Image preview - the first page of the document
![Panel_LG_Display_LP140WD2-TLB1_0_[DS]](/pics/5eafdb46f3cbb.gif)
>> Download Panel_LG_Display_LP140WD2-TLB1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP140WD2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 14.0"W HD+ TFT LCD
Customer LENOVO SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP140WD2
Suffix TLB1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
S. R. Kim / S.Manager
/
REVIEWED BY
/
J. S. Park / Manager
/ PREPARED BY
C. W. Lee/ Engineer
D. J. Lee/ Engineer
Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 1.0 Dec. 16. 2010 1 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WD2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6-7
3-2 INTERFACE CONNECTIONS 8
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 9-10
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14-16
5 MECHANICAL CHARACTERISTICS 17-19
6 RELIABLITY 20
7 INTERNATIONAL STANDARDS 21
7-1 SAFETY
7-2 EMC
8 PACKING 22
8-1 DESIGNATION OF LOT MARK
8-2 PACKING FORM
8-3 LABEL DESCRIPTION
9 PRECAUTIONS 24
A APPENDIX A. Enhanced Extended Display Identification Data 26-28
Ver. 1.0 Dec. 16. 2010 2 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WD2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Oct. 18, 2010 All First Draft (Preliminary Specification) 0.1
0.1 Oct. 21, 2010 13 Update Power Sequence
14 Update Color Coordinates
26-28 Update EDID 0.3
0.2 Dec. 10. 2010 4 Update General Description 0.3
6 Update Electrical Specifications
11 Update TIMING TABLE
14 Update Optical Specification
15 Update Gray scale specification
0.3 Dec. 16. 2010 6 Update Electrical Specifications 0.3
Ver. 1.0 Dec. 16. 2010 3 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WD2
Liquid Crystal Display
Product Specification
1. General Description
The LP40WD2 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 14.0 inches diagonally measured active display area with HD+
resolution (1600 horizontal by 900 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors. The LP140WD2 has been designed to apply the interface method that enables low power, high
speed, low EMI. The LP140WD2 is intended to support applications where thin thickness, low power are
critical factors and graphic displays are important. In combination with the vertical arrangement of the sub-
pixels, the LP140WD2 characteristics provide an excellent flat display for office automation products such
as Notebook PC.
EEPROM Block
for EDID
EEPROM Block 1 1600
for Tcon Operating
User connector
TFT-LCD Panel
LVDS
Timing Control (HD+, TN)
2port (Tcon) Block
900
DVCC TCLKs
40
AVCC, AVDD
Pin
VCC Power VGH, VGL, GMA
Source Driver
(Bottom Bent)
Block GSP, GSC, GOE
VLED LED Driver VOUT_LED
LED_EN FB1~4
LED Backlight Ass'y
PWM Block
Control & Data Power EDID signal & Power
General Features
Active Screen Size 14.0 inches diagonal
Outline Dimension 322.3(H, typ) 187.1(V, typ) 3.6(D,max) [mm]
Pixel Pitch 0.1932mm 0.1932 mm
Pixel Format 1600 horiz. By 900 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 250 cd/m 2(Typ.5 point)
Power Consumption Total 4.81 Watt (Typ.) @ Logic input 0.91Watt (Typ.), B/L input 3.9 Watt (Typ.)
Weight 320g (Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-glare treatment of the front polarizer(3H)
RoHS Comply Yes
Ver. 1.0 Dec. 16. 2010 4 / 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WD2
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
