Image preview - the first page of the document
![Panel_LG_Display_LC420EUS-SCA2_0_[DS]](/pics/5eaf7f4b2e887.gif)
>> Download Panel_LG_Display_LC420EUS-SCA2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC420EUS
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 42.0" WUXGA TFT LCD
BUYER SUPPLIER LG.Display Co., Ltd.
MODEL *MODEL LC420EUS
SUFFIX SCA2 (RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ J.Y. LEE / Team Leader
REVIEWED BY
/ J.K.KIM / Project Leader
PREPARED BY
/ W.K.SANG / Engineer
Please return 1 copy for your confirmation with TV Products Development Dept.
your signature and comments. LG. Display LCD Co., Ltd
Ver. 1.0 0 /35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420EUS
Product Specification
CONTENTS
Number ITEM Page
COVER 0
CONTENTS 1
RECORD OF REVISIONS 2
1 GENERAL DESCRIPTION 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL SPECIFICATIONS 5
3-1 ELECTRICAL CHARACTERISTICS 5
3-2 INTERFACE CONNECTIONS 9
3-3 SIGNAL TIMING SPECIFICATIONS 12
3-4 DATA MAPPING AND TIMING 15
3-5 PANEL PIXEL STRUCTURE 16
3-6 POWER SEQUENCE 17
4 OPTICAL SPECIFICATIONS 18
5 MECHANICAL CHARACTERISTICS 22
6 RELIABILITY 25
7 INTERNATIONAL STANDARDS 26
7-1 SAFETY 26
7-2 ENVIRONMENT 26
8 PACKING 27
8-1 INFORMATION OF LCM LABEL 27
8-2 PACKING FORM 27
9 PRECAUTIONS 28
9-1 MOUNTING PRECAUTIONS 28
9-2 OPERATING PRECAUTIONS 28
9-3 ELECTROSTATIC DISCHARGE CONTROL 29
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 29
9-5 STORAGE 29
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 29
Ver. 1.0 1 /35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420EUS
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
0.0 June, 11, 2010 - Preliminary Specification(First Draft)
0.1 Aug.12.2010 7,8 Note 7 is inserted as LED Life Time
Rising/Falling Response Timing is changed
18
Rising/Falling : 5(Typ)-> 6(Typ) , 7(Max)->8(Max)
1.0 Aug.18.2010 Final CAS
Outline Dimension is changed because of simple LCM
3 973.2(H) x 566.2 (V) x 10.8 mm(B)/25.3(D) (Typ.)
973.2(H) x 566.2 (V) x 10.8 mm(B)
Power Consumption is changed
Total 111.2 W (Typ.)
(Logic=18.7 W with LGD T-Con Board, Backlight=92.5W @ with
Driver
3
Total 100.06 W (Typ.)
(Logic=18.66 W with LGD T-Con Board, Backlight=81.4W @ with
Driver
Power connector wire length is inserted
24
355
Ver. 1.0 2 /35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420EUS
Product Specification
1. General Description
The LC420EUS is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED)
bac k light s ys tem . T he m atr ix em plo ys a- S i T hin F i lm T r ans is tor as the ac ti ve e lem ent .
It is a transmissive type display operating in the normally black mode. It has a 42.02 inch diagonally measured
active display area with W UXGA resolution (1080 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 8-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 16.7M(true) colors.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
Power (VCC, VDD, VGH, VGL)
Source Control Signal Source Driver Circuit
Gate Control Signal CN1 S1 S1920
(60pin)
Gamma Reference Voltage G1
Gate Driver Circuit
mini-LVDS (RGB) for Left drive
Power (VCC, VDD, VGH, VGL) TFT - LCD Panel
Source Control Signal (1920 RGB 1080 pixels)
[Gate In Panel]
Gate Control Signal CN2
(60pin)
Gamma Reference Voltage
G1080
mini-LVDS (RGB) for Right drive
H : 6 Block
LED Anode CN1 (12pin) V : 2Block
CN2 (13pin)
LED Cathode Local Dimming : 12 Block
General Features
Active Screen Size 42.02 inches(1067.31mm) diagonal
Outline Dimension 973.2(H) x 566.2 (V) x 10.8 mm(B)
Pixel Pitch 0.4845 mm x 0.4845 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement
Color Depth 8-bit, 16.7 M colors ( 1.06B colors @ 10 bit (D) System Output )
Source D-IC : 8-bit mini-LVDS, gamma reference voltage, and control signals
Drive IC Data Interface
Gate D-IC : Line on Glass(LOG) Through Source D-IC
Luminance, White 450 cd/m2 (Center 1point ,Typ.)
Viewing Angle (CR>10) Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.))
Total 100.06 W (Typ.)
Power Consumption
(Logic=18.66 W with LGD T-Con Board, Backlight=81.4W @ with Driver
Weight 11.1Kg (Typ.)
Display Mode Transmissive mode, Normally black
Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer (Haze 10%)
Ver. 1.0 3 /35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC420EUS
Product Specification
2. Absolute Maximum Ratings
The following items are maximum values which, if exceeded, may cause faulty operation or damage to the
LCD module.
Table 1. ABSOLUTE MAXIMUM RATINGS
Value
Parameter Symbol Unit Note
Min Max
Logic Power Voltage VCC -0.5 +4.0 VDC
Gate High Voltage VGH +18.0 +30.0 VDC
Gate Low Voltage VGL -8.0 -4.0 VDC
Source D-IC Analog Voltage VDD -0.3 +18.0 VDC 1
