Image preview - the first page of the document
![Panel_LG_Display_LC320WXN-SBD1_0_[DS]](/pics/5eaf76f6b877f.gif)
>> Download Panel_LG_Display_LC320WXN-SBD1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
This Product must be used for a TV Application
( ) Final Specification This is not designed for the public display.
Title 32.0" WXGA TFT LCD
BUYER General SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LC320WXN
SUFFIX SBD1
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ S.S. Kim / Team Leader
REVIEWED BY
/ J.S. PARK / Sub Leader
PREPARED BY
/ Y.J. KIM / Engineer
Please return 1 copy for your confirmation with TV Product Development Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.4 1 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
CONTENTS
Number ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 6
3-2 INTERFACE CONNECTIONS 8
3-3 SIGNAL TIMING SPECIFICATIONS 10
3-4 SIGNAL TIMING WAVEFORMS 11
3-5 COLOR DATA REFERENCE 12
3-6 POWER SEQUENCE 13
4 OPTICAL SPECIFICATIONS 15
5 MECHANICAL CHARACTERISTICS 19
6 RELIABILITY 22
7 INTERNATIONAL STANDARDS 23
7-1 SAFETY 23
7-2 EMC 23
8 PACKING 24
8-1 DESIGNATION OF LOT MARK 24
8-2 PACKING FORM 24
9 PRECAUTIONS 25
9-1 MOUNTING PRECAUTIONS 25
9-2 OPERATING PRECAUTIONS 25
9-3 ELECTROSTATIC DISCHARGE CONTROL 26
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 26
9-5 STORAGE 26
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 26
Ver. 0.4 2 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
0.1 Jun, 30, 2008 - Preliminary Specification(First Draft)
0.2 Jul, 14, 2008 21 Change of Mechanical drawing(Cover bottom)
0.3 Aug, 12, 2008 21 Change of Mechanical drawing( UDM Hole Size)
0.4 Aug, 20, 2008 - Change of TDB SPEC
Ver. 0.4 3 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
1. General Description
The LC320WXN is a Color Active Matrix Liquid Crystal Display with an integral External Electrode Fluorescent
Lamp(EEFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 31.51 inch diagonally measured
active d ispla y area with WXGA reso lution (768 ver tica l by 1366 ho r izontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in Horizontal stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 8-bit gray scale signal for each dot,
thus presenting a palette of more than 16.7M(true) colors.
It has been designed to apply the 8-bit 1-port LVDS interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
EEPROM
+12.0V SCL SDA
LVDS 1Port
LVDS Select #9 Timing Controller TFT - LCD Panel
CN1 (1366 768 x RGB pixels)
EXTVBR-B #28 (30pin) [LVDS Rx + ODC + OPC
+ SDRAM + Spread Spectrum [Gate In Panel]
VBR_B out #27
OPC EN #10 integrated]
S1 S1366
Power Circuit RGB
Block Source Driver Circuit
+24.0V```
VBR-A, EXT.VBR-B
On/off ,Status Back light Assembly (12EEFL)
CN2, Inverter (Master, 14Pin, High)
General Features
Active Screen Size 31.51 inches(800.4mm) diagonal
Outline Dimension 760.0 mm(H) x 450.0 mm(V) x 48.0 mm(D) (Typ.)
Pixel Pitch 510.75 x 170.25 x RGB
Pixel Format 1366 horiz. by 768 vert. pixels RGB stripe arrangement
Color Depth 8bit, 16,7 M colors
Luminance, White 500 cd/m2 (Center 1 point) (Typ.)
Viewing Angle (CR>10) Viewing angle free ( R/L 178(Typ.), U/D 178(Typ.))
Power Consumption Total 87.8Watt (Typ.) (Logic=3.8 W, Inverter= 84W [VBR-A=1.65V] )
Weight 6,000g(Typ.)
Display Operating Mode Transmissive mode, normally black
Surface Treatment Hard coating(3H), anti-glare treatment of the front polarizer (Haze 10%)
Ver. 0.4 4 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
2. Absolute Maximum Ratings
The following items are maximum values which, if exceeded, may cause faulty operation or damage to the
LCD module.
Table 1. ABSOLUTE MAXIMUM RATINGS
Value
Parameter Symbol Unit Remark
Min Max
Power Input LCM VLCD -0.3 +14.0 VDC at 25 r 2 C
Voltage Backlight inverter VBL -0.3 +27.0 VDC
ON/OFF Control Voltage VON/OFF -0.3 +5.5 VDC
Brightness Control Voltage VBR 0 +5.0 VDC
Operating Temperature TOP 0 +50 C
Storage Temperature TST -20 +60 C
Note 1,2
Operating Ambient Humidity HOP 10 90 %RH
Storage Humidity HST 10 90 %RH
Notes : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39 C Max. and no condensation of water.
2. Gravity mura can be guaranteed under 40 condition.
90%
60
60%
50 Storage
Humidity [(%)RH]
Wet Bulb
Temperature [ C]
40
40%
Operation
30
20
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ C]
Ver. 0.4 5 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
It requires two power inputs. One is employed to power for the LCD circuit.
The other Is used for the EEFL backlight and inverter circuit.
Table 2. ELECTRICAL CHARACTERISTICS
Value
Parameter Symbol Unit Note
Min Typ Max
Circuit :
Power Input Voltage VLCD 10.8 12.0 13.2 VDC
- 311 405 mA 1
Power Input Current ILCD
- 270 360 mA 2
Power Consumption PLCD - 3.73 4.75 Watt 1
Rush current IRUSH - - 3.0 A 3
Notes : 1. The specified current and power consumption are under the VLCD=12.0V, 25 r 2 C, fV=60Hz
condition whereas mosaic pattern(8 x 6) is displayed and fV is the frame frequency.
2. The current is specified at maximum current pattern.
3. The duration of rush current is about 2ms and rising time of power input is 0.5ms (min.).
White : 255 Gray
Black : 0 Gray
Mosaic Pattern(8 x 6)
Ver. 0.4 6 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
Table 3. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
Inverter :
Power Supply Input Voltage VBL 22.8 24.0 25.2 Vdc 1
Power Supply Input Voltage Ripple - - 0.5 Vp-p 1
- 3.5 3.85 A VBR-A = 1.65V ... 1
After Aging IBL_A
Power Supply - 3.6 4.0 A VBR-A = 3.3V ... 1
Input Current - 4.0 4.5 A VBR-A = 1.65V ... 2
Before Aging IBL_B
- 4.5 5.0 A VBR-A = 3.3V ... 2
VBL = 22.8V
Power Supply Input Current (In-Rush) Irush - - 6.3 A Ext VBR-B = 100%
VBR-A = 1.65V
Power Consumption PBL - 84 92.4 W VBR-A = 1.65V ... 1
Brightness Adjust VBR-A 0.0 1.65 3.3 Vdc
On V on 2.5 - 5.0 Vdc
On/Off
Off V off -0.3 0.0 0.8 Vdc
Input Voltage for Brightness Adjust Ext. VBR-B 30 - 100 % On Duty
Control System
Signals PWM Frequency for NTSC 120 Hz
5
NTSC & PAL PAL 100 Hz
Pulse Duty High Level 2.5 - 5.0 Vdc
Level(PWM) HIGH: Lamp on
LOW:Lamp off
(Burst mode) Low Level 0.0 - 0.8 Vdc
Lamp:
Discharge Stabilization Time Ts 3 min 3
Life Time 50,000 Hrs 4
Notes :
1. Electrical characteristics are determined after the unit has been `ON' and stable for approximately 120
minutes at 25 2 C. The specified current and power consumption are under the typical supply Input voltage
24Vand VBR (VBR-A : 1.65V & ExtVBR-B : 100%), it is total power consumption.
The ripple voltage of the power supply input voltage is under 0.5 Vp-p. LGD recommend Input Voltage is
24.0V 5%.
2. Electrical characteristics are determined within 30 minutes at 25 2 C.
The specified currents are under the typical supply Input voltage 24V.
3. The brightness of the lamp after lighted for 5minutes is defined as 100%.
TS is the time required for the brightness of the center of the lamp to be not less than 95% at typical current.
The screen of LCD module may be partially dark by the time the brightness of lamp is stable after turn on.
4. Specified Values are for a single lamp which is aligned horizontally.
The life time is determined as the time which luminance of the lamp is 50% compared to that of initial value
at the typical lamp current (VBR-A : 1.65V & ExtVBR-B :100%), on condition of continuous operating at 25 2 C
5. LGD recommend that the PWM freq. is synchronized with Two times harmonic of Vsync signal of system.
6. The duration of rush current is about 10ms.
Ver. 0.4 7 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-2. Interface Connections
This LCD module employs two kinds of interface connection, a 30-pin connector is used for the module
electronics and One connectors(14-pin) are used for the integral backlight system.
3-2-1. LCD Module
-LCD Connector(CN1) : FI-X30SSL-HF (Manufactured by JAE) or Equivalent
-Mating Connector : FI-X30C2L (Manufactured by JAE) or Equivalent
Table 4. MODULE CONNECTOR(CN1) PIN CONFIGURATION
Pin No. Symbol Description Note
1 VLCD Power Supply +12.0V
2 VLCD Power Supply +12.0V
3 VLCD Power Supply +12.0V
4 VLCD Power Supply +12.0V
5 GND Ground
6 GND Ground
7 GND Ground
7 GND Ground
9 LVDS Select `H' =JEIDA , `L' or NC = VESA
10 OPC Enable OPC Enable(`L' = Disable, `H' = Enable)
11 GND Ground
12 RA- LVDS Receiver Signal(-)
13 RA+ LVDS Receiver Signal(+)
14 GND Ground
15 RB- LVDS Receiver Signal(-)
16 RB+ LVDS Receiver Signal(+)
17 GND Ground
18 RC- LVDS Receiver Signal(-)
19 RC+ LVDS Receiver Signal(+)
20 GND Ground
21 RCLK- LVDS Receiver Clock Signal(-)
22 RCLK+ LVDS Receiver Clock Signal(+)
23 GND Ground
24 RD- LVDS Receiver Signal(-)
25 RD+ LVDS Receiver Signal(+)
26 GND Ground
27 OPC OUT OPC Output (From LCM)
28 EXT_VBR External VBR (From System)
29 GND Ground
30 GND Ground 5
Notes :
1. All GND(ground) pins should be connected together to the LCD module's metal frame.
2. All VLCD (power input) pins should be connected together.
3. All Input levels of LVDS signals are based on the EIA 644 Standard.
4. Specific pins(pin No. #10,#27,#28) are used for OPC function of the LCD module.
If not used, these pins are no connection. (Please see the Appendix V for more information.)
5. Specific pin No. #30 is used for "No signal detection" of system signal interface.
It should be GND for NSB(No Signal Black) during the system interface signal is not.
If this pin is "H", LCD Module displays AGP(Auto Generation Pattern).
Ver. 0.4 8 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-2-2. Backlight Inverter
Master
-Inverter Connector : 20022WR-14B1
(manufactured by Yeon-Ho) or Equivalent
- Mating Connector : 20022HS-14 or Equivalent
Table 5. INVERTER CONNECTOR PIN CONFIGULATION
Pin No Symbol Description Master Note
1 VBL Power Supply +24.0V VBL
2 VBL Power Supply +24.0V VBL
3 VBL Power Supply +24.0V VBL
4 VBL Power Supply +24.0V VBL
5 VBL Power Supply +24.0V VBL
6 GND Backlight Ground GND
7 GND Backlight Ground GND
8 GND Backlight Ground GND 1
9 GND Backlight Ground GND
10 GND Backlight Ground GND
11 VBR-A Analog Dimming VBR-A 2
12 VON/OFF Backlight ON/OFF control VON/OFF 3
13 EXTVBR-B External PWM EXTVBR-B 4
14 Status Lamp Status Status 5
Notes : 1. GND should be connected to the LCD module's metal frame.
2. Minimum Brightness : 0.0V / Maximum Brightness : 3.3V / "OPEN" : 1.65V
3. ON : 2.5 ~ 5.0V / OFF : 0.0 ~ 0.8V . Open or `H' for B/L On is default status.
4. High : Lamp ON/ Low : Lamp OFF, Pin#13 can be opened. ( if Pin #13 is open , EXTVBR-B is 100% )
Please see Appendix V for more information.
5. Normal : Low (under 0.7V) / Abnormal : High (upper 3.0V)
Please see Appendix VI for more information.
6. Each impedance of pin #11, 12 and 13 is TBD [K ] , TBD [K ] and TBD [K ].
Rear view of LCM PCB
14
...
...
1
Ver. 0.4 9 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-3. Signal Timing Specifications
Table 6-1 shows the signal timing required at the input of the LVDS transmitter. All of the interface signal
timing should be satisfied with the following specification for normal operation.
[ DE (Data Enable) Only ]
ITEM Symbol Min Typ Max Unit Note
Period tCLK 12.5 13.8 15.8 ns
DCLK
Frequency - 63 72.4 80 MHz
Period tHT 1456 1528 1920 tCLK
Horizontal Valid tHV 1366 1366 1366 tCLK
Horizontal Blank - tHP- tHV 162 tHP- tHV
Hsync Frequency fH 45 47.4 50 KHz
Width tWH - 32 - tCLK
Horizontal Back Porch tHBP 24 50 -
Horizontal Front Porch tHFP 40 80 -
776 790 1063
Period tVT tHP
(894) (948) (1008)
Vertical Valid tVV 768 768 768 tHP
Vertical Blank - tVP- tVV 22 tVP- tVV tHP
57 60 63 Note 1)
Vsync Frequency fV Hz NTSC : 57~63Hz
(47) (50) (53)
5 (PAL : 47~53Hz)
Width tWV - - tHP
(12)
15
Vertical Back Porch tVBP 5 - Hz
(128)
2
Vertical Front Porch tVFP 1 - tHP
(40)
Note :
1. The input of HSYNC & VSYNC signal does not have an effect on normal operation(DE Only Mode).
If you use spread spectrum of EMI, add some additional clock to minimum value for clock margin.
2. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rate and the horizontal frequency
3. Timing should be set based on clock frequency.
Ver. 0.4 10 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-4. Signal Timing Waveforms
0.7VDD
DE, Data
0.3VDD
tCLK
0.5 VDD
DCLK
Valid data
First data Invalid data Pixel 0,0 Pixel 2,0 Invalid data
Valid data
Second data Invalid data Pixel 1,0 Pixel 3,0 Invalid data
DE(Data Enable)
tHV
tHT
1 768
DE(Data Enable)
tVV
tVT
Ver. 0.4 11 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-5. Color Data Reference
The brightness of each primary color(red,green,blue) is based on the 8-bit gray scale data input for the color.
The higher binary input, the brighter the color. Table 7 provides a reference for color versus data input.
Table 7. COLOR DATA REFERENCE
Input Color Data
RED GREEN BLUE
Color
MSB LSB MSB LSB MSB LSB
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red (255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green (255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Basic Blue (255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RED (000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (001) 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED ... ... ... ...
RED (254) 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
GREEN ... ... ... ...
GREEN (254) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
GREEN (255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
BLUE (000) Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BLUE (001) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
BLUE ... ... ... ...
BLUE (254) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
BLUE (255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Ver. 0.4 12 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-6. Power Sequence
3-6-1. LCD Driving circuit
90% 90%
Power Supply For LCD
VLCD 10% 10%
0V
T1 T6
Valid Data
T2 T5
Invalid Invalid
30%
Interface Signal (Tx) Data Data
0V
T3 T4
Option Signal T7 T8
(LVDS_select, OPC_Enable)
T9 Lamp ON
Power for Lamp
Table 9. POWER SEQUENCE
Value
Parameter Unit Notes
Min Typ Max
T1 0.5 - 20 ms
T2 0.5 - - ms 4
T3 200 - - ms 3
T4 200 - - ms 3
T5 0 - - ms
T6 2.0 - - s 5
T7 0.5 - T2 ms 4
T8 0 - - ms 4
T9 T2 + T 3 - 5 s
Note : 1. Please avoid floating state of interface signal at invalid period.
2. When the interface signal is invalid, be sure to pull down the power supply VLCD to 0V.
3. The T3/T4 is recommended value, the case when failed to meet a minimum specification,
abnormal display would be shown. There is no reliability problem.
4. If the on time of signals(Interface signal and Option signals) precedes the on time of Power(V LCD),
it will be happened abnormal display.
5. T6 should be measured after the Module has been fully discharged between power off and on
period.
Ver. 0.4 13 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
3-6-2. On/Off for Inverter
Power Supply For Inverter
24V (typ.)
90%
VBL
10% 0.7V
0V
T1 T2 1000ms (Min) T5 T3 T2 1000ms (Min)
VON/OFF Lamp ON
T4 T4
VBR-A &
Ext. VBR-B T7
3-6-3. Deep condition for Inverter
VBL
VBL : 24V
VBL
Table 9. Power Sequence for Inverter
Values
Parameter Units Remarks
Min Typ Max
T1 20 - - ms 1
T2 500 - - ms
T3 200 - - ms 2
T4 0 - ms
T5 10 - - ms
T6 - - 10 ms VBL(Typ) x 0.8
T7 1000 - - ms 3
Notes : 1. T1 describes rising time of 0V to 24V and this parameter does not applied at restarting time.
2. T4(max) is less than T2.
3. In T7 section, EXTVBR-B is recommended 100%.
Ver. 0.4 14 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and for 30 minutes in a dark environment at
25 2 C. The values are specified at an approximate distance 50cm from the LCD surface at a viewing angle of
) and T equal to 0 .
FIG. 1 shows additional information concerning the measurement equipment and method.
LCD Module Pritchard 880 or
Optical Stage(x,y)
equivalent
50cm
FIG. 1 Optical Characteristic Measurement Equipment and Method
Table 10. OPTICAL CHARACTERISTICS
Ta= 25 2 C, VLCD=12.0V, fV=60Hz, Dclk=72.4MHz, VBR-A =1.65V, Ext. VBR-B =100%
Value
Parameter Symbol Unit Note
Min Typ Max
Contrast Ratio CR 900 1200 - 1
Surface Luminance, white LWH 400 500 cd/m2 2
Luminance Variation G WHITE 5P - - 1.3 3
Gray-to-Gray G to G - 8 12 ms 4
Response Time
Uniformity G G TO G - - 1 5
Rx 0.639
RED
Ry 0.333
Gx 0.292
GREEN
Color Coordinates Gy Typ 0.603 Typ
[CIE1931] Bx -0.03 0.145 +0.03
BLUE
By 0.063
Wx 0.279
WHITE
Wy 0.292
Viewing Angle (CR>10)
x axis, right(I=0 ) Tr 89 - -
x axis, left (I=180 ) Tl 89 - -
degree 6
y axis, up (I=90 ) Tu 89 - -
y axis, down (I=270 ) Td 89 - -
Gray Scale 2.2 7
Ver. 0.4 15 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
Notes :1. Contrast Ratio(CR) is defined mathematically as :
Surface Luminance at all white pixels
CR =
Surface Luminance at all black pixels
It is measured at center 1-point.
2. Surface luminance are determined after the unit has been `ON' and 30min after lighting the
backlight in a dark environment at 25 2 C. Surface luminance is the luminance value at center
1-point across the LCD surface 50cm from the surface with all pixels displaying white.
For more information see the FIG. 2.
3. The variation in surface luminance , G WHITE is defined as :
G WHITE(5P) = Maximum(Lon1,Lon2, Lon3, Lon4, Lon5) / Minimum(Lon1,Lon2, Lon3, Lon4, Lon5)
Where Lon1 to Lon5 are the luminance with all pixels displaying white at 5 locations .
For more information, see the FIG. 2.
4. Response time is the time required for the display to transition from G(N) to G(M) (Rise Time, TrR)
and from G(M) to G(N) (Decay Time, TrD). For additional information see the FIG. 3. (N
Ver. 0.4 20 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
Ver. 0.4 21 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
6. Reliability
Table 13. ENVIRONMENT TEST CONDITION
No. Test Item Condition
1 High temperature storage test Ta= 60 C 240h
2 Low temperature storage test Ta= -20 C 240h
3 High temperature operation test Ta= 50 C 50%RH 240h
4 Low temperature operation test Ta= 0 C 240h
Wave form : random
Vibration level : 1.0G RMS
Vibration test
5 Bandwidth : 10-300Hz
(non-operating)
Duration : X,Y,Z, 10 min
One time each direction
Shock level : 100G
Shock test Waveform : half sine wave, 2ms
6
(non-operating) Direction : X, Y, Z
One time each direction
7 Humidity condition Operation Ta= 40 C ,90%RH
Altitude operating 0 - 15,000 ft
8
storage / shipment 0 - 40,000 ft
Note : Before and after Reliability test, LCM should be operated with normal function.
Ver. 0.4 22 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
7. International Standards
7-1. Safety
a) UL 60065, 7th Edition, dated June 30, 2003, Underwriters Laboratories, Inc.,
Standard for Audio, Video and Similar Electronic Apparatus.
b) CAN/CSA C22.2, No. 60065:03, Canadian Standards Association,
Standard for Audio, Video and Similar Electronic Apparatus.
c) IEC60065:2001, 7th Edition CB-scheme and EN 60065:2002,
Safety requirements for Audio, Video and Similar Electronic Apparatus..
7-2. EMC
a) ANSI C63.4 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and
Electrical Equipment in the Range of 9kHZ to 40GHz. "American National Standards Institute(ANSI),
1992
b) CISPR13 "Limits and Methods of Measurement of Radio interference characteristics of Sound
and Television broadcast receivers and associated equipment"
CISPR22 "Limits and Methods of Measurement of Radio interference characteristics of Information
Technology Equipment" International Special Committee on Radio Interference.
c) EN55013 "Limits and Methods of Measurement of Radio interference characteristics of Sound and
Television broadcast receivers and associated equipment"
EN55022 "Limits and Methods of Measurement of Radio interference characteristics of Information
Technology Equipment" European Committee for Electro Technical Standardization.(CENELEC),
1988(Including A1:2000)
Ver. 0.4 23 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
8. Packing
8-1. Designation of Lot Mark
a) Lot Mark
A B C D E F G H I J K L M
A,B,C : SIZE(INCH)
D : YEAR E : MONTH
F : PANEL CODE G : FACTORY CODE
H : ASSEMBLY CODE I,J,K,L,M : SERIAL NO.
Note
1. YEAR
Year 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010
Mark 1 2 3 4 5 6 7 8 9 0
2. MONTH
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Mark 1 2 3 4 5 6 7 8 9 A B C
b) Location of Lot Mark
Serial No. is printed on the label. The label is attached to the backside of the LCD module.
This is subject to change without prior notice.
8-2. Packing Form
a) LCM quantity in one pallet : 24 pcs
b) Pallet Size : 1030mm X 870mm X 1210mm
Ver. 0.4 24 / 26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC320WXN
Product Specification
9. Precautions
Please pay attention to the followings when you use this TFT LCD module.
9-1. Mounting Precautions
(1)You must mount a module using specified mounting holes (Details refer to the drawings).
(2) You should consider the mounting structure so that uneven force (ex. Twisted stress) is not applied to the
module. And the case on which a module is mounted should have sufficient strength so that external
force is not transmitted directly to the module.
(3) Please attach the surface transparent protective plate to the surface in order to protect the polarizer.
Transparent protective plate should have sufficient strength in order to the resist external force.
(4) You should adopt radiation structure to satis ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
