Image preview - the first page of the document
![Panel_LG_Display_LM201WE3-TLK3_0_[DS]](/pics/5eafce2f5e234.gif)
>> Download Panel_LG_Display_LM201WE3-TLK3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 20.1" WSXGA+ TFT LCD
BUYER SUPPLIER LG. Display LCD Co., Ltd.
MODEL *MODEL LM201WE3
SUFFIX TLK3
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ Hans. Kim / G.Manager
REVIEWED BY
C. K. LEE / Manager [C]
/ J. H. LEE / Manager [M]
Y. S. Lee / Manager [P]
PREPARED BY
/
J.H. Oh / Engineer
Please return 1 copy for your confirmation with MNT Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 1.0 Sep. 17. 2008 1 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 9
3-3 SIGNAL TIMING SPECIFICATIONS 16
3-4 SIGNAL TIMING WAVEFORMS 17
3-5 COLOR INPUT DATA REFERNECE 18
3-6 POWER SEQUENCE 19
3-7 VCC POWER DIP CONDITION 20
4 OPTICAL SFECIFICATIONS 21
5 MECHANICAL CHARACTERISTICS 25
6 RELIABILITY 28
7 INTERNATIONAL STANDARDS 29
7-1 SAFETY 29
7-2 EMC 29
7-3 ENVIRONMENT 29
8 PACKING 30
8-1 DESIGNATION OF LOT MARK 30
8-2 PACKING FORM 30
9 PRECAUTIONS 31
Ver. 1.0 Sep. 17. 2008 2 / 32
From www.fpdclub.net
www fpdclub net
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
Revision No Revision Date Page DESCRIPTION
1.0 Sep. 04. 2008 - Final Specification of LM201WE3-TLK3
Ver. 1.0 Sep. 17. 2008 3 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
1. General Description
LM201WE3 is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally White mode. It has a 20.1 inch diagonally
measured active display area with WSXGA+ resolution (1050 vertical by 1680 horizontal pixel array)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus, presenting a palette of more than 16,7M colors with A-FRC(Advanced Frame Rate Control).
It has been designed to apply the 8Bit 2 port LVDS interface.
It is intended to support displays where high brightness, super wide viewing angle,
high color saturation, and high color are important.
Source Driver Circuit
RGB, Dclk, DE Timing Control
Hsync, Vsync S1 S1680
CN1 Block
(LVDS 2 port) (30pin)
Gate Driver circuit G1
VLCD(+5V)
TFT-LCD Panel
Power Circuit Block (1680 u 1050 pixels)
G1050
VLamp
CN2, 3(2PIN)
VLamp Backlight Assembly(4 CCFL)
CN4, 5(2PIN)
Figure 1. Block diagram
General Features
Active Screen Size 20.1 inches(511.133mm) diagonal (Aspect ratio 16:10)
Outline Dimension 459.4(H) x 296.4 (V) x 16.5(D) mm (Typ.)
Pixel Pitch 0.258mm x 0.258mm
Pixel Format 1680 horiz. By 1050 vert. Pixels RGB strip arrangement
Color Depth 16,7 M colors
Luminance, White 300 cd/m2 (Center 1 point, Typ.)
Viewing Angle (CR>10) Viewing Angle Free ( R/L 170(Typ.), U/D 160(Typ) )
Power Consumption Total 26.98 Watt(Typ.) (4.78 Watt@VLCD, 22.2 Watt@300cd/[LAMP=(7.5mA)])
Weight 2,100 g (Typ.)
Display Operating Mode Transmissive mode, Normally White
Surface Treatment Hard coating(3H) & Anti-Glare treatment of the front polarizer
Ver. 1.0 Sep. 17. 2008 4 / 32
From www.fpdclub.net
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VLCD -0.3 +5.5 Vdc r
Operating Temperature TOP 0 50 C 1
Storage Temperature TST -20 60 C 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
Figure 2. Temperature and relative humidity
Ver. 1.0 Sep. 17. 2008 5 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM201WE3
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and
liquid crystal. The second input power for the CCFL, is typically generated by an inverter. The inverter is an
external unit to the LCDs.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VRF - - 100 mV 13
- 955 1099 mA 1
Power Supply Input Current ILCD
- 1145 1489 mA 2
Differential Impedance Zm 90 100 110 ohm
Power Consumption PLCD - 4.78 5.49 Watt 1
Rush current IRUSH - - 3 A 3
LAMP :
Operating Voltage VBL 725 740 900 VRMS 4, 5
Operating Current IBL 3.0 7.5 8.0 mARMS 4
Established Starting Voltage Vs 4, 6
at 25 C 1,250 VRMS
at 0 C 1,550 VRMS
Operating Frequency fBL 40 60 70 kHz 7
Discharge Stabilization Time Ts 3 Min 4, 8
Power Consumption PBL 22.2 24.4 Watt 9
Life Time 50,000 Hrs 4, 10
Note : The design of the inverter must have specifications for the lamp in LCD Assembly.
The performance of the Lamp in LCM, for example life time or brightness, is extremely influenced by
the characteristics of the DC-AC inverter. So all the parameters of an inverter should be carefully
designed so as not to produce too much leakage current from high-voltage output of the inverter.
When you design or order the inverter, please make sure unwanted lighting caused by the mismatch
of the lamp and the inverter (no lighting, flicker, etc) never occurs. When you confirm it, the LCD◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
