Image preview - the first page of the document
![Panel_LG_Display_LP121WX3-TLB1_0_[DS]](/pics/5e7f74cfdb232.gif)
>> Download Panel_LG_Display_LP121WX3-TLB1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 12.1" WXGA TFT LCD
Customer LENOVO SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP121WX3
Suffix TLB1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
G. J. Kwon / G.Manager
/
REVIEWED BY
/
S. R. Kim / Manager
/ PREPARED BY
S. Y. Kim / Engineer
T.S. Yun / Engineer
Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 8
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 9
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 17
6 RELIABLITY 24
7 INTERNATIONAL STANDARDS
7-1 SAFETY 25
7-2 EMC 25
8 PACKING
8-1 DESIGNATION OF LOT MARK 26
8-2 PACKING FORM 26
9 PRECAUTIONS 27
A APPENDIX. Enhanced Extended Display Identification Data 29
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Dec. 22. 2008 - First Draft (Preliminary Specification) 0.0
0.1 Feb. 10. 2009 12 Update the LED Power Sequence 0.1
13 Update the Color Coordinates (RGB Data)
28 Update the EDID Data
Product Code: 0A(h): FA 0B(h): 01
1.0 Mar. 14. 2009 - Final Specification 1.0
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
1. General Description
The LP121WX3 is a Color Active Matrix Liquid Crystal Display with an integral White LED backlight system.
The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display
operating in the normally white mode. This TFT-LCD has 12.1 inches diagonally measured active display
area with WXGA resolution(800 vertical by 1280 horizontal pixel array). Each pixel is divided into Red,
Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the
sub-pixel color is determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more
than 262,144 colors.
The LP121WX3 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP121WX3 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP121WX3 characteristics provide an excellent flat display for office automation products such as Notebook
PC.
'
General Features
Active Screen Size 12.1 inches diagonal
Outline Dimension 275.8 (H) 178.1 (V) 5.5(D, max) mm
Pixel Pitch 0.204 mm 0.204 mm
Pixel Format 1280 horiz. By 800 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 200 cd/m2(Typ.5 point)
Power Consumption Total 3.9 Watt(Typ.) @ LCM circuit 0.8Watt(Typ.), B/L input 3.1Watt(Typ.)
Weight 270g(Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-glare treatment of the front polarizer
RoHS Comply Yes
Ver. 1.0 ZZZISGFOXEQHW
Mar. 14, 2009 4 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 5 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP121WX3 requires two power inputs. The first logic is employed to power the LCD electronics and to
drive the TFT array and liquid crystal. The second backlight is the input about LED BL.with LED Driver.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
LOGIC :
Power Supply Input Voltage VCC 3.0 3.3 3.6 VDC
Power Supply Input Current ICC Mosaic - 250 280 mA 1
Power Consumption Pc Mosaic - 0.8 0.9 W
Power Supply Inrush Current ICC_P - - 1500 mA
LVDS Impedance ZLVDS 90 100 110 2
LED Backlight:
Operating Current per string ILED 5.0 20.0 21.0 mA 3
Operating Voltage per string VLED - 22.1 23.8 V
Power Consumption PBL 3.1 3.4 W 3
Life Time 12,000 Hrs 4
LED Driver
Power Supply Input Voltage VBL+ 7.0 12.0 20.0 V
Frequency FPWM 200 1000 Hz 5
PWM Dimming (Duty) Ratio Don 12.5 - 100 % 6
PWM High Voltage Level VPWM_H 3.0 - 5.3 V
PWM Low Voltage Level VPWM_L 0 - 0.5 V
LED_EN High Voltage VLED_EN_H 3.0 - 5.3 V
LED_EN Low Voltage VLED_EN_L 0 - 0.5 V
Note)
1. The specified current and power consumption are under the Vcc = 3.3V , 25 , fv = 60Hz condition
whereas Mosaic pattern is displayed and fv is the frame frequency.
2. This impedance value is needed to proper display and measured form
LVDS Tx to the mating connector.
3. The specified LED current and power consumption are under the Vled = 12.0V , 25 , Dimming of Max
luminance whereas White pattern is displayed and fv is the frame frequency.
4. The life time is determined as the time at which brightness of LCD is 50% compare to that of minimum
value at Table 7. These LED backlight has 6 strings on it and the typical current of LED's string is base
on typical current at Table 2.
5. This Spec. is not effective at 100% dimming ratio as an exception because it has DC level equivalent
to 0Hz. In spite of acceptable range as defined, the PWM Frequency should be fixed and stable for
more consistent brightness control at any specific level desired.
6. The operation of LED Driver below minimum dimming ratio may cause flickering or reliability issue.
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 6 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs one interface connections, a 40 pin connector is used for the module electronics interface
and the integral backlight system.
The electronics interface connector is a model FI-NXB40SL-HF10 manufactured by JAE.
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
Pin Symbol Description Notes
1 NC No Connection (Reserved for supplier)
2 VCC Power Supply, 3.3V (typical)
3 VCC Power Supply, 3.3V (typical)
4 V EEDID DDC 3.3V power 1, Interface chips
5 NC No Connection 1.1 LCD : SW, SW0612B (LCD Controller)
including LVDS Receiver
6 Clk EEDID DDC Clock 1.2 System : THC63LVD823A or equivalent
7 DATA EEDID DDC Data * Pin to Pin compatible with LVDS
8 RIN 0- Negative LVDS differential data input
2. Connector
9 RIN 0+ Positive LVDS differential data input 2.1 LCD : FI-NXB40SL-HF10, JAE
10 GND Ground it's compatible.
11 RIN 1- Negative LVDS differential data input
2.2 Mating : FI-NX400L or equivalent.
12 RIN 1+ Positive LVDS differential data input 2.3 Connector pin arrangement
13 GND Ground
14 RIN 2- Negative LVDS differential data input
15 RIN 2+ Positive LVDS differential data input
16 GND Ground
17 CLKIN- Negative LVDS differential clock input
18 CLKIN+ Positive LVDS differential clock input
19 GND Ground [LCD Module Rear View]
20 NC No Connection
21 NC No Connection
22 GND Ground
23 NC No Connection
24 NC No Connection
25 GND Ground
26 NC No Connection
27 NC No Connection
28 GND Ground
29 NC No Connection
30 NC No Connection
31 VBL- LED Ground
32 VBL- LED Ground
33 VBL- LED Ground
34 NC No Connection (Reserved for supplier)
35 VBL+ LED Power Supply 6V-20V
36 VBL+ LED Power Supply 6V-20V
37 VBL+ LED Power Supply 6V-20V
38 BLIM PWM for luminance control (200Hz ~ 1000Hz)
39 BL_Enable Backlight On/Off Control
40 NC No Connection (Reserved for supplier)
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 7 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3-3. LVDS Signal Timing Specifications
3-3-1. DC Specification
Symb
Description Min Max Unit Notes
ol
LVDS Differential Voltage |VID| 100 600 mV -
LVDS Common mode Voltage VCM 0.6 1.8 V -
LVDS Input Voltage Range VIN 0.3 2.1 V -
3-3-2. AC Specification
Description Symbol Min Max Unit Notes
85MHz > Fclk
tSKEW - 400 + 400 ps
65MHz
LVDS Clock to Data Skew Margin
65MHz > Fclk
tSKEW - 600 + 600 ps
25MHz
LVDS Clock to Clock Skew Margin (Even
tSKEW_EO - 1/7 + 1/7 Tclk -
to Odd)
Maximum deviation
FDEV - 3 % -
of input clock frequency during SSC
Maximum modulation frequency
FMOD - 200 KHz -
of input clock during SSC
Ver. 1.0 )URP Mar. 14, 2009 8 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
< Clock skew margin between channel >
Freq.
Fmax
Fcenter
Fmin
Time
< Spread Spectrum >
3-3-3. Data Format
1) LVDS 1 Port
RCLK+
RA+/- R3 R2 R1 R0 G0 R5 R4 R3 R2 R1 R0 G0 R5 R4
RB+/- G4 G3 G2 G1 B1 B0 G5 G4 G3 G2 G1 B1 B0 G5
RC+/- B5 B4 B3 B2 DE VSYNC HSYNC B5 B4 B3 B2 DE VSYNC HSYNC
RD+/- G7 G6 R7 R6 X B7 B6 G7 G6 R7 R6 X B7 B6
Previous (N-1)th Cycle Current (Nth ) Cycle Next (N+1)th Cycle
< LVDS Data Format >
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 9 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3-4. Signal Timing Specifications
This is the signal timing required at the input of the User connector. All of the interface signal timing should be
satisfied with the following specifications and specifications of LVDS Tx/Rx for its proper operation.
Table 4. TIMING TABLE
ITEM Symbol Min Typ Max Unit Note
DCLK Frequency fCLK 66.9 69.3 73.9 MHz
Period Thp 1376 1408 1480
Hsync Width tWH 24 32 40 tCLK
Width-Active tWHA 1280 1280 1280
Period tVP 810 820 832
Vsync
Width tWV 2 4 6 tHP
Width-Active tWVA 800 800 800
Horizontal back porch tHBP 56 72 96
tCLK
Data Horizontal front porch tHFP 16 24 64
Enable Vertical back porch tVBP 6 12 18
tHP
Vertical front porch tVFP 2 4 8
Condition : VCC =3.3V
3-5. Signal Timing Waveforms
High: 0.7VCC
Data Enable, Hsync, Vsync
Low: 0.3VCC
tCLK
DCLK 0.5 Vcc
tHP
Hsync t
WH
tHBP tWHA tHFP
Data Enable
tVP
tWV
Vsync tVFP
tVBP tWVA
Data Enable
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 10 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3-6. Color Input Data Reference
The brightness of each primary color (red,green and blue) is based on the 6-bit gray scale data input for the
color ; the higher the binary input, the brighter the color. The table below provides a reference for color
versus data input.
Table 5. COLOR DATA REFERENCE
Input Color Data
RED GREEN BLUE
Color
MSB LSB MSB LSB MSB LSB
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Basic Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RED (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (01) 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
RED ... ... ... ...
RED (62) 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (01) 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
GREEN ... ... ... ...
GREEN (62) 0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
GREEN (63) 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
BLUE (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BLUE (01) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
BLUE ... ... ... ...
BLUE (62) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
BLUE (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Ver. 1.0 )URP Mar. 14, 2009 11 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
3-7. Power Sequence
90% 90%
Power Supply Input
VCC
0V 10% 10%
T3 T7 T4
T1 T2 Valid Data
Interface Signal, Vi
LVDS
0V
T5 T6
LED on/off control Signal
0V (Off)
LED_EN
T9 T10
Dimming control signal Valid Data
Of LED BL 0V (Low)
PWM
T8 T11
90%
LED input Voltage
VLED 0V 10%
Table 6. POWER SEQUENCE TABLE
Value
Parameter Units
Min. Typ. Max.
T1 0.5 - 10 ms
T2 0 - 50 ms
T3 0 - 50 ms
T4 400 - - ms
T5 200 - - ms
T6 200 - - ms
T7 3 - 10 ms
T8 10 - - ms
T9 10 - - ms
T10 0 - - ms
T11 10 - - ms
Note)
1. Valid Data is Data to meet "3-3. LVDS Signal Timing Specifications"
2. Please avoid floating state of interface signal at invalid period.
3. When the interface signal is invalid, be sure to pull down the power supply for LCD VCC to 0V.
4. LED power must be turn on after power supply for LCD and interface signal are valid.
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 12 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and stable for approximately 30 minutes in
a dark environment at 25qC. The values specified are at an approximate distance 50cm from the LCD surface
at a viewing angle of ) and 4 equal to 0q.
FIG. 1 presents additional information concerning the measurement equipment and method.
FIG. 1 Optical Characteristic Measurement Equipment and Method
LCD Module Pritchard 880 or
Optical Stage(x,y)
equivalent
50cm
Table 7. OPTICAL CHARACTERISTICS
Ta=25qC, VCC=3.3V, fV=60Hz, fCLK= 69.3MHz, ILED= 20.0mA
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR - 300 - 1
Surface Luminance, white LWH 170 200 - cd/m2 2
Luminance Variation G WHITE - - 1.6 3
Response Time TrR+ TrD 16 ms 4
Color Coordinates
RED RX 0.562 0.592 0.622
RY 0.321 0.351 0.381
GREEN GX 0.304 0.334 0.364
GY 0.519 0.549 0.579
BLUE BX 0.124 0.154 0.184
BY 0.100 0.130 0.160
WHITE WX 0.283 0.313 0.343
WY 0.299 0.329 0.359
Viewing Angle 5
x axis, right()=0q) 4r 40 - - degree
x axis, left ()=180q) 4l 40 - - degree
y axis, up ()=90q) 4u 10 - - degree
y axis, down ()=270q) 4d 30 - - degree
Gray Scale 6
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 13 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
Note)
1. Contrast Ratio(CR) is defined mathematically as
Surface Luminance with all white pixels
Contrast Ratio =
Surface Luminance with all black pixels
2. Surface luminance is the average of 5 point across the LCD surface 50cm from the surface with
all pixels displaying white. For more information see FIG 1.
LWH = Average(L1,L2, ... L5)
3. The variation in surface luminance , The panel total variation (G WHITE) is determined by measuring LN
at each test position 1 through 13 and then defined as followed numerical formula.
For more information see FIG 2.
Maximum(L1,L2, ... L13)
G WHITE =
Minimum(L1,L2, ... L13)
4. Response time is the time required for the display to transition from white to black (rise time, TrR) and
from black to white(Decay Time, TrD). For additional information see FIG 3.
5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD surface. For more information see FIG 4.
6. Gray scale specification * fV = 60Hz
Gray Level Luminance [%] (Typ)
L0 0.22
L7 2.77
L15 8.65
L23 16.4
L31 25.4
L39 39.3
L47 57.2
L55 77.9
L63 100
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 14 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
FIG. 2 Luminance
H
A D
L6 L7 L8 H,V : ACTIVE AREA
C
A : H/4 mm
B : V/4 mm
L2 L3 C : 10 mm
D : 10 mm
B
POINTS : 13 POINTS
V
L9 L1 L10
Center Point
L4 L5
L11 L12 L13
FIG. 3 Response Time
The response time is defined as the following figure and shall be measured by switching the input signal
for "black" and "white".
TrR TrD
%
100
90
Optical
Response
10
0 white white
black
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 15 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
5. Mechanical Characteristics
The contents provide general mechanical characteristics for the model LP121WX3. In addition the figures
in the next page are detailed mechanical drawing of the LCD.
Horizontal 275.8 r 0.5mm
Outline Dimension Vertical 178.1 r 0.5mm
Thickness 5.5 (Max)
Horizontal 264.8 r 0.5mm
Bezel Area
Vertical 166.6 r 0.5mm
Horizontal 261.12 r 0.3mm
Active Display Area
Vertical 163.20 r 0.3mm
Weight 270g(Max)
Surface Treatment Anti-glare treatment of the front polarizer
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 16 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 17 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 18 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
[ DETAIL DESCRIPTION OF SIDE MOUNTING SCREW ]
*Screw Torque (4 point): Max. 2Kgf.Cm
*Mounting SCREW Depth : 1.8mm max
Notes : 1. Screw plated through the method of non-electrolytic nickel plating is preferred
to reduce possibility that results in vertical and/or horizontal line defect due to
the conductive particles from screw surface.
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 19 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.(Appendix)
1
Gap check for securing the enough gap between LCM
and System cover.
1.Rear side of LCM is sensitive against external stress,and previous check
about interference is highly needed.
Define 2.In case there is something from system cover comes into the boundary
above,mechanical interference may cause the FOS defects.
(Eg:Ripple,White spot..)
2 Check if antenna cable is sufficiently apart from T-CON of LCD Module.
Define
NO GOOD GOOD
1.If system antenna is overlapped with T-CON,it might be cause the noise.
Ver. 1.0 )URP ZZZISGFOXEQHW
Mar. 14, 2009 20 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP121WX3
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.
Gap check for securing the enough gap between LCM
3
and System hinge.
1.At least 2.0mm of gap needs to be secured to prevent the shock
Define related defects.
2."L" type of hinge is recommended than "I" type under shock test.
4 Checking the path of the System wire.
#6 #5 #4 #3 #2 #1
Good Ok Bad
1.COF area needs to be handled with care.
2.GOOD ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
