Image preview - the first page of the document
![Panel_LG_Display_LP173WD1-TLA3_0_[DS]](/pics/5eafe634862d5.gif)
>> Download Panel_LG_Display_LP173WD1-TLA3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.3" HD+ TFT LCD
BUYER Acer SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP173WD1
Suffix TLA3
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE
APPROVED BY SIGNATURE
K. J. KWON / S.Manager
/ REVIEWED BY
G. J. Han / Manager
/
PREPARED BY
/
C. Y. Kim / Engineer
S. W. Kim / Engineer
Product Engineering Dept.
Please return 1 copy for your confirmation with LG Display Co., Ltd
your signature and comments.
Ver. 1.0 9. Sep, 2009 1/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER
CONTENTS 1
RECORD OF REVISIONS 2
1 GENERAL DESCRIPTION 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 5
3-2 INTERFACE CONNECTIONS 6
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 8
3-4 SIGNAL TIMING SPECIFICATIONS 10
3-5 SIGNAL TIMING WAVEFORMS 10
3-6 COLOR INPUT DATA REFERNECE 11
3-7 POWER SEQUENCE 12
4 OPTICAL SFECIFICATIONS 12
5 MECHANICAL CHARACTERISTICS 16
6 RELIABLITY 23
7 INTERNATIONAL STANDARDS
7-1 SAFETY 24
7-2 EMC 24
8 PACKING
8-1 DESIGNATION OF LOT MARK 25
8-2 PACKING FORM 25
9 PRECAUTIONS 26
A APPENDIX A. Enhanced Extended Display Identification Data 28
Ver. 1.0 9. Sep, 2009 2/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
1.0 Sep. 9, 2009 - First Draft 1.0
Ver. 1.0 9. Sep, 2009 3/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
1. General Description
The LP173WD1 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 17.3 inches diagonally measured active display area with
WHD+ resolution(1600 horizontal by 900 vertical pixel array). Each pixel is divided into Red, Green and
Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel
color is determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than
262,144 colors.
The LP173WD1 has been designed to apply the interface method that enables low power, high speed, low
EMI.
The LP173WD1 is intended to support applications where thin thickness, low power are critical factors and
graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP173WD1 characteristics provide an excellent flat display for office automation products such as Notebook
PC.
'
General Features
Active Screen Size 17.3 inches diagonal
Outline Dimension 398.1(H, Typ.) 232.8(V, Typ.) 6.0(D, Max.) mm
Pixel Pitch 0.23868 X 0.23868 mm
Pixel Format 1600 horiz. by 900 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 220 cd/m2(Typ., @ILED=21mA)
Power Consumption Total 7.2W(Typ.) Logic : 1.5 W (Typ.@Mosaic), B/L : 5.7W (Typ.)
Weight 570g (Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Glare treatment of the front Polarizer
Ver. 1.0 9. Sep, 2009 4/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 1.0 9. Sep, 2009 5/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP173WD1 requires two power inputs. The first logic is employed to power the LCD electronics and to
drive the TFT array and liquid crystal. The second backlight is the input about LED BL.with LED Driver.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
LOGIC :
Power Supply Input Voltage VCC 3.0 3.3 3.6 V
Power Supply Input Current ICC - 455 515 mA 1
Power Consumption PCC - 1.5 1.7 W 1
Power Supply Inrush Current ICC_P - - 1800 mA
LVDS Impedance ZLVDS 90 100 110 2
BACKLIGHT : ( with LED Driver)
LED Power Input Voltage VLED 7.0 12.0 20.0 V
LED Power Input Current ILED - 21 25 mA 3
LED Power Comsumption PLED - 5.7 6.0 W 3
LED Power Inrush Current ILED_P - - 1800 mA
PWM Dimming (Duty) Ratio - 5 - 100 % 4
PWM Frequency FPWM 200 1500 Hz 5
PWM High Level Voltage VPWM_H 2.1 3.3 5 V
PWM Low Level Voltage VPWM_L 0 - 0.8 V
LED_EN High Voltage VLED_EN_H 2.1 3.3 5 V
LED_EN Low Voltage VLED_EN_L 0 - 0.8 V
Life Time 10,000 - - Hrs 6
Note)
1. The specified Icc current and power consumption are under the Vcc = 3.3V , 25 , fv = 60Hz condition
whereas Mosaic pattern is displayed and fv is the frame frequency.
2. This impedance value is needed to proper display and measured form
LVDS Tx to the mating connector.
3. The specified LED current and power consumption are under the Vled = 12.0V , 25 , Dimming of Max
luminance whereas White pattern is displayed and fv is the frame frequency.
4. The operation of LED Driver below minimum dimming ratio may cause flikering or relaibility issue.
5. This Spec. is not effective at 100% dimming ratio as an exception because it has DC level equivalent
to 0Hz. In spite of acceptable range as defined, the PWM Frequency should be fixed and stable for
more consistent brightness control at any specific level desired.
6. The life time is determined as the time at which brightness of LCD is 50% compare to that of initial value
at the typical LED current. These LED backlight has 6 strings on it and the typical current of LED's string
is base on 21mA.
Ver. 1.0 9. Sep, 2009 6/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs two interface connections, a 40 pin connector is used for the module electronics interface
and the other connector is used for the integral backlight system.
The electronics interface connector is a model UJU 20455-040E manufactured by UJU.
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
1. LCD :
SW, SW0617(LCD Controller)
Including LVDS Receiver.
2. System : SiWLVDSRx or equivalent
* Pin to Pin compatible with LVDS
UJU 20455-040E or equivalent
20345-#40E-## series
or equivalent
40 1
Ver. 1.0 9. Sep, 2009 7/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3-3. LVDS Signal Timing Specifications
3-3-1. DC Specification
Symb
Description Min Max Unit Notes
ol
LVDS Differential Voltage |VID| 100 600 mV -
LVDS Common mode Voltage VCM 0.6 1.8 V -
LVDS Input Voltage Range VIN 0.3 2.1 V -
3-3-2. AC Specification
Description Symbol Min Max Unit Notes
85MHz > Fclk
tSKEW - 400 + 400 ps
65MHz
LVDS Clock to Data Skew Margin
65MHz > Fclk
tSKEW - 600 + 600 ps
25MHz
LVDS Clock to Clock Skew Margin (Even
tSKEW_EO - 1/7 + 1/7 Tclk -
to Odd)
Maximum deviation
FDEV - 3 % -
of input clock frequency during SSC
Maximum modulation frequency
FMOD - 200 KHz -
of input clock during SSC
Ver. 1.0 9. Sep, 2009 8/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
< Clock skew margin between channel >
Freq.
Fmax
Fcenter
Fmin
Time
< Spread Spectrum >
3-3-3. Data Format
1) LVDS 2 Port
< LVDS Data Format >
Ver. 1.0 9. Sep, 2009 9/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3-4. Signal Timing Specifications
This is the signal timing required at the input of the User connector. All of the interface signal timing should be
satisfied with the following specifications and specifications of LVDS Tx/Rx for its proper operation.
Table 5. TIMING TABLE
Period
Width
Width-Active
Period
Width
Width-Active
Horizontal back porch HBP
Horizontal front porch
Vertical back porch
Vertical front porch
3-5. Signal Timing Waveforms Condition : VCC =3.3V
High: 0.7VCC
Low: 0.3VCC
tHP
Hsync t
WH
tHBP tWHA tHFP
Date Enable
tVP
tWV
Vsync tVFP
tVBP tWVA
Date Enable
Ver. 1.0 9. Sep, 2009 10/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3-6. Color Input Data Reference
The brightness of each primary color (red,green and blue) is based on the 6-bit gray scale data input for the
color ; the higher the binary input, the brighter the color. The table below provides a reference for color
versus data input.
Table 6. COLOR DATA REFERENCE
Input Color Data
RED GREEN BLUE
Color
MSB LSB MSB LSB MSB LSB
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Basic Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RED (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (01) 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
RED ... ... ... ...
RED (62) 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (01) 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
GREEN ... ... ... ...
GREEN (62) 0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
GREEN (63) 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
BLUE (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BLUE (01) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
BLUE ... ... ... ...
BLUE (62) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
BLUE (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Ver. 1.0 9. Sep, 2009 11/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
3-7. Power Sequence
90% 90%
Power Supply Input
VCC
0V 10% 10%
T5 T6 T7
T1 T2 Valid Data
Interface Signal, Vi
LVDS
0V
T3 T4
LED input Voltage
VLED T8 T11
0V
Dimming control signal Valid Data
Of LED BL 0V (Low)
PWM
T9 T10
LED on/off control Signal
0V (Off)
LED_EN
Table 6. POWER SEQUENCE TABLE
Value
Parameter Units
Min. Typ. Max.
T1 0.5 - 10 ms
T2 0 - 50 ms
T3 200 - - ms
T4 200 - - ms
T5 0 - 50 ms
T6 3 - 10 ms
T7 400 - - ms
T8 50 - 100 ms
T9 0 - 100 ms
T10 0 - 100 ms
T11 50 - 100 ms
Note)
1. Valid Data is Data to meet "3-3. LVDS Signal Timing Specifications"
2. Please avoid floating state of interface signal at invalid period.
3. When the interface signal is invalid, be sure to pull down the power supply for LCD VCC to 0V.
4. LED power must be turn on after power supply for LCD and interface signal are valid.
Ver. 1.0 9. Sep, 2009 12/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and stable for approximately 20 minutes in
a dark environment at 25qC. The values specified are at an approximate distance 50cm from the LCD surface
at a viewing angle of ) and 4 equal to 0q.
FIG. 1 presents additional information concerning the measurement equipment and method.
FIG. 1 Optical Characteristic Measurement Equipment and Method
LCD Module Equipment
Optical Stage(x,y)
500mm 50mm
Table 8. OPTICAL CHARACTERISTICS Ta=25qC, VCC=3.3V, fV=60Hz, fCLK= 97.75MHz, ILED =22 mA
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR 400 600 - 1
Surface Luminance, white LWH 190 220 - cd/m2 2
Luminance Variation G WHITE 1.4 1.6 3
Response Time - 8 16 ms 4
Color Coordinates
RED RX TBD TBD TBD
RY TBD TBD TBD
GREEN GX TBD TBD TBD
GY TBD TBD TBD
BLUE BX TBD TBD TBD
BY TBD TBD TBD
WHITE WX 0.283 0.313 0.343
WY 0.299 0.329 0.359
Viewing Angle 5
x axis, right()=0q) 4r 40 degree
x axis, left ()=180q) 4l 40 degree
y axis, up ()=90q) 4u 10 degree
y axis, down ()=270q) 4d 30 degree
Gray Scale 6
Color Gamut - 60 %
Ver. 1.0 9. Sep, 2009 13/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Note)
1. Contrast Ratio(CR) is defined mathematically as
Surface Luminance with all white pixels
Contrast Ratio =
Surface Luminance with all black pixels
2. Surface luminance is the average of 5 point across the LCD surface 50cm from the surface with
all pixels displaying white. For more information see FIG 1.
LWH = Average(L1,L2, ... L5)
3. The variation in surface luminance , The panel total variation (G WHITE) is determined by measuring LN
at each test position 1 through 13 and then defined as followed numerical formula.
For more information see FIG 2.
Maximum(L1,L2, ... L13)
G WHITE =
Minimum(L1,L2, ... L13)
4. Response time is the time required for the display to transition from white to black (rise time, TrR) and
from black to white(Decay Time, TrD). For additional information see FIG 3.
5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD surface. For more information see FIG 4.
6. Gray scale specification * fV = 60Hz
Gray Level Luminance [%] (Typ)
L0
L7
L15
L23
L31
L39
L47
L55
L63
Ver. 1.0 9. Sep, 2009 14/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
FIG. 2 Luminance
H
A D
L6 L7 L8
C
H,V : ACTIVE AREA
A : H/4 mm
L2 L3 B : V/4 mm
C : 10 mm
B
D : 10 mm
POINTS : 13 POINTS
V
L9 L1 L10
Center Point
L4 L5
L11 L12 L13
FIG. 3 Response Time
The response time is defined as the following figure and shall be measured by switching the input signal
for "black" and "white".
TrR TrD
%
100
90
Optical
Response
10
0 white white
black
FIG. 4 Viewing angle Normal
Eye Y
I = 90 q , Up
I = 180 q ,
Left T
I
I = 0q ,
Right
I = 270 q ,
Down
Ver. 1.0 9. Sep, 2009 15/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
5. Mechanical Characteristics
The contents provide general mechanical characteristics for the model LP173WD1.
In addition the figures in the next page are detailed mechanical drawing of the LCD.
Horizontal 398.1 r 0.50mm
Outline Dimension Vertical 232.8 r 0.50mm
Depth 6.0mm(Max.)
Horizontal 1.5mm Min.( Lager than Active Display Area )
Bezel Area
Vertical 1.5mm Min.( Lager than Active Display Area )
Horizontal 381.89mm
Active Display Area
Vertical 214.81 mm
Weight 570g (Max.)
Surface Treatment Glare treatment of the front Polarizer (Haze 0%)
Upper Glass (C/F Glass) 0.50 + 0.05 / -0.03 mm
Mother Glass Thickness
Lower Glass (TFT Glass) 0.50 + 0.05 / -0.03 mm
Ver. 1.0 9. Sep, 2009 16/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 9. Sep, 2009 17/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 9. Sep, 2009 18/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 9. Sep, 2009 19/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
[ DETAIL DESCRIPTION OF SIDE MOUNTING SCREW ]
Ver. 1.0 9. Sep, 2009 20/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
Backlight Exploded View. (Appendix)
16
8
15
11 7
18
9
10
12
13
17
6
5
4
3
14
2
1
No Part Name No Part Name
1 Diffuser Up Sheet 10 LED Array
2 Prism Up Sheet 11 Cover Bottom Fixing Double Tape
3 Prism Down Sheet 12 LGP Fixing Double Tape
4 Diffuser Down Sheet 13 Reflective Single Tape
5 Light Guide Panel 14 Sheet Fixing Pad (4pcs)
6 Reflector 15 Panel Fixing Pad (2pcs)
7 Supporter Main 16 Screw (2pcs)
8 Cover Bottom 17 Reflector Fixing Tape
9 LED Housing 18 FPC Fixing Tape
Ver. 1.0 9. Sep, 2009 21/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.(Appendix)
Gap check for securing the enough gap between LCM
1
and System cover.
Max Thickness
Sponge
LCM Reflector Side
System Cover
S-PCB
A Boundary Line
1.Rear side of LCM is sensitive against external stress,and previous check
about interference is highly needed.
Define 2.In case there is something from system cover comes into the boundary
above,mechanical interference may cause the FOS defects.
(Eg:Ripple,White spot..)
2 Check if antenna cable is sufficiently apart from T-CON of LCD Module.
Define
NO GOOD GOOD
1.If system antenna is overlapped with T-CON,it might be cause the noise.
Ver. 1.0 9. Sep, 2009 22/ 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WD1
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.
Gap check for securing the enough gap between LCM
3
and System hinge.
LCM Reflector Side
COF
S-PCB
(D-IC)
Hinge
Side Mount Screw Hole (4ea) ("I" TYPE) ("L" TYPE)
GAP:Min2.0mm
1.At least 2.0mm of gap needs to be secured to prevent the shock
Define related defects.
2."L" type of hinge is recommended than "I" type under shock test.
4 Checking the path of the System wire.
#1
#8 #7 #6 #5 #4 #3 #2 #1
Good Ok Bad
1.COF area needs to be handled with care.
2.GOOD ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
