Image preview - the first page of the document
![Panel_LG_Display_LP133WH2-TLA3_0_[DS]](/pics/5eafd95cceee1.gif)
>> Download Panel_LG_Display_LP133WH2-TLA3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 13.3" HD TFT LCD
BUYER Acer SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP133WH2
Suffix TLA3
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE
APPROVED BY SIGNATURE
K. J. KWON / S.Manager
/ REVIEWED BY
G. J. Han / Manager
/
PREPARED BY
/
C. Y. Kim / Engineer
S. C. Jung / Engineer
Product Engineering Dept.
Please return 1 copy for your confirmation with LG Display Co., Ltd
your signature and comments.
Ver. 1.0 31, Mar., 2009 1/ 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 SIGNAL TIMING SPECIFICATIONS 10
3-4 SIGNAL TIMING WAVEFORMS 10
3-5 COLOR INPUT DATA REFERNECE 11
3-6 POWER SEQUENCE 12
4 OPTICAL SFECIFICATIONS 13
5 MECHANICAL CHARACTERISTICS 16
6 RELIABLITY 21
7 INTERNATIONAL STANDARDS
7-1 SAFETY 22
7-2 EMC 22
8 PACKING
8-1 DESIGNATION OF LOT MARK 23
8-2 PACKING FORM 23
9 PRECAUTIONS 24
A APPENDIX A. Enhanced Extended Display Identification Data 26
Ver. 1.0 31, Mar., 2009 2/ 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 4. Feb, 2009 - First Draft 0.0
0.1 16. Mar, 2009 13 Updated Color Coordinates. 0.1
14 Updated Gray scale
19 Updated Rear view
25-27 Updated EDID (Added Color Coordinates)
1.0 31. Mar, 2009 - Final Draft 1.0
Ver. 1.0 31, Mar., 2009 3/ 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
1. General Description
The LP133WH2 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 13.3 inches diagonally measured active display area with HD
resolution(1366 horizontal by 768 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors.
The LP133WH2 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP133WH2 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP133WH2 characteristics provide an excellent flat display for office automation products such as Notebook
PC.
LVDS & 1
Timing
CN1 User connector 40 Pin
Control Gate Driver
Block TFT-LCD Panel
(1366 x 768)
POWE
(LOG_B type)
R 768
1 1366
BLOCK
Source Driver Circuit
EDID
BLOCK
LED Backlight Ass'y
TBD LEDs X TBD strings
Control & Data Power EDID signal & Power
General Features
Active Screen Size 13.3 inches diagonal
Outline Dimension 306.3(Typ. H) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
