Image preview - the first page of the document
![Panel_LG_Display_LD550WUD-SCA1_0_[DS]](/pics/5eafc8f52a23d.gif)
>> Download Panel_LG_Display_LD550WUD-SCA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LD550WUD
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 55.0" WUXGA TFT LCD
BUYER General SUPPLIER LG.Display Co., Ltd.
MODEL *MODEL LD550WUD
SUFFIX SCA1 (RoHS Verified)
*When you obtain standard approval,
please use the above model name without suffix.
SIGNATURE SIGNATURE
APPROVED BY APPROVED BY
DATE DATE
/ Y.S. Park /Senior Manager
REVIEWED BY
/ B.Y. Park / Manager
PREPARED BY
/ J.H. Kim / Engineer
Please return 1 copy for your confirmation with PD Product Development Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.0 0 / 43
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LD550WUD
Product Specification
CONTENTS
Number ITEM Page
COVER -
CONTENTS 1
RECORD OF REVISIONS 2
1 GENERAL DESCRIPTION 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL SPECIFICATIONS 5
3-1 ELECTRICAL CHARACTERISTICS 5
3-2 INTERFACE CONNECTIONS 7
3-3 SIGNAL TIMING SPECIFICATIONS 10
3-4 LVDS SIGNAL SPECIFICATIONS 11
3-5 COLOR DATA REFERENCE 14
3-6 POWER SEQUENCE 15
4 OPTICAL SPECIFICATIONS 17
5 MECHANICAL CHARACTERISTICS 21
6 RELIABILITY 24
7 INTERNATIONAL STANDARDS 25
7-1 SAFETY 25
7-2 EMC 25
7-3 ENVIRONMENT 25
8 PACKING 26
8-1 INFORMATION OF LCM LABEL 26
8-2 PACKING FORM 26
9 PRECAUTIONS 27
9-1 MOUNTING PRECAUTIONS 27
9-2 OPERATING PRECAUTIONS 27
9-3 ELECTROSTATIC DISCHARGE CONTROL 27
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 27
9-5 STORAGE 27
9-6 HANDLING PRECAUTIONS FOR PROTECTION FILM 27
9-7 APPROPRIATE CONDITION FOR PUBLIC DISPLAY 27
Ver. 0.0 1 / 43
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LD550WUD
Product Specification
RECORD OF REVISIONS
Revision No. Revision Date Page Description
0.0 Jan. 22. 2010 - Preliminary Specification (First Draft)
Ver. 0.0 2 / 43
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LD550WUD
Product Specification
1. General Description
The LD550WUD is a Color Active Matrix Liquid Crystal Display with an integral Cold Cathode Fluorescent
Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive display type which is operating in the normally black mode. It has a 54.64 inch diagonally
measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.06Bilion colors.
It is intended to support Public Display where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.
Mini-LVDS(RGB)
EEPROM
CN2 Source Driver Circuit
LVDS (41pin)
2Port SCL SDA S1 S1920
LVDS 3,4 G1
Gate Driver Circuit
Timing Controller
+12.0V
CN1 [LVDS Rx + OPC + ODC
LVDS (51pin)
LVDS 1,2
2Port DGA+SSIC+SDRAM TFT - LCD Panel
