Image preview - the first page of the document
![Panel_LG_Display_LM230WF5-TRA1_0_[DS]](/pics/5eafd2b775933.gif)
>> Download Panel_LG_Display_LM230WF5-TRA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 23.0" FHD TFT LCD
BUYER General SUPPLIER L&T Display Technology (Fujian) Limited.
MODEL LM230WF5
SUFFIX TRA1
SIGNATURE DATE APPROVED BY DATE
J.D. Park / Director
/
REVIEWED BY
K.H. HWANG / Manager [EE]
/
H.J. CHO / Manager [ME]
Kent.Zhuang / Manager [PM]
/
Please return 1 copy for your confirmation R&D LCM Dept.
With your signature and comments. L&T Display Technology (Fujian) Limited.
Ver. 0.5 Oct., 25, 2010 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
1) ELECTRICAL CHARACTERISTICS 6
2) INTERFACE CONNECTIONS 8
3) Mini-LVDS characteristics 11
4) SIGNAL TIMING SPECIFICATIONS 15
5) SIGNAL TIMING WAVEFORMS 16
6) COLOR INPUT DATA REFERNECE 17
7) POWER SEQUENCE 18
8) POWER DIP CONDITION 19
4 OPTICAL SFECIFICATIONS 20
5 MECHANICAL CHARACTERISTICS 26
6 INTERNATIONAL STANDARDS 28
1) SAFETY 28
2) EMC 28
3) Environment 28
7 Precautions 29
Ver. 0.5 Oct., 25, 2010 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
Record of revisions
Revision No Date Page Description
Ver 0.1 Apr.,23,2010 - Preliminary Specifications
Ver 0.2 Jun.,06,2010 18 Modify Power Sequence
20 Change RGB color coordinate spec
29 Add Precautions
Ver 0.3 Jun.,12,2010 27 Updated mechanical drawing sheet
Ver 0.4 Jul.,12,2010 11 Add Mini-LVDS min. frequency
4 Add Color Gamut
Ver 0.5 Oct.,25,2010 7 Delete Notes 8.
Ver. 0.5 Oct., 25, 2010 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
1. General description
LM230WF5-TRA1 is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting
Diode (LED) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally white mode. It has a 23.0 inch
diagonally measured active display area with Full HD resolution (1080 vertical by 1920 horizontal
pixel array) Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in
vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with
a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 16,7M colors in case
of using Advanced-FRC(Frame Rate Control). It has been designed to apply the interface method
that enables low power, high speed, low EMI. FPD Link or compatible must be used
as a mini-LVDS (Low Voltage Differential Signaling) chip. It is intended to support applications
where thin thickness, wide viewing angle, low power are critical factors and graphic displays are
important. In combination with the vertical arrangement of the sub-pixels, the LM230WF5-TRA1
characteristics provide an excellent flat panel display for office automation products such as
monitors.
FIG. 1 Block diagram
Source driver circuit
S1 S1920
G1
Mini-LVDS
pair #1
CN1 TFT-LCD Panel
(1920 RGB 1080 pixels)
+5V Power circuit G1080
VLCD block
Backlight assembly (Single LED Bar)
FB 4ch
General features
Active screen size 23 inches(58.42cm) diagonal
Outline Dimension 533.2(H) x 312.0(V) x 8.3(D) mm(Typ.)
Pixel Pitch 0.0883*RGB(H)mm x 0.265(V)mm
Pixel Format 1920 horiz. By 1080 vert. Pixels RGB stripes arrangement
Interface Mini-LVDS 1Port
Color depth 16.7M colors (When use Advanced FRC)
Luminance, white 250 cd/m2 ( Center 1Point, typ)
Viewing Angle (CR>10) R/L 170(Typ.), U/D 160(Typ.)
Power Consumption Total 19.2 W(Typ.), (5.4 W@VLCD , 13.8 W@W/O Driver)
Weight 1490 g (Typ.)
Display operating mode Transmissive mode, Normally White
Surface treatments Hard coating (3H), Anti-glare treatment of the front polarizer
Color Gamut 68%(Typ.) CIE 1931
Ver. 0.5 Oct., 25, 2010 4 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
2. Absolute maximum ratings
The following are maximum values which, if exceeded,
may cause faulty operation or damage to the unit.
Table 1. Absolute maximum ratings
Values
Parameter Symbol Units Notes
Min Max
Power Supply Input Voltage VLCD -0.3 +6.0 Vdc At 25
Operating Temperature TOP 0 50 C
Storage Temperature TST -20 60 C
1
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max, and no condensation of water.
FIG. 2 Temperature and relative humidity
90%
60
60%
50 Storage
Wet Bulb
Temperature [ ]
Humidity
[(%)RH]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 0.5 Oct., 25, 2010 5 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
3. Electrical specifications
3-1. Electrical characteristics
It requires two power inputs. One is employed to power the LCD electronics and to drive the
TFT array and liquid crystal. The second input power for the LED/Backlight, is typically
generated by an LED Driver. The LED Driver is an external unit to the LCDs.
Table 2. Electrical characteristics
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.3 V 3
ILCD-MOSAIC(60Hz) - 1080 1410 mA 1
Power Supply Input Current ILCD-BLACK(60Hz) - 1300 1690 mA 2
ILCD-BLACK(75Hz) - 1960 mA
Power Consumption PLCD - 5.4 7.15 Watt 1
Inrush current IRUSH - - 3.0 A 4
Note :
1. The specified current and power consumption are
under the VLCD=5.0V, 25 r 2 C,fV=60Hz condition
whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current of Black pattern is specified under the VLCD=5.0V, 25 r 2 C,fV=60Hz condition.
3. Permissive power ripple should be measured under VCC=5.0V, 25 C, fV (frame frequency)=75Hz
condition and At that time, we recommend the bandwidth configuration of oscilloscope
is to be under 20MHz.
4. The duration of rush current is about 5ms and rising time of power Input is 500us r 20%.
FIG.3 pattern for Electrical characteristics
power consumption measurement power input ripple
White : 255Gray
Black : 0Gray
Mosaic Pattern(8 x 6) Full Black Pattern
Ver. 0.5 Oct., 25, 2010 6 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
Table 3. LED bar Electrical characteristics
Values
Parameter Symbol Condition Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 60 65 mA 2,7
LED String Voltage Vs - 57.6 59.9 V 3,7
Power Consumption PBar - 13.8 14.4 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7
* LED driver design guide
: The design of the LED driver must have specifications for the LED in LCD Assembly.
The performance of the LED in LCM, for example life time or brightness, is extremely
influenced by the characteristics of the LED driver.
So all the parameters of an LED driver should be carefully designed and output current
should be constant current control.
Please control feedback current of each string individually to compensate the current
variation among the strings of LEDs.
When you design or order the LED driver, please make sure unwanted lighting caused by
the mismatch of the LED and the LED driver (no lighting, flicker, etc) never occurs.
When you confirm it, the LCD module should be operated in the same condition as
installed in your instrument.
1. Specified values are for a single LED bar.
2. The specified current is input LED chip 100% duty current.
3. The specified voltage is input LED string and Bar voltage at typical 60 mA 100% duty current.
4. The specified power consumption is input LED bar power consumption at typical 60 mA 100%
duty current.
5. The life is determined as the time at which luminance of the LED is 50% compared to that of
initial value at the typical LED current on condition of continuous operating at 25 r 2 C.
6. The LED bar power consumption shown above does not include loss of external driver.
The used LED bar current is the LED typical current.
Min Power Consumption is calculated with PBar = Vs(Min.) x Is(Typ.) x Nstring
Max Power Consumption is calculated with PBar = Vs(Max.) x Is(Typ) x Nstring
7. LED operating DC Forward Current and Junction Temperature must not exceed LED Max
Ratings at 25 r 2 C.
Ver. 0.5 Oct., 25, 2010 7 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
3-2. Interface connections
LCD connector(CN1) : TF19L-50S-0.5SH(Hirose) or Equivalent
Mating connector : 50pin FFC locking Cable
Table 4. Module connector(CN1) pin configuration
NO. Symbol Description NO. Symbol Description
1 GND Ground 26 POL Polarity Control Signal
Charge Share mode Control
2 GND Ground 27 CSC
Signal
3 LV5- Mini LVDS Receiver Signal(5-) 28 H2DOT Horizontal 2 Inversion Signal
4 LV5+ Mini LVDS Receiver Signal(5+) 29 GND Ground
5 GND Ground 30 ICLK_RESET Vertical Start Pulse
6 LV4- Mini LVDS Receiver Signal(4-) 31 ICLK1 GIP GATE Clock 1
7 LV4+ Mini LVDS Receiver Signal(4+) 32 ICLK2 GIP GATE Clock 2
8 GND Ground 33 ICLK3 GIP GATE Clock 3
9 LV3- Mini LVDS Receiver Signal(3-) 34 ICLK4 GIP GATE Clock 4
GIP Panel VDD for Odd GATE
10 LV3+ Mini LVDS Receiver Signal(3+) 35 IVDD-O
TFT
GIP Panel VDD for Even GATE
11 GND Ground 36 IVDD-E
TFT
Mini LVDS Receiver Clock
12 LVCLK- 37 FLK2 GPM Control Clock
Signal(-)
Mini LVDS Receiver Clock
13 LVCLK+ 38 FLK1 GPM Control Clock
Signal(+)
14 GND Ground 39 GND Ground
15 LV2- Mini LVDS Receiver Signal(2-) 40 SDA I2C Data
16 LV2+ Mini LVDS Receiver Signal(2+) 41 SCL I2C Clock
17 GND Ground 42 GND Ground
18 LV1- Mini LVDS Receiver Signal(1-) 43 VIN Input Voltage
19 LV1+ Mini LVDS Receiver Signal(1+) 44 VIN Input Voltage
20 GND Ground 45 VIN Input Voltage
21 LV0- Mini LVDS Receiver Signal(0-) 46 VIN Input Voltage
22 LV0+ Mini LVDS Receiver Signal(0+) 47 VIN Input Voltage
23 GND Ground 48 VIN Input Voltage
24 SOE Source Output Enable SIGNAL 49 GND Ground
25 POL2 Polarity Control Signal 50 GND Ground
Ver. 0.5 Oct., 25, 2010 8 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
FIG. 4 Connector diagram
TBD
#1# CN1 #50
#30
1 .......
signal pairs
Power(5V)
#1 #50
Rear view of LCM
Note:
1. NC: No Connection.
2. All GND(ground) pins should be connected together and to Vss which should also
be connected to the LCD's metal frame.
3. All VLCD (power input) pins should be connected together.
4. Input Level of Mini-LVDS signal is based on the Source D-IC Spec
Ver. 0.5 Oct., 25, 2010 9 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
The LED interface connector is a model 10FH-SM1-GAN-TB manufactured by JST.
The mating connector is a FFC/FPC specified in LED interface connector specification.
The pin configuration for the connector is shown in the table below.
Table 5. LED connector pin configuration
Pin No. Symbol Description Notes
1 FB1 Channel1 Current Feed Back
2 FB2 Channel2 Current Feed Back
3 X N/C
4 X N/C
5 Vled LED Power Supply (Common Input)
6 Vled LED Power Supply (Common Input)
7 X N/C
8 X N/C
9 FB3 Channel3 Current Feed Back
10 FB4 Channel4 Current Feed Back
FIG. 5 Backlight connector view
PCB
10
1
LED
Ver. 0.5 Oct., 25, 2010 10 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
3-3. Mini-LVDS characteristics
3-3-1. Signal Timing Specifications
Table 6. ELECTRICAL CHARACTERISTICS
Parameter Symbol Condition MIN TYP MAX Unit Note
Mini-LVDS Clock frequency CLK 3.0V VCC 3.6V 160 290 MHz
mini-LVDS input Voltage (VCC-1.2)
VIB 0.9 V
(Center) VID / 2
mini-LVDS input Voltage
VIB 0.8 V
Distortion (Center)
Mini-LVDS Clock
5
mini-LVDS differential and Data
VID 0.2 0.7 V
Voltage range
mini-LVDS differential
VID 0.025 0.7 V
Voltage range Dip
FIG. 6 Description of VID, VIB, VID
Ver. 0.5 Oct., 25, 2010 11 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LM230WF5
Liquid Crystal Display
Product Specification
3-3-1. Signal Timing Specifications
Table 7. Timing Requirements
Parameter Symbol Condition Min Typ Max Unit Note
Mini Clock pulse period T1 3.45 - ns
Mini Clock pulse low period T2 1.6 - - ns
Mini Clock pulse high period T3 1.6 - - ns 1
Mini Data setup time T6 0.7 - - ns
Mini Data hold time T7 0.7 - - ns
Reset low to SOE rising time T8 0 - - ns
SOE to Reset input time T9 200 - - ns
CLK
Receiver off to SOE timing T10 5 - -
cycle
POL signal to SOE setup time T11 -5 - - ns
POL signal to SOE hold time T12 6 - - ns
CLK
Reset High Period T13 3
cycle
SOE signal Pulse Width T14 200 ns
Note : 1. 290 MHz Clock Frequency @ 3.0
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
