Image preview - the first page of the document
![Panel_LG_Display_LP133WH2-TLL1_0_[DS]](/pics/5eafd9a84098d.gif)
>> Download Panel_LG_Display_LP133WH2-TLL1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 13.3" HD TFT LCD
BUYER ACER SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP133WH2
Suffix TLL1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE
APPROVED BY SIGNATURE
N. J. Seong / Manager
/ REVIEWED BY
S. S. Han / Engineer
/
PREPARED BY
/
H. S. Kim / Engineer
H. S. Jung / Engineer
Product Engineering Dept.
Please return 1 copy for your confirmation with LG Display Co., Ltd
your signature and comments.
Ver. 1.0 Mar. 11. 2010 1/ 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6-7
3-2 INTERFACE CONNECTIONS 8
3-3 LVDS SIGNAL TIMING SPECIFICATION 9-10
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14-16
5 MECHANICAL CHARACTERISTICS 17-20
6 RELIABLITY 21
7 INTERNATIONAL STANDARDS
7-1 SAFETY 22
7-2 EMC 22
7-3 Environment 22
8 PACKING
8-1 DESIGNATION OF LOT MARK 23
8-2 PACKING FORM 23
9 PRECAUTIONS 24-25
A APPENDIX. Enhanced Extended Display Identification Data 26-28
Ver. 1.0 Mar. 11. 2010 2/ 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP133WH2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Sep. 24. 2009 - First Draft (Preliminary Specification) -
6 Update the Electrical Characteristics Spec.
9 Change the LVDS Signal Timing DC specifications
0.1 Nov. 17. 2009 13 Update the Power Sequence -
17 Add detail outline dimension (Horizontal & Vertical)
20 Add LED Block Diagram
0.2 Dec. 01. 2009 26~28 Update EEDID Table 0.0
6 Update the Electrical Characteristics Spec. (Power Consumption)
0.3 Jan. 14. 2010 0.0
8 Change the Pin Configuration (#19 : Ground No Connection)
14 Update Optical Characteristics
15 Update Gray scale specification
0.4 Feb. 09. 2010 0.1
26~28 Update EEDID Table
23 Update Packing Form
6 Update the Electrical Characteristics Spec. (Power Consumption)
1.0 Mar. 10. 2010 23 Update Packing Form (30 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
