Image preview - the first page of the document
![Panel_LG_Display_LM201WE3-TLF8_0_[DS]](/pics/5eafce0ee6db2.gif)
>> Download Panel_LG_Display_LM201WE3-TLF8_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 20.1" WSXGA+ TFT LCD
BUYER Apple SUPPLIER LG. Display Co., Ltd.
MODEL *MODEL LM201WE3
SUFFIX TLF8
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ Hans. Kim / G. Manager
REVIEWED BY
/ Tomi. Jung / Manager
PREPARED BY
/ S.H. Kim / Engineer
Please return 1 copy for your confirmation with MNT Products Engineering Dept.
your signature and comments. LG. Display Co., Ltd
Ver. 1.0 Dec. 03. 2008 1 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 9
3-3 SIGNAL TIMING SPECIFICATIONS 13
3-4 SIGNAL TIMING WAVEFORMS 14
3-5 COLOR INPUT DATA REFERNECE 15
3-6 POWER SEQUENCE 16
4 OPTICAL SFECIFICATIONS 17
5 MECHANICAL CHARACTERISTICS 22
6 RELIABILITY 25
7 INTERNATIONAL STANDARDS 26
7-1 SAFETY 26
7-2 EMC 26
8 PACKING 27
8-1 DESIGNATION OF LOT MARK 27
8-2 PACKING FORM 27
9 PRECAUTIONS 28
10 EDID DATA FOR LM201WE3-TLF7 30
Ver. 1.0 Dec. 03. 2008 2 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
Revision No Revision Date Page DESCRIPTION
0.0 Oct. 15. 2008 - Preliminary Specification of LM201WE3-TLF8
1.0 Dec. 03. 2008 - Final Specification of LM201WE3-TLF8
Ver. 1.0 Dec. 03. 2008 3 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
1. General Description
LM201WE3 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally white mode. It has a 20.1 inch diagonally measured
active display area with WSXGA+ resolution (1050 vertical by 1680 horizontal pixel array)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus, presenting a palette of more than 16,7M colors with A-FRC(Advanced Frame Rate Control).
It has been designed to apply the 8Bit 2 port LVDS interface.
It is intended to support displays where high brightness, super wide viewing angle,
high color saturation, and high color are important.
Source Driver Circuit
RGB, Dclk, DE Timing Control
Hsync, Vsync CN1 S1 S1680
Block
(LVDS 2 port) (30pin)
G1
Gate Driver circuit
VLCD(+5V)
TFT-LCD Panel
Power Circuit Block (1680 u 1050 pixels)
G105
0
VLamp
CN2(2PIN), 3(2PIN)
VLamp Backlight Assembly(4 CCFL)
CN4(2PIN), 5(2PIN)
General Features
Active Screen Size 20.1 inches(511.133mm) diagonal (Aspect ratio 16:10)
Outline Dimension 459.4(H) x 296.4 (V) x 14.5(D) mm (Typ.)
Pixel Pitch 0.258mm x 0.258mm
Pixel Format 1680 horiz. By 1050 vert. Pixels RGB strip arrangement
Color Depth 16.7 M colors
Luminance, White 300 cd/m2 (5 points Avg.)
Viewing Angle (CR>10) Viewing Angle Free ( R/L 160(Typ.), U/D 160(Typ) )
Power Consumption Total 25.21 Watt(Typ.) (3.91 Watt@VLCD, 21.3 Watt@300cd/[LAMP=7.0mA])
Weight 2050 g (Typ.)
Display Operating Mode Transmissive mode, Normally White
Surface Treatment Hard coating (2H), Glare treatment of the front polarizer
Ver. 1.0 Dec. 03. 2008 4 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VLCD -0.3 +5.5 Vdc r
Operating Temperature TOP 0 50 C 1
Storage Temperature TST -20 60 C 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
Ver. 1.0 Dec. 03. 2008 5 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and
liquid crystal. The second input power for the CCFL, is typically generated by an inverter. The inverter is an
external unit to the LCDs.
Table 2_1. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
- 781 899 mA 1
Power Supply Input Current ILCD
- 976 1269 mA 2
Power Consumption PLCD - 3.91 4.50 Watt 1
Rush current IRUSH - - 3 A 3
Note :
1. The specified current and power consumption are under the VLCD=5.0V, 25 r 2 C,fV=60Hz condition
whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current is specified at the maximum current pattern.
3. The duration of rush current is about 2ms and rising time of power Input is 500us r 20%.(min.).
White : 255Gray Maximum current pattern
Black : 0Gray
Mosaic Pattern(8 x 6) Black Pattern
Ver. 1.0 Dec. 03. 2008 6 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
Table 2_2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
LAMP :
Operating Voltage VBL 725(8.0mA) 760(7.0mA) 920(2.5mA) VRMS 1, 2
Operating Current IBL 2.5 7.0 8.0 mARMS 1
Established Starting Voltage Vs 1, 3
at 25 C 1250 VRMS
at 0 C 1550 VRMS
Operating Frequency fBL 40 60 70 kHz 4
Discharge Stabilization Time Ts 3 Min 1, 5
Power Consumption PBL 21.3 23.43 Watt 6
Life Time 50,000 Hrs 1, 7
Note : The design of the inverter must have specifications for the lamp in LCD Assembly.
The performance of the Lamp in LCM, for example life time or brightness, is extremely influenced by
the characteristics of the DC-AC inverter. So all the parameters of an inverter should be carefully
designed so as not to produce too much leakage current from high-voltage output of the inverter.
When you design or order the inverter, please make sure unwanted lighting caused by the mismatch
