Image preview - the first page of the document
![Panel_LG_Display_LC370WUH-SBA1_0_[DS]](/pics/5eaf790cd7b82.gif)
>> Download Panel_LG_Display_LC370WUH-SBA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LC370WUH
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 37.0" WUXGA TFT LCD
BUYER General SUPPLIER LG Display Co., Ltd.
LCM MODEL LC370WUD-SBA1 *MODEL LC370WUH
SET MODEL SUFFIX SBA1(RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ H.S.SONG /Team Leader
REVIEWED BY
/ H.I. JANG / Project Leader
PREPARED BY
/ J.H. Lee/ Engineer
Please return 1 copy for your confirmation with TV Product Development Dept.
your signature and comments. LG Display Co., Ltd
Ver. 1.0 1 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC370WUH
Product Specification
CONTENTS
Number ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS 6
3-1 ELECTRICAL CHARACTERISTICS 6
3-2 INTERFACE CONNECTIONS 11
3-3 SIGNAL TIMING SPECIFICATIONS 14
SIGNAL TIMING WAVEFORMS 15
3-4 Data mapping and Timing 17
3-6 POWER SEQUENCE 19
4 OPTICAL SPECIFICATIONS 20
5 MECHANICAL CHARACTERISTICS 24
6 RELIABILITY 27
7 INTERNATIONAL STANDARDS 28
7-1 SAFETY 28
7-2 ENVIRONMENT 28
8 PACKING 29
8-1 DESIGNATION OF LOT MARK 29
8-2 PACKING FORM 29
9 PRECAUTIONS 30
9-1 MOUNTING PRECAUTIONS 30
9-2 OPERATING PRECAUTIONS 30
9-3 ELECTROSTATIC DISCHARGE CONTROL 31
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 31
9-5 STORAGE 31
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 31
Ver. 1.0 2 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC370WUH
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
1.0 Feb.02.27,2009 - Final specification.
Ver. 1.0 3 /38
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LC370WUH
Product Specification
1. General Description
The LC370WUH is a Color Active Matrix Liquid Crystal Display with an integral External Electrode
Fluorescent Lamp(EEFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active
element. It is a transmissive display type which is operating in the normally black mode. It has a 37 inch
diagonally measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel
array). Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.06Bilion (FRC) colors.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
Power (VCC, VDD, VGH, VGL)
Source Control Signal Source Driver Circuit
Gate Control Signal(GCLK,VST) CN1 S1 S1920
(60pin)
Gamma Reference Voltage
G1
mini-LVDS (RGB) for Left drive
Power (VCC, VDD, VGH, VGL)
Source Control Signal TFT - LCD Panel
Gate Control Signal(GLK,VST) CN2 (1920 RGB 1080 pixels)
(60pin)
Gamma Reference Voltage
mini-LVDS (RGB) for Right drive G1080
High Input CN3, 3pin, 16 Lamps/@120 mA
Back light Assembly
High Input CN4, 3pin, 16 Lamps/@120mA
General Features
Active Screen Size 37 inches(940.091mm) diagonal
Outline Dimension 877(H) x 516.8 (V) x 36.4 mm(D) (Typ.)
Pixel Pitch 0.42675 mm x 0.42675 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement
