNC
R2
RXinO3+/
- OG7 OG6 OR7 OR6 X OB7 OB6 OG7 OG6 OR7 OR6 X OB7 OB6 R1
LSB R0
-
RXinE0+/ ER3 ER2 ER1 ER0 EG0 ER5 ER4 ER3 ER2 ER1 ER0 EG0 ER5 ER4
* ODD = 1 Pixel
st
EG4 EG3 EG2 EG1 EB1 EB0 EG5 EG4 EG3 EG2 EG1 EB1 EB0 EG5 nd
EVEN = 2 Pixel
RXinE1+/
-
-
RXinE2+/ EB5 EB4 EB3 EB2 DE VSYNC HSYNC EB5 EB4 EB3 EB2 DE VSYNC HSYNC
-
RXinE3+/ EG7 EG6 ER7 ER6 X EB7 EB6 EG7 EG6 ER7 ER6 X EB7 EB6
Previous(N-
1)th Cycle Current(Nth) Cycle Next(N+1)th Cycle
< LVDS Data Format >
3-3-2. DC Specification
Description Symbol Min Max Unit Notes
LVDS Differential Voltage |VID| 200 600 mV -
LVDS Common mode Voltage VCM 0.6 1.5 V -
LVDS Input Voltage Range VIN 0.3 1.8 V -
Ver. 0.0 Dec. 21. 2012 11 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-3-3. AC Specification
Tclk
LVDS Clock
LVDS Data
t SKEW (Fclk = 1/Tclk )
1) 85 MHz > Fclk 65 MHz : - 400 ~ +400
t SKEW 2) 65 MHz > Fclk 25 MHz : - 600 ~ +600
< Clock skew margin between channel >
t SKEW EO
_
LVDS Odd Clock
T clk
LVDS Even Clock
T clk
LVDS Even Data
< Clock skew margin between clock (Even/Odd) >
Description Symbol Min Max Unit Notes
85MHz > Fclk
tSKEW - 400 + 400 ps
65MHz
LVDS Clock to Data Skew Margin
65MHz > Fclk
tSKEW - 600 + 600 ps
25MHz
Maximum deviation
FDEV - 3 % 1
of input clock frequency during SSC
LVDS Clock to Clock Skew Margin
tSKEW_EO - 1/7 + 1/7 Tclk -
(Even to Odd)
Note 1 :
This SSC specifications are just T-CON operation specification. In case of various system
condition, the optimum setting value of SSC can be different. LGD recommend the SI
should be adjust the SSC deviation and modulation frequency in order not to happen any
kinds of defect phenomenon.
Ver. 0.0 Dec. 21. 2012 12 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
Table 6. Required signal assignment for Flat Link(NS:DS90CF383) transmitter
Pin # Pin Name Require Signal Pin # Pin Name Require Signal
1 VCC Power Supply for TTL Input 29 GND Ground pin for TTL
2 D5 TTL Input (R7) 30 D26 TTL Input (DE)
3 D6 TTL Input (R5) 31 TX CLKIN TTL Level clock Input
4 D7 TTL Input (G0) 32 PWR DWN Power Down Input
5 GND Ground pin for TTL 33 PLL GND Ground pin for PLL
6 D8 TTL Input (G1) 34 PLL VCC Power Supply for PLL
7 D9 TTL Input (G2) 35 PLL GND Ground pin for PLL
8 D10 TTL Input (G6) 36 LVDS GND Ground pin for LVDS
9 VCC Power Supply for TTL Input 37 TxOUT3 Positive LVDS differential data output 3
10 D11 TTL Input (G7) 38 TxOUT3 Negative LVDS differential data output 3
11 D12 TTL Input (G3) 39 TX CLKOUT Positive LVDS differential clock output
12 D13 TTL Input (G4) 40 TX CLKOUT Negative LVDS differential clock output
13 GND Ground pin for TTL 41 TX OUT2 Positive LVDS differential data output 2
14 D14 TTL Input (G5) 42 TX OUT2 Negative LVDS differential data output 2
15 D15 TTL Input (B0) 43 LVDS GND Ground pin for LVDS
16 D16 TTL Input (B6) 44 LVDS VCC Power Supply for LVDS
17 VCC Power Supply for TTL Input 45 TX OUT1 Positive LVDS differential data output 1
18 D17 TTL Input (B7) 46 TX OUT1 Negative LVDS differential data output 1
19 D18 TTL Input (B1) 47 TX OUT0 Positive LVDS differential data output 0
20 D19 TTL Input (B2) 48 TX OUT0 Negative LVDS differential data output 0
21 GND Ground pin for TTL Input 49 LVDS GND Ground pin for LVDS
22 D20 TTL Input (B3) 50 D27 TTL Input (R6)
23 D21 TTL Input (B4) 51 D0 TTL Input (R0)
24 D22 TTL Input (B5) 52 D1 TTL Input (R1)
25 D23 TTL Input (RSVD) 53 GND Ground pin for TTL
26 VCC Power Supply for TTL Input 54 D2 TTL Input (R2)
27 D24 TTL Input (HSYNC) 55 D3 TTL Input (R3)
28 D25 TTL Input (VSYNC) 56 D4 TTL Input (R4)
Notes : Refer to LVDS Transmitter Data Sheet for detail descriptions.
Ver. 0.0 Dec. 21. 2012 13 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-4. Signal timing specifications
This is the signal timing required at the input of the User connector. All of the interface signal
timing should be satisfied with the following specifications for it's proper operation.
Table 7. Timing table
Parameter Symbol Min. Typ. Max. Unit Notes
Period tCLK 14.6 18.5 23.1 ns Pixel frequency
DCLK : Typ.108.0MHz
Frequency fCLK 43.2 54.0 68.4 MHz
Horizontal Valid tHV 800 800 800
Horizontal tCLK
H Period Total tHP 856 900 1200
Hsync Frequency fH 48.0 60.0 76.0 kHz
Vertical Valid tVV 900 900 900
tHP
Vertical V Period Total tVP 908 1000 1300
Vsync Frequency fV 48 60 76 Hz
Note:
1. DE Only mode operation. The input of Hsync & Vsync signal does not
have an effect on LCD normal operation.
2. The performance of the electro-optical characteristics may be influenced by variance of the
vertical refresh rates.
3. Horizontal period should be even.
4. Hsync Period, Hsync Width, and Horizontal Back Porch should be any times of of character
number(4).
Ver. 0.0 Dec. 21. 2012 14 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-5. Signal timing waveforms
1. DCLK , DE, DATA waveforms
tCLK
Dclk
tSD tHD Valid
Invalid Invalid
Data
tSI tHI
DE(Data Enable)
2. Horizontal waveform
tHP
tHV
DE(Data Enable) DE
3. Vertical waveform
tVP
tVV
DE(Data Enable) DE
Ver. 0.0 Dec. 21. 2012 15 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-6. Color input data reference
The brightness of each primary color (red,green and blue) is based on the 8bit gray scale data
input for the color, the higher the binary input, the brighter the color. The table below
provides a reference for color versus data input.
Table 8. Color data reference
Input Color Data
Red Green Blue
Color
MSB LSB MSB LSB MSB LSB
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red (255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green (255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Basic Blue (255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Red(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(001) 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(002) 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Red
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Red(253) 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(254) 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(255) Bright 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
Green(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Green
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Green(253) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0
Green(254) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
Green(255)Bright 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Blue(000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Blue(001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Blue(002) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Blue
--------- - - - - - - - - - - - - - - - - - - - - - - - -
Blue(253) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1
Blue(254) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
Blue(255) Bright 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Ver. 0.0 Dec. 21. 2012 16 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-7. Power sequence
90% 90%
VLCD 10% 10%
Power Supply For LCD
T1 T2 T5 T7
Valid data
Interface Signal (Tx)
0V
T3 T4
LED on
Power for Backlight OFF OFF
Table 9. Power sequence
Values
Parameter Units
Min Typ Max
T1 0.5 - 10 ms
T2 0.01 - 50 ms
T3 500 - - ms
T4 200 - - ms
T5 0.01 - 50 ms
T7 1 - - s
Notes :
1. Please avoid floating state of interface signal at invalid period.
2. When the interface signal is invalid, be sure to pull down the power supply for
LCD VLCD to 0V.
3. LED power must be turn on after power supply for LCD an interface signal are valid.
Ver. 0.0 Dec. 21. 2012 17 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
3-8. VLCD Power dip condition
FIG. 6 Power dip condition
VLCD
4.5V
3.5V
GND(ground)
td
1) Dip condition
3.5V VLCD 4.5V , td 20ms
2) VLCD 3.5V
VLCD-dip conditions should also follow the Power On/Off conditions for supply voltage.
Ver. 0.0 Dec. 21. 2012 18 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
4. Optical specification
Optical characteristics are determined after the unit has been `ON' for 30 minutes in a dark
environment at 25 C.
Table 10. Optical characteristics Ta= 25 C, VLCD=5.0V, fV=60Hz fCLK=54MHz, IBL=120mA
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR 700 1000 1
Surface Luminance, white LWH 200 250 cd/m2 2
Luminance Variation G WHITE 75 % 3
Response Time Gray to Gray TGTG_AVR - 14 25 ms 4
RED Rx TBD
Ry TBD
GREEN Gx TBD
Color Coordinates Gy TBD
Typ Typ
[CIE1931]
BLUE Bx -0.03 TBD +0.03
(By PR650)
By TBD
WHITE Wx 0.313
Wy 0.329
Horizontal TCST_H - TBD -
Color Shift
Degree 5
(Avg. u'v' < 0.02)
Vertical TCST_V - TBD -
Viewing Angle (CR>10)
Horizontal TH 170 178 -
General Degree 6
Vertical TV 170 178 -
Horizontal GGamma_H - - 20
GSR @ 60dgree
% 7
(Gamma shift rate)
Vertical GGamma_V - - 20
Gray Scale 2.2 8
Ver. 0.0 Dec. 21. 2012 19 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM195WD2
Liquid Crystal Display
Product Specification
Notes 1. Contrast Ratio(CR) is defined mathematically as : (By PR880)
Surface Luminance with all white pixels
Contrast Ratio
Surface Luminance with all black pixels
It is measured at center point(Location P1)
2. Surface luminance(LWH)is luminance value at Center 1 point(P1) across the LCD surface 50cm
from the surface with all pixels displaying white. For more information see FIG 7. (By PR880)
3. The variation in surface luminance , G WHITE is defined as : (By PR880)
Minimum(L P1 , L P2 , }.. L P9 )
GWHITE u 100
Maximum (L P1 , L P2 , .... L P9 )
Where L1 to L9 are the luminance with all pixels displaying white at 9 locations.
For more information see FIG 8.
4. Gray to gray response time is the time required for the display to transition from gray to gray. For
additional information see Table 10. (By RD80S)
5. Color shift is the angle at which the average color difference for all Macbeth is lower than 0.02.
For more information see FIG 9. (By EZ Contrast)
- Color difference ( u'v')
4x 9y
u' v' 'u ' v' (u '1 u '2 ) 2 (v'1 v'2 ) 2
2 x 12 y 3 2 x 12 y 3
24
u'1, v'1 : u'v' value at viewing angle direction
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
