Image preview - the first page of the document
![Panel_LG_Display_LP140WH1-TPD1_0_[DS]](/pics/5e81ecba29674.gif)
>> Download Panel_LG_Display_LP140WH1-TPD1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP140WH1
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 14.0"W HD TFT LCD
Customer HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP140WH1
Suffix TPD1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
K. J. Kwon / G.Manager
/
REVIEWED BY
/
M. J. Lee / Manager
/ PREPARED BY
J. Y. Lee / Engineer
Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.3 Dec. 11, 2009 1 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WH1
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6-7
3-2 INTERFACE CONNECTIONS 8
3-3 eDP SIGNAL TIMING SPECIFICATION 9
3-3 SIGNAL TIMING SPECIFICATIONS 10
3-4 SIGNAL TIMING WAVEFORMS 10
3-5 COLOR INPUT DATA REFERNECE 11
3-6 POWER SEQUENCE 12
4 OPTICAL SFECIFICATIONS 13-15
5 MECHANICAL CHARACTERISTICS 16-19
6 RELIABLITY 20
7 INTERNATIONAL STANDARDS
7-1 SAFETY 21
7-2 EMC 21
8 PACKING
8-1 DESIGNATION OF LOT MARK 22
8-2 PACKING FORM 22
9 PRECAUTIONS 23-24
A APPENDIX. Enhanced Extended Display Identification Data 28-30
Ver. 0.3 Dec. 11, 2009 2 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WH1
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Feb. 10, 2009 - First Draft (Preliminary Specification) -
4 Block Diagram update
6 Electrical Characteristics update
0.1 Jun.09. 2009 12 Power Sequence update 0.1
13~14 Optical Specification update
28~30 EDID Update
0.2 Jul.14. 2009 28~30 EDID Update 0.2
0.3 Dec.11.2009 6 Electrical Specifications update
12 Signal Timing Specifications update
13~14 Optical Specification update
28~30 EDID Update 0.3
Ver. 0.3 Dec. 11, 2009 3 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WH1
Liquid Crystal Display
Product Specification
1. General Description
The LP140WH1 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 14.0 inches diagonally measured active display area with HD
resolution(768 vertical by 1366 horizontal pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors.
The LP140WH1 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP140WH1 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP140WH1 characteristics provide an excellent flat display for office automation products such as Notebook
PC.
$8;
eDP Timing Control 1 1366
eDP (Tcon) Block
1Lane
User conne
TFT-LCD Panel
(HD, GIP, TN)
ector
DVCC TCLKs
768
30 Mini-LVDS
Power AVCC, AVDD
Pin
VCC Source Driver
VGH, VGL, GMA
Block (Bottom Bent)
GIP CLKs, DSC
VOUT_LED
VLED LED Driver LED Backlight Ass'y
LED_EN FB1~6
PWM Block
&RQWURO 'DWD 3RZHU (',' VLJQDO 3RZHU
General Features
Active Screen Size 14.0 inches diagonal
Outline Dimension 323.5(H, typ) 192.0(V, typ) 5.2(D,max) [mm]
Pixel Pitch 0.2265mm 0.2265 mm
Pixel Format 1366 horiz. By 768 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 200 cd/m2(Typ.5 point)
Power Consumption Total 4.2 Watt(Typ..) @ LCM circuit 1.6 Watt(Typ..), B/L input 2.8 Watt(Typ.. with Driver)
Weight 350g (Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-Glare treatment of the front polarizer
RoHS Comply Yes
Ver. 0.3 Dec. 11, 2009 4 / 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP140WH1
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
