Image preview - the first page of the document
![Panel_LG_Display_LC260WXE-SBV2_0_[DS]](/pics/5eaf700e9ed57.gif)
>> Download Panel_LG_Display_LC260WXE-SBV2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
"
APPROVED BY
REVIEWED BY
PREPARED BY
Ver. 0.0 1 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
Ver. 0.0 2 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
RECORD OF REVISIONS
Ver. 0.0 3 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
1. General Description
The LC260WXE is a Color Active Matrix Liquid Crystal Display with an integral External Electrode Fluorescent
Lamp(EEFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive display type which is operating in the normally black mode. It has a 26.01 inch diagonally
measured active display area with WXGA resolution (768 vertical by 1366 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in Horizontal stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus presenting a palette of more than 16.7M(true) colors.
It has been designed to apply the 8-bit 1-port LVDS interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
EEPROM
+12.0V SCL SDA
LVDS 1Port
LVDS Select #9 TFT - LCD Panel
CN1 Timing Controller (1366 768 x RGB pixels)
(30pin)
[LVDS Rx + Spread Spectrum [Gate In Panel]
integrated]
S1 S1366
Power Circuit RGB
Block Source Driver Circuit
High Input CN2, 3pin, 10 Lamps/@60mA
Back light Assembly (10EEFL)
High Input CN3, 3pin, 10 Lamps/@60mA
General Features
Ver. 0.0 4 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
2. Absolute Maximum Ratings
The following items are maximum values which, if exceeded, may cause faulty operation or damage to the
LCD module.
Table 1. ABSOLUTE MAXIMUM RATINGS
r
r
Notes : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be Max. 39 C and no condensation of water.
2. Gravity mura can be guaranteed below 40 condition.
3. The mold backlight can be discolored in a high temperature by long time operation
but it doesn't care about the picture quality.
90%
60
60%
50 Storage
Humidity [(%)RH]
Wet Bulb
Temperature [ C]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ C]
Ver. 0.0 5 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
3-1. Electrical Characteristics
It requires two power inputs. One is employed to power for the LCD circuit.
The other Is used for the EEFL backlight circuit.
Table 2. ELECTRICAL CHARACTERISTICS
Notes : 1. The specified current and power consumption are under the VLCD=12.0V, 25 r 2 C, fV=60Hz
condition whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current is specified at maximum current pattern
3. The duration of rush current is about 2ms and rising time of power input is 0.5ms (min.).
White : 255 Gray
Black : 0 Gray
Mosaic Pattern(8 x 6)
Ver. 0.0 6 / 27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC260WXE
Product Specification
Table 3. ELECTRICAL CHARACTERISTICS for IPB& Lamp (Continue)
Notes : The design of the inverter must have specifications for the lamp in LCD Assembly.
The electrical characteristics of inverter are based on High-High Driving type.
The performance of the lamps in LCM, for example life time or brightness, is extremely influenced by
the characteristics of the DC-AC inverter. So, all the parameters of an inverter should be carefully
designed so as not to produce too much leakage current from high-voltage output of the inverter.
When you design or order the inverter, please make sure unwanted lighting caused by the mismatch
of the lamp and the inverter (no lighting, flicker, etc) has never been occurred. When you confirm it,
the LCD◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
