Image preview - the first page of the document
![Panel_LG_Display_LP171WU7-TLB1_0_[DS]](/pics/5eafe5c094567.gif)
>> Download Panel_LG_Display_LP171WU7-TLB1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP171WU7
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.1" WUXGA TFT LCD
BUYER HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP171WU7
Suffix TLB1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
H. S. Kim / S.Manager
/
REVIEWED BY
/ M. J. Lee / Manager
/ PREPARED BY
S. U. Kim / Engineer
Please return 1 copy for your confirmation with Product Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.5 Dec. 28. 2009 0/ 33
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP171WU7
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 0
CONTENTS 1
RECORD OF REVISIONS 2
1 GENERAL DESCRIPTION 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 5
3-2 INTERFACE CONNECTIONS 7
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 8
3-4
34 SIGNAL TIMING SPECIFICATIONS 10
3-5 SIGNAL TIMING WAVEFORMS 10
3-6 COLOR INPUT DATA REFERNECE 11
3-7 POWER SEQUENCE 12
4 OPTICAL SFECIFICATIONS 13
5 MECHANICAL CHARACTERISTICS 16
6 RELIABLITY 26
7 INTERNATIONAL STANDARDS
7-1 SAFETY 27
7-2 EMC 27
7-3 Environment 27
8 PACKING
8-1 DESIGNATION OF LOT MARK 28
8-2 PACKING FORM 28
9 PRECAUTIONS 29
A APPENDIX A. Enhanced Extended Display Identification Data 31
Ver. 0.5 Dec. 28. 2009 1/ 33
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP171WU7
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 10. Jul. 2009 - First Draft TBD
0.1 24. Nov. 2009 29.30.31 Update EDID 0.1
0.2 27. Nov. 2009 29.30.31 Update EDID 0.2
0.3 7.Dec. 2009 5 Electrical Characteristics ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
