Image preview - the first page of the document
![Panel_LG_Display_LB150X03-TL01_0_[DS]](/pics/5eaf6c638d804.gif)
>> Download Panel_LG_Display_LB150X03-TL01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LB150X03-TL01
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 15.1" XGA TFT LCD
Customer SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LB150X03
Suffix TL01
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
J. D. KIM / G.Manager
/
REVIEWED BY
/
W. Y. SUN / Manager
/ PREPARED BY
T. I. OH / Engineer
Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.1 JUL. 21. 2011 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LB150X03-TL01
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 CONNECTION BETWEEN HOST SYSTEM AND LVDS RECEIVER 8
3-4 LVDS SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING SPECIFICATION 12
3-6 POWER SEQUENCE 17
4 OPTICAL SFECIFICATIONS 19
5 MECHANICAL CHARACTERISTICS 23
6 RELIABLITY 26
7 INTERNATIONAL STANDARDS
7-1 SAFETY 27
7-2 ENVIRONMENTAL 27
7-3 EMC 27
8 PACKING
8-1 DESIGNATION OF LOT MARK 28
8-2 PACKING FORM 28
9 PRECAUTIONS 29
Ver. 0.1 JUL. 21. 2011 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LB150X03-TL01
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
Revision No Revision Date Page Description Note
0.1 JUL.21.2011 - First Draft (preliminary)
Ver. 0.1 JUL. 21. 2011 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LB150X03-TL01
Liquid Crystal Display
Product Specification
1. General Description
The LB150X03-TL01 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system.
The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display
operating in the normally white mode. This TFT-LCD has 15.0 inches diagonally measured active display
area with XVGA resolution(1024 horizontal by 768 vertical pixel array). Each pixel is divided into Red, Green
and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-
pixel color is determined with a 8-bit(or 6-bit) gray scale signal for each dot, thus, presenting a palette of
more than 16,777,216(or 262,144) colors.
The LB150X03-TL01 has been designed to apply the interface method that enables low power, high speed,
low EMI.
The LB150X03-TL01 is intended to support applications where thin thickness, low power are critical factors
and graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LB150X03-TL01 characteristics provide an excellent flat display for office automation products such as PC
or etc.
LVDS-Rx Column Driver Circuit
&
Timing
Control
Block
Row Driver Circuit
GMA
Reference TFT LCD
CN1
Block (1024 x 768)
Power
Block
LED Driver LED Backlight Ass'y
Block
: GMA : Power : Control & Data
General Features
Active Screen Size 15.0 inches(30.75cm) diagonal
Outline Dimension 326.5(H) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
