Image preview - the first page of the document
![Panel_LG_Display_LM200WD1-TLD2_0_[DS]](/pics/5eafcd386d07b.gif)
>> Download Panel_LG_Display_LM200WD1-TLD2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 20.0" HD+ TFT LCD
BUYER HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LM200WD1
SUFFIX TLD2
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE DATE APPROVED BY DATE
S.G. Hong / G.Manager
/
REVIEWED BY
D.G. Kim / Manager [C]
/ K.H. Moon / Manager [M]
D.Y. Seok / Manager [P]
PREPARED BY
/
S.J. Yeom / Engineer
Please return 1 copy for your confirmation Product Engineering Dept.
With your signature and comments. LG Display Co., Ltd
Ver.0.2 Jan., 21, 2010 1 / 33
PDF created with pdfFactory trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
1) ELECTRICAL CHARACTERISTICS 6
2) INTERFACE CONNECTIONS 9
3) LVDS characteristics 12
4) SIGNAL TIMING SPECIFICATIONS 15
5) SIGNAL TIMING WAVEFORMS 16
6) COLOR INPUT DATA REFERNECE 17
7) POWER SEQUENCE 18
8) POWER DIP CONDITION 19
4 OPTICAL SFECIFICATIONS 20
5 MECHANICAL CHARACTERISTICS 26
6 RELIABILITY 29
7 INTERNATIONAL STANDARDS 30
1) SAFETY 30
2) EMC 30
3) ENVIRONMENT 30
8 PACKING 31
1) DESIGNATION OF LOT MARK 31
2) PACKING FORM 31
9 PRECAUTIONS 32
1) MOUNTING PRECAUTIONS 32
2) OPERATING PRECAUTIONS 32
3) ELECTROSTATIC DISCHARGE CONTROL 33
4) PRECAUTIONS FOR STRONG LIGHT EXPOSURE 33
5) STROAGE 33
6) HANDLING PRECAUTIONS FOR PROTECTION FILM 33
Ver.0.2 Jan., 21, 2010 2 / 33
PDF created with pdfFactory trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
Record of revisions
Revision No Date Page Description
Ver.0.1 Dec.,04,2009 Preliminary Specifications.
Ver.0.2 Jan.,21,2010 Change the weight
4,26 (1,580g 1,650g)
22,23 Updating the 2D drawings.
Ver.0.2 Jan., 21, 2010 3 / 33
PDF created with pdfFactory trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
1. General description
LM200WD1-TLD2 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode
Fluorescent Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the
active element. It is a transmissive type display operating in the normally white mode. It has a
20.0 inch diagonally measured active display area with HD+ resolution (900 vertical by 1600
horizontal pixel array) Each pixel is divided into Red, Green and Blue sub-pixels or dots which are
arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with
a 8-bit gray scale signal for each dot, thus, presenting a palette of more than 16.7M colors with
Advanced-FRC(Frame Rate Control). It has been designed to apply the interface method that
enables low power, high speed, low EMI. FPD Link or compatible must be used as a LVDS(Low
Voltage Differential Signaling) chip. It is intended to support applications where thin thickness,
wide viewing angle, low power are critical factors and graphic displays are important. In
combination with the vertical arrangement of the sub-pixels, the LM200WD1-TLD2 characteristics
provide an excellent flat panel display for office automation products such as monitors.
RGB
FIG. 1 Block diagram
Source driver circuit
S1 S1600
LVDS G1
pair #1 Timing
LVDS
controller
pair #2 TFT-LCD Panel
(1600 RGB 900 pixels)
CN1
G900
+5V Power circuit
VLCD block
CN2, (2pin)
Backlight assembly (2 CCFLs)
CN3 (2pin)
General features
Active screen size 20.0 inches (508.05mm) diagonal
Outline Dimension 462.8(H) x 272.0(V) x 14.5(D) mm(Typ.)
Pixel Pitch 0.0922*RGB(H)mm x 0.2766(V)mm
Pixel Format 1600 horizontal By 900 vertical Pixels. RGB stripe arrangement
Interface LVDS 2Port
Color depth 16.7M colors
Luminance, white 250 cd/m2 ( Center 1Point, typ)
Viewing Angle (CR>10) R/L 170(Typ.), U/D 160(Typ.)
Power Consumption Total 16.25 W(Typ.), (4.75 W@VLCD , 11.5 W@IBL = 8.5mA)
Weight 1,650 g (Typ.)
Display operating mode Transmissive mode, normally White
Surface treatments Hard coating (3H), Anti-glare treatment of the front polarizer
Ver.0.2 Jan., 21, 2010 4 / 33
PDF created with pdfFactory trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
2. Absolute maximum ratings
The following are maximum values which, if exceeded,
may cause faulty operation or damage to the unit.
Table 1. Absolute maximum ratings
Values
Parameter Symbol Units Notes
Min Max
Power Supply Input Voltage VLCD -0.3 +6.0 Vdc At 25
Operating Temperature TOP 0 50 C
Storage Temperature TST -20 60 C
1
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
FIG. 2 Temperature and relative humidity
90%
60
60%
50 Storage
Wet Bulb
Temperature [ ]
Humidity
[(%)RH]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver.0.2 Jan., 21, 2010 5 / 33
PDF created with pdfFactory trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM200WD1
Liquid Crystal Display
Product Specification
3. Electrical specifications
3-1. Electrical characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input power for the CCFL/Backlight, is typically
generated by an inverter. The inverter is an external unit to the LCDs.
Table 2. Electrical characteristics
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.2 V 3
ILCD-MOSAIC - 950 1235 mA 1
Power Supply Input Current ILCD-BLACK - 1155 1500 mA 2
ILCD-L80 - 850 1105 mA 2
Power Consumption PLCD - 4.75 6.18 Watt 1
Inrush current IRUSH - - 3.0 A 3
Note :
1. The specified current and power consumption are
under the VLCD=5.0V, 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
