Image preview - the first page of the document
![Panel_LG_Display_LP173WF2-TPB1_0_[DS]](/pics/5eafe7d28959c.gif)
>> Download Panel_LG_Display_LP173WF2-TPB1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.3" Full HD TFT LCD
BUYER HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP173WF2
Suffix TPB1
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE
APPROVED BY SIGNATURE
K. S. Kwon / Manager
/ REVIEWED BY
J. W. Kim / Engineer
/
PREPARED BY
/
H. M. Yoon / Engineer
J. K. Han / Engineer
Product Engineering Dept.
Please return 1 copy for your confirmation with LG Display Co., Ltd
your signature and comments.
Ver. 0.1 May. 05. 2010 1/ 33
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6-7
3-2 INTERFACE CONNECTIONS 8
3-3 eDP SIGNAL TIMING SPECIFICATION 9
3-4 SIGNAL TIMING SPECIFICATIONS 10
3-5 SIGNAL TIMING WAVEFORMS 10
3-6 COLOR INPUT DATA REFERNECE 11
3-7 POWER SEQUENCE 12
4 OPTICAL SFECIFICATIONS 13-16
5 MECHANICAL CHARACTERISTICS 17-20
6 RELIABLITY 26
7 INTERNATIONAL STANDARDS
7-1 SAFETY 27
7-2 EMC 27
7-3 Environment 27
8 PACKING
8-1 DESIGNATION OF LOT MARK 28
8-2 PACKING FORM 28
9 PRECAUTIONS 29-30
A APPENDIX. Enhanced Extended Display Identification Data 31-33
Ver. 0.1 May. 05. 2010 2/ 33
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Feb. 11. 2010 - First Draft (Preliminary Specification) -
0.1 May.05.2010 8 Change connector pinmap
10 Update TIMING TABLE
31-33 Update EEDID data V0.1
Ver. 0.1 May. 05. 2010 3/ 33
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
1. General Description
The LP173WF2 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 17.3 inches diagonally measured active display area with FHD
resolution (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors. The LP173WF2 has been designed to apply the interface method that enables low power, high
speed, low EMI. The LP173WF2 is intended to support applications where thin thickness, high brightness
are critical factors and graphic displays are important. In combination with the vertical arrangement of the
sub-pixels, the LP173WF2 characteristics provide an excellent flat display for office automation products
such as Notebook PC.
VOUT_LED
VLED LED Driver FB1~6
LED Driver
LED_EN
PWM
Block
Block LED Backlight Ass'y
FB7~12
User connector
1 1920
AUX
eDP Timing Control
eDP Timing Control
eDP (Tcon) Block
4Lane (Tcon) Block
TFT-LCD Panel
(FHD, Dual Gate COF , TN)
AVCC FLK GSP
DVCC DPM GOE
50 GSC
TVCC GSC 1080
Pin
Mini-LVDS
Power AVCC, AVDD Source Driver
VCC +5V Power
VGH, VGL, GMA (Bottom Bent)
Block
Block
Control & Data Power EDID signal & Power
General Features
Active Screen Size 17.3 inches diagonal
Outline Dimension 381.888(Typ. H) 214.812(Typ. V) 6.5(D, Max.) [mm]
Pixel Pitch 0.199 0.199 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 400 cd/m2(Typ.)
Power Consumption Total 2D TBD W/ 3D TBD W(Typ.)
Weight 650g(Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-Glare treatment of the front Polarizer
RoHS Compliance Yes
BFR / PVC / As Free Yes for all.
Ver. 0.1 May. 05. 2010 4/ 33
PDF created with pdfFactory Pro trial version www.pdffactory.com
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
