Image preview - the first page of the document
![Panel_LG_Display_LC840EQD-SEM1_0_[DS]](/pics/5eafc4524115e.gif)
>> Download Panel_LG_Display_LC840EQD-SEM1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC840EQD
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 84.0" QWUXGA TFT LCD
BUYER General SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LC840EQD
SUFFIX SEM1 (RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ S.K.Park / Team Leader
REVIEWED BY
/ S.W. Yu / Project Leader
PREPARED BY
/ K.H.Jang / Engineer
Please return 1 copy for your confirmation with TV Product Development Dept.
your signature and comments. LG Display Co., Ltd.
Ver. 0.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC840EQD
Product Specification
CONTENTS
Number ITEM Page
COVER -
CONTENTS 1
RECORD OF REVISIONS 2
1 GENERAL DESCRIPTION 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL SPECIFICATIONS 5
3-1 ELECTRICAL CHARACTERISTICS 5
3-2 INTERFACE CONNECTIONS 7
3-3 SIGNAL TIMING SPECIFICATIONS 11
3-4 V by One SIGNAL SPECIFICATIONS 12
3-5 COLOR DATA REFERENCE 14
3-6 POWER SEQUENCE 15
4 OPTICAL SPECIFICATIONS 17
5 MECHANICAL CHARACTERISTICS 21
6 RELIABILITY 24
7 INTERNATIONAL STANDARDS 25
7-1 SAFETY 25
7-2 EMC 25
7-3 ENVIRONMENT 25
8 PACKING 26
8-1 INFORMATION OF LCM LABEL 26
8-2 PACKING FORM 26
9 PRECAUTIONS 27
9-1 MOUNTING PRECAUTIONS 27
9-2 OPERATING PRECAUTIONS 27
9-3 ELECTROSTATIC DISCHARGE CONTROL 28
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 28
9-5 STORAGE 28
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 28
Ver. 0.1 1 /41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC840EQD
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
0.1 Mar, 30, 2012 - Preliminary Specification (First Draft)
Ver. 0.1 2 /41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC840EQD
Product Specification
1. General Description
The LC840EQD is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED)
backl i ght sy st em . T he m at rix em pl oys a-Si T hi n F i lm T ransi st o r as t he act iv e el em ent .
It is a transmissive display type which is operating in the normally black mode. It has a 84.04 inch diagonally
measured active display area with QWUXGA resolution (2160 vertical by 3840 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.06Bilion colors.
It has been designed to apply the 10-bit 16 Lane V by One interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
EPI (RGB)
+12.0V CN1 +12.0V
5pin)
EEPROM Source Driver Circuit
Vby1
8lane Vby1 SCL SDA S1 S3840
Data 1~8lane Gate Driver Circuit G1
format
PCID Option
Enable signal Timing Controller
Bit
CN2 I2C Vby1 Rx +L/D TFT - LCD Panel
selection (51pin)
+ DGA + ODC (3840 RGB 2160 pixels)
L-DIM Control
Enable Signals
HTPDN
LOCKN G2160 S1 S3840
Power Signals
Power Circuit
Block Source Driver Circuit
Vby1 Vby1 EPI (RGB)
8lane 9~16lane
CN3
(41pin)
VSYNC, SIN, SCLK, GND Local Dimming
LED Driver : 32 Block
+24.0V, GND, On/Off
ExtVBR-B
Active Screen Size 84.04 inches(2134.62 mm) diagonal
Outline Dimension 1904.0(H) 1096.0(V) X 15.5(B) /24.0 mm(D) (Typ.)
Pixel Pitch 0.4845 mm x 0.4845 mm
Pixel Format 3840 horiz. by 2160 vert. Pixels, RGB stripe arrangement
Color Depth 10bit(D), 1.06Billon colors
Luminance, White 350 cd/m 2 (Center 1point ,Typ.)
Viewing Angle (CR>10) Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.))
Total 412W (TBD) (Typ.) [Logic= 17(TBD)W,
Power Consumption
LED Driver=395(TBD)W (ExtVbr_B=100% )]
Weight 43.5 Kg(TBD) (Typ.)
Display Mode Transmissive mode, Normally black
Surface Treatment Hard coating(3H), Anti-glare treatment of the front polarizer (Haze 1%)
Ver. 0.1 3 /41
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC840EQD
Product Specification
2. Absolute Maximum Ratings
The following items are maximum values which, if exceeded, may cause faulty operation or permanent damage
to the LCD module.
Table 1. ABSOLUTE MAXIMUM RATINGS
Value
Parameter Symbol Unit notes
Min Max
LCD Circuit VLCD -0.3 +14.0 VDC
Power Input Voltage
Driver VBL -0.3 + 27.0 VDC
ON/OFF VOFF / VON -0.3 +5.5 VDC 1
Driver Control Voltage
Brightness EXTVBR-B 0.0 +5.5 VDC
T-Con Option Selection Voltage VLOGIC -0.3 +4.0 VDC
Operating Temperature TOP 0 +50 C
2,3
Storage Temperature TST -20 +60 C
Panel Front Temperature TSUR - +68 C 4
Operating Ambient Humidity HOP 10 90 %RH
2,3
Storage Humidity HST 10 90 %RH
notes :1. Ambient temperature condition (Ta = 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
