Image preview - the first page of the document
![Panel_LG_Display_LM215WF3-SLC1_0_[DS]](/pics/5eafced909e8b.gif)
>> Download Panel_LG_Display_LM215WF3-SLC1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM215WF3
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 21.5" Full HD TFT LCD
BUYER General SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LM215WF3
SUFFIX SLC1
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ J. H. Park / G.Manager
REVIEWED BY
D. I . Chung / Manager [C]
/
Y. S. Chung / Manager [M]
D. H. Kang / Manager [P]
PREPARED BY
/
J. H. Oh / Engineer
Please return 1 copy for your confirmation with MNT Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.0 Jun. 24. 2010 1 / 32
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM215WF3
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 9
3-3 SIGNAL TIMING SPECIFICATIONS 14
3-4 SIGNAL TIMING WAVEFORMS 15
3-5 COLOR INPUT DATA REFERNECE 16
3-6 POWER SEQUENCE 17
3-7 VLCD Power Dip Condition 18
4 OPTICAL SFECIFICATIONS 19
5 MECHANICAL CHARACTERISTICS 25
6 RELIABLITY 28
7 INTERNATIONAL STANDARDS 29
7-1 SAFETY 29
7-2 EMC 29
7-3 ENVIRONMENT 29
8 PACKING 30
8-1 DESIGNATION OF LOT MARK 30
8-2 PACKING FORM 30
9 PRECAUTIONS 31
Ver. 0.0 Jun. 24. 2010 2 / 32
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM215WF3
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
Revision Revision
Page Description
No Date
0.0 Jun. 24. 2010 - First Draft, Preliminary Specifications
Ver. 0.0 Jun. 24. 2010 3 / 32
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM215WF3
Liquid Crystal Display
Product Specification
1. General Description
LM215WF3 is a Color Active Matrix Liquid Crystal Display with a Light Emitting Diode ( White LED) backlight
system without LED driver. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 23 inch diagonally measured
a c ti ve di s pl ay ar ea wi t h F HD re sol u ti o n (10 80 ve rti cal by 1 920 ho r i z ontal pi x el a rr ay)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus, presenting a palette of more than 16,7M colors with A-FRC (Advanced Frame Rate Control).
It has been designed to apply the 8Bit 2 port LVDS interface.
I t i s i n te n d ed to s up po r t di s pl ay s w h er e h i g h b ri g ht n e s s , s u p er w i d e vi ewi n g a n gl e,
high color saturation, and high color are important.
Mini-LVDS (RGB)
RGB Source Driver Circuit
S1 S1920
LVDS
2port
G1
CN1 Timing
(30pin)
Controller
+5.0V
TFT - LCD Panel
(1920 RGB 1080 pixels)
G900
+5.0V
Power Circuit
Block
Back light Assembly
VLED CN2 (6PIN)
(LED)
[ Figure 1 ] Block diagram
General Features
Active Screen Size 21.46 inches(545.22mm) diagonal
Outline Dimension 495.6(H) x 292.2(V) x 10.2(D) mm (Typ.)
Pixel Pitch 0.2475 mm x 0.2475mm
Pixel Format 1920 horiz. By 1080 vert. Pixels RGB stripes arrangement
Color Depth 16,7M colors (6bit + A-FRC)
Luminance, White 250 cd/m2 ( Center 1 Point, Typ.)
Viewing Angle(CR>10) View Angle Free (R/L 178(Typ.), U/D 178(Typ.))
Power Consumption Total 22.68 Watt (Typ.) (4.38 Watt @VLCD, 18.3 Watt @W/O Driver)
Weight 1300 g (typ.)
Display Operating Mode Transmissive mode, normally black
Surface Treatment Hard coating(3H), Anti-Glare treatment of the front polarizer
Ver. 0.0 Jun. 24. 2010 4 / 32
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM215WF3
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VLCD -0.3 6.0 Vdc at 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
