Image preview - the first page of the document
![Panel_LG_Display_LP173WF1-TLA1_0_[DS]](/pics/5eafe77bc1810.gif)
>> Download Panel_LG_Display_LP173WF1-TLA1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.3" FHD TFT LCD
BUYER ASUS SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP173WF1
Suffix TLA1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
K. J. KWON / S.Manager
/
REVIEWED BY
/ G. J. Han / Manager
PREPARED BY
/
S. W. Park / Engineer
S. W. Kim / Engineer
Please return 1 copy for your confirmation with Product Engineering Dept.
your signature and comments. LG Display Co., Ltd
Ver. 0.0 Oct.15.2009 1/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 8
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 9
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 17
6 RELIABLITY 27
7 INTERNATIONAL STANDARDS
7-1 SAFETY 28
7-2 EMC 28
7-3 Environment 28
8 PACKING
8-1 DESIGNATION OF LOT MARK 29
8-2 PACKING FORM 29
9 PRECAUTIONS 30-31
A APPENDIX A. Enhanced Extended Display Identification Data 32-34
Ver. 0.0 Oct.15.2009 2/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Oct. 15. 2009 - First Draft 0.0
Ver. 0.0 Oct.15.2009 3/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
1. General Description
The LP173WF1 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 17.3 inches diagonally measured active display area with FHD
resolution (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors. The LP173WF1 has been designed to apply the interface method that enables low power, high
speed, low EMI. The LP173WF1 is intended to support applications where thin thickness, low power are
critical factors and graphic displays are important. In combination with the vertical arrangement of the sub-
pixels, the LP173WF1 characteristics provide an excellent flat display for office automation products such as
Notebook PC.
EEPROM Block
EEPROM Block
for EDID
for EDID
EEPROM Block
EEPROM Block 1 1920
for Tcon Operating
for Tcon Operating
User connector
TFT-LCD Panel
LVDS Timing Control
Timing Control (FHD, GIP, TN)
2port
(Tcon) Block
(Tcon) Block
Min
i- LVD 1080
DVCC TCLKs S
40
DVCC, AVDD
Pin
VCC Power Source Driver
Power VGH, VGL, GMA
(Bottom Bent)
Block
Block GIP CLKs, DSC
VOUT_LED
VLED LED Driver LED Backlight Ass'y
LED Driver FB1~6
LED_EN
PWM Block
Block
Control & Data Power EDID signal & Power
General Features
Active Screen Size 17.3 inches diagonal
Outline Dimension 398.1(H, Typ.) 232.8(V, Typ.) 6.0(D, Max.) mm
Pixel Pitch 0.1989 X 0.1989 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 300 cd/m2(Typ., @ ILED=22mA)
Power Consumption Total 8.5W(Typ.) Logic : 2.0W (Typ.@ Mosaic), B/L : 6.5W (Typ.@ VLED 12V )
Weight 580g (Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Glare treatment (4H) of the front Polarizer
RoHS Compliance Yes
BFR / PVC / As Free Yes for all
Ver. 0.0 Oct.15.2009 4/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 0.0 Oct.15.2009 5/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP173WF1 requires two power inputs. The first logic is employed to power the LCD electronics and to
drive the TFT array and liquid crystal. The second backlight is the input about LED BL.with LED Driver.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
LOGIC :
Power Supply Input Voltage VCC 3.0 3.3 3.6 V 1
Power Supply Input Current ICC - 600 680 mA 2
Power Consumption PCC - 1.98 2.24 W 2
Power Supply Inrush Current ICC_P - 770 900 mA 4
LVDS Impedance ZLVDS 90 100 110 5
BACKLIGHT : ( with LED Driver)
LED Power Input Voltage VLED 7.5 12.0 21.0 V 6
LED Power Input Current ILED - TBD TBD mA 7
LED Power Consumption PLED - TBD TBD W 7
LED Power Inrush Current ILED_P - 450 550 mA 8
PWM Duty Ratio 5 - 100 % 9
PWM Jitter - 0 - 0.2 % 10
PWM Impedance ZPWM 20 40 60 k
PWM Frequency FPWM 200 - 1000 Hz 11
PWM High Level Voltage VPWM_H 3.0 - 5.3 V
PWM Low Level Voltage VPWM_L 0 - 0.5 V
LED_EN Impedance ZPWM 20 40 60 k
LED_EN High Voltage VLED_EN_H 3.0 - 5.3 V
LED_EN Low Voltage VLED_EN_L 0 - 0.5 V
Life Time 12,000 - - Hrs 12
Ver. 0.0 Oct.15.2009 6/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Note)
1. The measuring position is the connector of LCM and the test condition is under 25 , fv = 60Hz,
Black pattern.
2. The specified Icc current and power consumption are under
the Vcc = 3.3V , 25 , fv = 60Hz condition whereas Mosaic pattern
is displayed and fv is the frame frequency.
3. The below figures aire the measuring Vcc condition and the Vcc control block LGD used.
The Vcc condition is same the minimum of T1 at Power on sequence.
3.3V
Rising time
Vcc 90%
0V 10%
0.5ms
4. This impedance value is needed to proper display and measured form LVDS Tx to the mating connector.
5. The measuring position is the connector of LCM and the test conditions are under 25 .
6. The current and power consumption with LED Driver are under the Vled = 12.0V , 25 , Dimming of
Max luminance whereas White pattern is displayed and fv is the frame frequency.
7. The below figures aire the measuring Vled condition 12.0V
and the Vled control block LGD used. Rising time 90%
VLED control block is same with Vcc control block. VLED
0V 10%
0.5ms
8. The operation of LED Driver below minimum dimming ratio may cause flickering or reliability issue.
9. If Jitter of PWM is bigger than maximum. It may cause flickering.
10. This Spec. is not effective at 100% dimming ratio as an exception because it has DC level equivalent
to 0Hz. In spite of acceptable range as defined, the PWM Frequency should be fixed and stable for
more consistent brightness control at any specific level desired.
11. The life time is determined as the time at which the typical brightness of LCD is 50% compare to that of
initial value at the typical LED current. These LED backlight has 6 strings on it and the typical current
of LED's string is base on 22mA.
Ver. 0.0 Oct.15.2009 7/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs two interface connections, a 40 pin connector is used for the module electronics interface
and the other connector is used for the integral backlight system.
The electronics interface connector is a model 20455-040E manufactured by UJU & LSMtron
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
Pin Symbol Description Notes
1 DIAG_LOOP Buyer's Test loop to 34pin [Interface Chip]
2 VDD Power Supply (3.3V typ.) 1. LCD :
3 VDD Power Supply (3.3V typ.) SW, SW0617(LCD Controller)
4 V EEDID DDC 3.3V power Including LVDS Receiver.
5 BIST Panel Self Test 2. System : SiWLVDSRx or equivalent
6 CLK EEDID DDC clock / SMBus clock * Pin to Pin compatible with LVDS
7 DATA EEDLD DDC data / SMBus data
[Connector]
8 Odd_Rin0- - LVDS differential data input (R0-R5,G0)
UJU IS050-L40B-C10
9 Odd_Rin0+ + LVDS differential data input (R0-R5,G0) LSMtron GT05Q-40S-H10
10 GND Ground or equivalent
11 Odd_Rin1- - LVDS differential data input (G1-G5,B0-B1)
12 Odd_Rin1+ + LVDS differential data input (G1-G5,B0-B1) [Mating Connector]
20345-#40E-## series
13 GND Ground
or equivalent
14 Odd_Rin2- - LVDS differential data input (B2-B5,HS,VS,DE)
15 Odd_Rin2+ + LVDS differential data input (B2-B5,HS,VS,DE)
16 GND Ground [Connector pin arrangement]
17 Odd_ClkIN- - LVDS differential clock input
18 Odd_ClkIN+ + LVDS differential clock input
19 GND No Connection
20 Even Rin0- - LVDS differential data input (R0-R5,G0)
40 1
21 Even Rin0+ + LVDS differential data input (R0-R5,G0)
22 GND Ground
23 Even Rin1- - LVDS differential data input (G1-G5,B0-B1)
24 Even Rin1+ + LVDS differential data input (G1-G5,B0-B1)
25 GND Ground
26 Even Rin2- - LVDS differential data input (B2-B5,HS,VS,DE)
27 Even Rin2+ + LVDS differential data input (B2-B5,HS,VS,DE)
28 GND Ground
29 Even ClkIN- - LVDS differential clock input
30 Even ClkIN+ + LVDS differential clock input
31 GND LED power return
32 GND LED power return
33 GND LED power return
34 DIAG_LOOP Buyer's Test loop to 1pin
35 PWM PWM for luminance control
36 LED_EN BL On/Off
37 NC No Connection.
38 VLED 7V-21V LED power
39 VLED 7V-21V LED power
40 VLED 7V-21V LED power
Ver. 0.0 Oct.15.2009 8/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3-3. LVDS Signal Timing Specifications
3-3-1. DC Specification
Symb
Description Min Max Unit Notes
ol
LVDS Differential Voltage |VID| 100 600 mV -
LVDS Common mode Voltage VCM 0.6 1.8 V -
LVDS Input Voltage Range VIN 0.3 2.1 V -
3-3-2. AC Specification
Description Symbol Min Max Unit Notes
85MHz > Fclk
tSKEW - 400 + 400 ps
65MHz
LVDS Clock to Data Skew Margin
65MHz > Fclk
tSKEW - 600 + 600 ps
25MHz
LVDS Clock to Clock Skew Margin (Even
tSKEW_EO - 1/7 + 1/7 Tclk -
to Odd)
Maximum deviation
FDEV - 3 % -
of input clock frequency during SSC
Maximum modulation frequency
FMOD - 200 KHz -
of input clock during SSC
Ver. 0.0 Oct.15.2009 9/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
< Clock skew margin between channel >
Freq.
Fmax
Fcenter
Fmin
Time
< Spread Spectrum >
3-3-3. Data Format
1) LVDS 2 Port
< LVDS Data Format >
Ver. 0.0 Oct.15.2009 10/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3-4. Signal Timing Specifications
This is the signal timing required at the input of the User connector. All of the interface signal timing should be
satisfied with the following specifications and specifications of LVDS Tx/Rx for its proper operation.
Table 5. TIMING TABLE
ITEM Symbol Min Typ Max Unit Note
DCLK Frequency fCLK - 74.9 - MHz 2port
Period tHP 1086 1138 1190
Hsync Width tWH 32 48 56 tCLK 2port
Width-Active tWHA 960 960 960
Period tVP 1093 1097 1101
Vsync
Width tWV 2 3 4 tHP
Width-Active tWVA 1080 1080 1080
Horizontal back porch tHBP 68 98 134
tCLK 2port
Data Horizontal front porch tHFP 26 32 40
Enable Vertical back porch tVBP 10 12 14
tHP
Vertical front porch tVFP 1 2 3
Note)
1. In this documentation, all reliabilities are specified for timing specification based on refresh rate of 60Hz.
However, LP173WF1 has a good actual performance even at lower refresh rate( eg. 40Hz or 50Hz) for
power saving mode, whereas LP173WF1 is secured only for function under lower refresh rate.
60Hz at Normal mode, 50Hz ,40 Hz at Power save mode. Don't care Flicker level (power save mode).
Condition : VCC =3.3V
3-5. Signal Timing Waveforms High: 0.7VCC
Low: 0.3VCC
tHP
Hsync t
WH
tHBP tWHA tHFP
Date Enable
tVP
tWV
Vsync tVFP
tVBP tWVA
Date Enable
Ver. 0.0 Oct.15.2009 11/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3-6. Color Input Data Reference
The brightness of each primary color (red,green and blue) is based on the 6-bit gray scale data input for the
color ; the higher the binary input, the brighter the color. The table below provides a reference for color
versus data input.
Table 6. COLOR DATA REFERENCE
Input Color Data
RED GREEN BLUE
Color
MSB LSB MSB LSB MSB LSB
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Basic Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RED (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (01) 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
RED ... ... ... ...
RED (62) 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (01) 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
GREEN ... ... ... ...
GREEN (62) 0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
GREEN (63) 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
BLUE (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BLUE (01) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
BLUE ... ... ... ...
BLUE (62) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
BLUE (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Ver. 0.0 Oct.15.2009 12/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
3-7. Power Sequence
90% 90%
Power Supply Input
VCC
0V 10% 10%
T3 T7 T4
T1 T2 Valid Data
Interface Signal, Vi
LVDS
0V
T5 3.0V 3.0V T6
LED on/off control Signal
0V (Off)
LED_EN
T9 T10
Dimming control signal Valid Data
Of LED BL 0V (Low)
PWM
T8 T11
90% 90%
LED input Voltage
VLED 0V 10% T12 T13 10%
Table 6. POWER SEQUENCE TABLE
Logic Value LED Value
Units Units
Parameter Min. Typ. Max. Parameter Min. Typ. Max.
T1 0.5 - 10 ms T8 10 - - ms
T2 0 - 50 ms T9 0 - - ms
T3 0 - 50 ms T10 0 - - ms
T4 400 - - ms T11 10 - - ms
T5 200 - - ms T12 0.5 - - ms
T6 200 - - ms T13 0 - 5000 ms
T7 3 - 10 ms
Note)
1. Do not insert the mating cable when system turn on.
2. Valid Data have to meet "3-3. LVDS Signal Timing Specifications"
3. LVDS, LED_EN and PWM need to pull-down condition on invalid status.
4. LGD recommend the rising sequence of VLED after the Vcc and valid status of LVDS turn on.
Ver. 0.0 Oct.15.2009 13/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and stable for approximately 20 minutes in
a dark environment at 25qC. The values specified are at an approximate distance 50cm from the LCD surface
at a viewing angle of ) and 4 equal to 0q.
FIG. 1 presents additional information concerning the measurement equipment and method.
FIG. 1 Optical Characteristic Measurement Equipment and Method
LCD Module Equipment
Optical Stage(x,y)
500mm 50mm
Table 8. OPTICAL CHARACTERISTICS Ta=25qC, VCC=3.3V, fV=60Hz, fCLK= 97.75MHz, ILED =TBD mA
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR 500 600 - 1
Surface Luminance, white LWH 270 300 - cd/m2 2
Luminance Variation G WHITE - 35% 3
Response Time - 8 16 ms 4
Color Coordinates
RED RX 0.610 0.640 0.670
RY 0.305 0.335 0.365
GREEN GX 0.290 0.320 0.350
GY 0.580 0.630 0.660
BLUE BX 0.120 0.150 0.180
BY 0.030 0.060 0.090
WHITE WX 0.283 0.313 0.343
WY 0.299 0.329 0.359
Viewing Angle 5
x axis, right()=0q) 4r 60 - - degree
x axis, left ()=180q) 4l 60 - - degree
y axis, up ()=90q) 4u 50 - - degree
y axis, down ()=270q) 4d 50 - - degree
Gray Scale 6
Color Gamut 67 72 - %
Ver. 0.0 Oct.15.2009 14/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Note)
1. Contrast Ratio(CR) is defined mathematically as
Surface Luminance with all white pixels
Contrast Ratio =
Surface Luminance with all black pixels
2. Surface luminance is the average of 5 point across the LCD surface 50cm from the surface with
all pixels displaying white. For more information see FIG 1.
LWH = Average(L1,L2, ... L5)
3. The variation in surface luminance , The panel total variation (G WHITE) is determined by measuring LN
at each test position 1 through 13 and then defined as followed numerical formula.
For more information see FIG 2.
Maximum(L1,L2, ... L13) - Minimum(L1,L2, ... L13)
G WHITE( = * 100(%)
Maximum(L1,L2, ... L13)
4. Response time is the time required for the display to transition from white to black (rise time, TrR) and
from black to white(Decay Time, TrD). For additional information see FIG 3.
5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD surface. For more information see FIG 4.
6. Gray scale specification * fV = 60Hz
Gray Level Luminance [%] (Typ)
L0 0.11
L7 1.20
L15 5.23
L23 11.8
L31 20.6
L39 34.6
L47 53.3
L55 74.8
L63 100
Ver. 0.0 Oct.15.2009 15/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
FIG. 2 Luminance
H
A D
L6 L7 L8 H,V : ACTIVE AREA
C
A : H/5 mm
L2 L3
B : V/5 mm
C : V/10 mm
B
D : H/10 mm
POINTS : 13 POINTS
V
L9 L1 L10
Center Point
L4 L5
L11 L12 L13
FIG. 3 Response Time
The response time is defined as the following figure and shall be measured by switching the input signal
for "black" and "white".
TrR TrD
%
100
90
Optical
Response
10
0 white white
black
FIG. 4 Viewing angle Normal
Eye Y
I = 90 q , Up
I = 180 q ,
Left T
I
I = 0q ,
Right
I = 270 q ,
Down
Ver. 0.0 Oct.15.2009 16/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
5. Mechanical Characteristics
The contents provide general mechanical characteristics for the model LP173WF1.
In addition the figures in the next page are detailed mechanical drawing of the LCD.
Horizontal 398.1 r 0.50mm
Outline Dimension Vertical 232.8 r 0.50mm
Depth 6.0mm(Max.)
Horizontal 1.5mm Min.( Lager than Active Display Area )
Bezel Area
Vertical 1.5mm Min.( Lager than Active Display Area )
Horizontal 381.888mm
Active Display Area
Vertical 214.812 mm
Weight 580g (Max.)
Surface Treatment 4H Glare treatment of the front Polarizer (Haze 0%)
Upper Glass (C/F Glass) 0.50 + 0.05 / -0.03 mm
Mother Glass Thickness
Lower Glass (TFT Glass) 0.50 + 0.05 / -0.03 mm
Ver. 0.0 Oct.15.2009 17/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 0.0 Oct.15.2009 18/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 0.0 Oct.15.2009 19/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
[ DETAIL DESCRIPTION OF SIDE MOUNTING SCREW ]
[ DETAIL INFORMATION OF PPID LABEL AND REVISION CODE ]
* PPID Label Revision
37 mm
78 mm
* PPID Label Revision :
It is subject to change with Dell event. Please refer to the below table for detail.
Classification No Change 1st Revision 2nd Revision ... 9th Revision ...
SST(WS) X00 X01 X02 ... A09 ...
PT(ES) X10 X11 X12 ... A19 ...
ST(CS) X20 X21 X22 ... A29 ...
XB(MP) A00 A01 A02 ... A09 ...
Ver. 0.0 Oct.15.2009 20/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
Backlight Exploded View. (Appendix)
16
8
15
11 7
18
9
10
12
13
17
6
5
4
3
14
2
1
No Part Name No Part Name
1 Diffuser Up Sheet 10 LED Array
2 Prism Up Sheet 11 Cover Bottom Fixing Double Tape
3 Prism Down Sheet 12 LGP Fixing Double Tape
4 Diffuser Down Sheet 13 Reflective Single Tape
5 Light Guide Panel 14 Sheet Fixing Pad (4pcs)
6 Reflector 15 Panel Fixing Pad (2pcs)
7 Supporter Main 16 Screw (2pcs)
8 Cover Bottom 17 Reflector Fixing Tape
9 LED Housing 18 FPC Fixing Tape
Ver. 0.0 Oct.15.2009 21/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.(Appendix)
Gap check for securing the enough gap between LCM
1
and System cover.
Max Thickness
Sponge
LCM Reflector Side
System Cover
A Boundary Line
1.Rear side of LCM is sensitive against external stress,and previous check
about interference is highly needed.
Notes 2.In case there is something from system cover comes into the boundary
above,mechanical interference may cause the FOS defects.
(Eg:Ripple,White spot..)
2 Check if antenna cable is sufficiently apart from T-CON of LCD Module.
NO GOOD GOOD
Notes 1.If system antenna is overlapped with T-CON,it might be cause the noise.
Ver. 0.0 Oct.15.2009 22/ 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF1
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.
Gap check for securing enough gap between LCM
3
and System hinge.
LCM Reflector Side
COF
(D-IC)
Hinge
Side Mount Screw Hole (4ea)
GAP:Min2.0mm ("I" TYPE) ("L" TYPE)
1. At least 2.0mm gap is required to secure from any damage
during shock test.
Notes
2. "L" type hinge is more recommended than "I" type to get better
performance for shock test.
4 Checking the path of the System wire.
#3 #2
#1
Ok Bad Good
1. It is required to handle COF area carefully .
2. Good : Wire path does not overlap with LCM
Notes OK : Wire path is located between COFs.
BAD : Wire path overlapped with COF area.
Flat type cable is highly recommended if cable should be located on bad case
Ver. 0.0 Oct.15.2009 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
