Image preview - the first page of the document
![Panel_LG_Display_LP141WX5-TLP3_0_[DS]](/pics/5eafdef72adeb.gif)
>> Download Panel_LG_Display_LP141WX5-TLP3_0_[DS] documenatation <<
Text preview - extract from the document
LP141WX5
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 14.1" WXGA TFT LCD
Customer General SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP141WX5
Suffix TLP3
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
H. S. Kim / G.Manager
/
REVIEWED BY
/
M. J. Lee / Manager
/ PREPARED BY
J. P. Lee / Engineer
D. J. Lee / Engineer
Please return 1 copy for your confirmation with Products Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 1.1 Oct. 15, 2010 1 / 33
LP141WX5
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 9
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 18
6 RELIABLITY 25
7 INTERNATIONAL STANDARDS
7-1 SAFETY 26
7-2 EMC 26
8 PACKING
8-1 DESIGNATION OF LOT MARK 27
8-2 PACKING FORM 27
9 PRECAUTIONS 28
A APPENDIX. Enhanced Extended Display Identification Data 30
Ver. 1.1 Oct. 15, 2010 2 / 33
LP141WX5
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
1.0 Oct. 06. 2010 - Final Specification 1.0
6 Electrical Characteristics update
20 Rear View Drawing update (Label drawing update)
28 Label Description update
1.1 Oct. 15. 2010 20 Connector position update
Ver. 1.1 Oct. 15, 2010 3 / 33
LP141WX5
Liquid Crystal Display
Product Specification
1. General Description
The LP141WX5 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 14.1 inches diagonally measured active display area with
WXGA resolution (1280 horizontal by 800 vertical pixel array). Each pixel is divided into Red, Green and
Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel
color is determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than
262,144 colors. The LP141WX5 has been designed to apply the interface method that enables low power,
high speed, low EMI. The LP141WX5 is intended to support applications where thin thickness, low power
are critical factors and graphic displays are important. In combination with the vertical arrangement of the
sub-pixels, the LP141WX5 characteristics provide an excellent flat display for office automation products
such as Notebook PC.
Timing Control
LVDS
1port (Tcon) Block
TCLKs
Source Driver
User connector
DVCC (Top Bent)
DVCC, AVDD
Power VGH, VGL, GMA
VCC
GIP CLKs, DSC 1 1280
Block
EEPROM Block TFT-LCD Panel
40 for EDID
(WXGA, GIP, TN)
Pin
800
VLED LED Driver VOUT_LED
SMBus
LED_EN Block FB1~6 LED Backlight Ass'y
PWM
Control & Data Power EDID signal & Power
General Features
Active Screen Size 14.1 inches diagonal
Outline Dimension 319.5(H,Typ.) ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
