Image preview - the first page of the document
![Panel_LG_Display_LP173WF2-TPB2_0_[DS]](/pics/5eafe7e79ce20.gif)
>> Download Panel_LG_Display_LP173WF2-TPB2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.3" Full HD TFT LCD
BUYER HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP173WF2
Suffix TPB2
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE
APPROVED BY SIGNATURE
J. Y. Lee / Manager
/ REVIEWED BY
S. W. Park / Engineer
/
PREPARED BY
/
H. M. Yoon / Engineer
J. H. Shin / Engineer
Product Engineering Dept.
Please return 1 copy for your confirmation with LG Display Co., Ltd
your signature and comments.
Ver. 1.0 Dec. 14. 2010 1/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6-7
3-2 INTERFACE CONNECTIONS 8
3-3 eDP SIGNAL TIMING SPECIFICATION 9-10
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 15-18
5 MECHANICAL CHARACTERISTICS 19-22
6 RELIABLITY 28
7 INTERNATIONAL STANDARDS
7-1 SAFETY 29
7-2 EMC 29
7-3 Environment 29
8 PACKING
8-1 DESIGNATION OF LOT MARK 30
8-2 PACKING FORM 30
9 PRECAUTIONS 31-32
A APPENDIX. Enhanced Extended Display Identification Data 33-35
Ver. 1.0 Dec. 14. 2010 2/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 Nov. 09. 2010 - First Draft (Preliminary Specification) -
1.0 Dec. 14, 2010 - Final Draft 1.0
Ver. 1.0 Dec. 14. 2010 3/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
1. General Description
The LP173WF2 is a Color Active Matrix Liquid Crystal Display with an integral LED backlight system. The
matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in
the normally white mode. This TFT-LCD has 17.3 inches diagonally measured active display area with FHD
resolution (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into Red, Green and Blue sub-
pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 6-bit gray scale signal for each dot, thus, presenting a palette of more than 262,144
colors. The LP173WF2 has been designed to apply the interface method that enables low power, high
speed, low EMI. The LP173WF2 is intended to support applications where thin thickness, high brightness
are critical factors and graphic displays are important. In combination with the vertical arrangement of the
sub-pixels, the LP173WF2 characteristics provide an excellent flat display for office automation products
such as Notebook PC.
VOUT_LED
VLED LED Driver FB1~6
LED Driver
LED_EN
PWM
Block
Block LED Backlight Ass'y
FB7~12
User connector
1 1920
AUX
eDP Timing Control
eDP Timing Control
eDP (Tcon) Block
4Lane (Tcon) Block
TFT-LCD Panel
(FHD, Dual Gate COF , TN)
AVCC FLK GSP
DVCC DPM GOE
50 GSC
TVCC GSC 1080
Pin
Mini-LVDS
Power AVCC, AVDD Source Driver
VCC +5V Power
VGH, VGL, GMA (Bottom Bent)
Block
Block
Control & Data Power EDID signal & Power
General Features
Active Screen Size 17.3 inches diagonal
Outline Dimension 381.888(Typ. H) 214.812(Typ. V) 6.5(D, Max.) [mm]
Pixel Pitch 0.199 0.199 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels RGB strip arrangement
Color Depth 6-bit, 262,144 colors
Luminance, White 400 cd/m2(Typ.)
Power Consumption Total 60Hz : 16.3W , Total 120Hz(+VBI32%) : 20 W (Typ.)
Weight 650g(Max.)
Display Operating Mode Transmissive mode, normally white
Surface Treatment Anti-Glare treatment of the front Polarizer
RoHS Compliance Yes
BFR / PVC / As Free Yes for all.
Ver. 1.0 Dec. 14. 2010 4/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 1.0 Dec. 14. 2010 5/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP173WF2 requires two power inputs. The first logic is employed to power the LCD electronics and to
drive the TFT array and liquid crystal. The second backlight is the input about LED BL with LED Driver.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
LOGIC :
Power Supply Input Voltage VCC 4.5 5.0 5.5 V 1
Power Supply Input Current (2D) Mosaic ICC - 750 880
_60Hz
mA
Power Supply Input Current (3D) Mosaic ICC - 1300 1500
_120Hz + VBI 32%
2
Power Consumption (2D) Mosaic PCC - 3.8 4.4
_60Hz
W
Power Consumption(3D) Mosaic PCC - 6.5 7.5
_120Hz+VB I32%
Power Supply Inrush Current ICC_P - - 2000 mA 4
eDP Impedance ZeDP 90 100 110 5
BACKLIGHT : ( with LED Driver)
LED Power Input Voltage VLED 7.0 12.0 21.0 V 6
LED Power Input Current ILED - 960 1000 mA 7
LED Power Consumption PLED - 11.5 12 W 7
LED Power Inrush Current ILED_P - - 1000 mA 8
PWM Duty Ratio 5 - 100 % 9
PWM Jitter - 0 - 0.2 % 10
PWM Impedance ZPWM 450 500 550 k
PWM Frequency FPWM(2D) 200 - 1000 Hz 11
FPWM(3D) 90 - 120 Hz 12
PWM High Level Voltage VPWM_H 3.0 - 3.6 V
PWM Low Level Voltage VPWM_L 0 - 0.3 V
LED_EN Impedance ZPWM 450 500 550 k
LED_EN High Voltage VLED_EN_H 3.0 - 3.6 V
LED_EN Low Voltage VLED_EN_L 0 - 0.3 V
Life Time 12,000 - - Hrs 13
Ver. 1.0 Dec. 14. 2010 6/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Note)
1. The measuring position is the connector of LCM and the test conditions are under 25 , fv = 60Hz.
2. The specified Icc current and power consumption are under the Vcc = 5V , 25 , fv = 60Hz or
120Hz+VBI condition.
White Pattern
4. The below figures are the measuring Vcc condition and the Vcc control block LGD used.
The Vcc condition is same as the minimum of T1 at Power on sequence.
3.3V
Rising time
Vcc 90%
0V 10%
0.5ms
5. This impedance value is needed for proper display and measured from eDP Tx to the mating connector.
6. The measuring position is the connector of LCM and the test conditions are under 25 .
7. The current and power consumption with LED Driver are under the Vled = 12.0V , 25 , Dimming of
Max luminance and White pattern with the normal frame frequency operated(60Hz).
8. The below figures are the measuring Vled condition 12.0V
and the Vled control block LGD used. Rising time 90%
VLED control block is same with Vcc control block. VLED
0V 10%
0.1ms
9. The operation of LED Driver below minimum dimming ratio may cause flickering or reliability issue.
10. If Jitter of PWM is bigger than maximum, it may induce flickering.
11. This Spec. is not effective at 100% dimming ratio as an exception because it has DC level equivalent
to 0Hz. In spite of acceptable range as defined, the PWM Frequency should be fixed and stable for
more consistent brightness control at any specific level desired.
12. If LCM want to B/L on/off concept for 3D operation.it has to be syncronized with 3D frame frequency.
13. The life time is determined as the time at which brightness of LCD is 50% compare to that of minimum
value specified in table 7. under general user condition.
Ver. 1.0 Dec. 14. 2010 7/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs two interface connections, a 50 pin connector used for the module electronics interface and
the other connector used for the integral backlight system.
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
Pin Symbol Description Notes
1 NC Reserved [Interface Chip]
2 NC Reserved 1. LCD :
3 GND Ground MStar, MST7329Y(LCD Controller)
4 Lane3_N Signal Link Lane3 Including eDP Receiver.
5 Lane3_P Signal Link Lane3 2. System : ANX9806 or equivalent
6 GND Ground
7 Lane2_N Signal Link Lane2
8 Lane2_P Signal Link Lane2
[Connector]
9 GND Ground
10 Lane1_N Signal Link Lane1 JAE FI-VHP50 or equivalent
11 Lane1_P Signal Link Lane1
12 GND Ground [Mating Connector]
13 Lane0_N Signal Link Lane0 JAE FI-VHP50 series or equivalent
14 Lane0_P Signal Link Lane0 (micro-coax type)
15 GND Ground
16 AUX_CH_P Signal Auxiliary Ch. [Connector pin arrangement]
17 AUX_CH_N Signal Auxiliary Ch.
18 GND Ground 1
50
19 Vcc LCD logic input power
20 Vcc LCD logic input power
21 Vcc LCD logic input power [LCD Module Rear View]
22 Vcc LCD logic input power 40 1
[LCD Module Rear View]
23 Vcc LCD logic input power
24 Vcc LCD logic input power
25 Vcc LCD logic input power
26 Vcc LCD logic input power
27 Vcc LCD logic input power
28 Vcc LCD logic input power
29 GND Ground
30 GND Ground
31 GND Ground
32 GND Ground
33 NC Reserved
34 GND Ground
35 HPD Hot plug Detection Pin
36 GND Ground
37 GND Ground
38 GND Ground
39 GND Ground
40 LED_EN Backlight On/Off Control
41 PWM PWM for luminance control
42 NC Reserved
43 NC Reserved
44 GND Ground
45 VLED LED Power Supply 7V-20V
46 VLED LED Power Supply 7V-20V
47 VLED LED Power Supply 7V-20V
48 VLED LED Power Supply 7V-20V
49 GND Ground
50 2D_3D 2D/3D Contents communication(3D selection)
Ver. 1.0 Dec. 14. 2010 8/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-3. eDP Signal Timing Specifications
3-3-1. DC Specification
The VESA Display Port related AC specification is compliant with the VESA Display Port Standard v1.1a.
Description Symbol Min Max Unit Notes
120 - For high bit rate
Differential peak-to-peak Input voltage VDIFF p-p mV
40 - For reduced bit rate
Rx DC common mode voltage VCM 0 2.0 V -
3-3-2. AC Specification
The VESA Display Port related AC specification is compliant with the VESA Display Port Standard v1.1a.
Description Symbol Min Typ Max Unit Notes
Unit Interval for high bit rate
UI_High_Rate - 370 - ps Range is nominal 350ppm.
(2.7Gbps/lane) DisplayPort Link Rx does not
require local crystal for link
Unit Interval for high bit rate clock generation
UI_Low_Rate - 617 - ps
(1.62Gbps/lane)
V Rx-SKEW-
Lane-to-Lane skew - - 5200 ps -
INTER_PAIR
V Rx-SKEW- - - 100 ps For high bit rate
Lane intra-pair skew
INTRA_PAIR - - 300 ps For reduced bit rate
Ver. 1.0 Dec. 14. 2010 9/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-3-3. Eye Diagram
The VESA Display Port related Eye Diagram is compliant with the VESA Display Port Standard v1.1a.
2
1 3
4
Main Link Position Spec.
Lane 0 Point2 Min 150mV
~ ~
Lane 3 Point4
Lane 0 Point1 (2.7Gbps,
~ ~ min 188.33ps)
Lane 3 Point3
Ver. 1.0 Dec. 14. 2010 10/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-4. Signal Timing Specifications
This is the signal timing required at the input of the User connector. All of the interface signal timing should be
satisfied with the following specifications and specifications of eDP Tx/Rx for its proper operation.
Table 4. TIMING TABLE
ITEM Symbol Min. Typ. Max. Unit Note
2D
(148.5MHz@60Hz)
DCLK Frequency fCLK - 37.1 100 MHz
3D
(396MHz@120+VBI)
Period tHP 520 550 550
Hsync Width tWH 5 11 11 tCLK
Width-Active twHA 480 480 480
Period tVP 1120 1125 1980
Vsync
Width tWV 5 5 5 tHP
Width-Active twVA 1080 1080 1080
Horizontal back porch tHBP 30 37 37
tCLK
Data Horizontal front porch tHFP 5 22 22
Enable Vertical back porch tVBP 32 36 892
tHP
Vertical front porch tVFP 3 4 5
* VBI : Vertical Blanking Interval.
Normal 2D/3D DCLK
1) 2D : Frame freq.(60Hz), Dclk(148.5MHz) , Htotal(2200, B/I 88+44+148) ,Vtotal(1125, B/I 4+5+36)
2) 3D : Frame freq.(120Hz), Dclk(396.4MHz) , Htotal(2080, B/I 20+20+120) ,Vtotal(1588, B/I 3+5+500)
cf: B/I Blanking Interval (front porch + sync width + back porch)
3-5. Signal Timing Waveforms
High: 0.7VCC
Data Enable, Hsync, Vsync Low: 0.3VCC
tHP
Hsync t
WH
tHBP tWHA tHFP
Data Enable
tVP
tWV
Vsync tWVA tVFP
tVBP
Data Enable
Ver. 1.0 Dec. 14. 2010 11/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-6. Color Input Data Reference
The brightness of each primary color (red,green and blue) is based on the 6-bit gray scale data input for the
color ; the higher the binary input, the brighter the color. The table below provides a reference for color
versus data input.
Table 5. COLOR DATA REFERENCE
Input Color Data
RED GREEN BLUE
Color
MSB LSB MSB LSB MSB LSB
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
Basic Blue 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Color Cyan 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 0 0 0 0 0 0 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RED (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (01) 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0
RED ... ... ... ...
RED (62) 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0
RED (63) 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GREEN (01) 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0
GREEN ... ... ... ...
GREEN (62) 0 0 0 0 0 0 1 1 1 1 1 0 0 0 0 0 0 0
GREEN (63) 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0 0 0
BLUE (00) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
BLUE (01) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
BLUE ... ... ... ...
BLUE (62) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 0
BLUE (63) 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Ver. 1.0 Dec. 14. 2010 12/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
3-7. Power Sequence 3.3V
90% 90%
Power Supply Input T1
VCC
0V 10% 10%
T2 T7
T6
HPD Out from LCM 0V
HPD Valid Channel Operational Data
Vcm
Aux Channel Data Input 0V
Link
AUX Training Idle
T3
Valid
Vcm Data Valid Video Data
Main Link Data Input 0V
ML0 T4 T5
T8 3.0V 3.0V
T9
LED BL
On/Off Control Signal 0V (Off)
LED_EN
T10 T11
LED BL Valid Data
Dimming Control Signal 0V (Low)
PWM T14 T15
90% 90%
LED Driver Input Voltage
0V 0V 10% T12 T13 10%
VLED
Table 6. POWER SEQUENCE TABLE
Logic Value LED Value
Units Units
Parameter Min. Typ. Max. Parameter Min. Typ. Max.
T1 0.5 - 10 ms T9 200 - - ms
T2 100 - 200 ms T10 0 - - ms
T3 50 75 - ms T11 0 - - ms
T4 0 - - ms T12 0.5 - - ms
T5 0 - - ms T13 0 - 5000 ms
T6 500 - - ms T14 10 - - ms
T7 3 - 10 ms T15 10 - - ms
T8 200 - - ms
Note)
1. Do not insert the mating cable when system turn on.
2. Valid Data have to meet "3-3. eDP Signal Timing Specifications"
3. LVDS, LED_EN and PWM need to be on pull-down condition on invalid status.
4. LGD recommend the rising sequence of VLED after the Vcc and valid status of LVDS turn on.
Ver. 1.0 Dec. 14. 2010 13/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
The sequence specification of LED Driver operation (2D 3D)
LP173WF2 Model is supported to change the operation mode of LED Driver IC by control 2D/3D.
When 2D/3D is changed, the operation of LED Driver should be operated by the below sequence.
3D selection Mode selection
LED Driver IC
[2D] Low [2D] High [2D] Phase shift
User
CNT [3D] High T con [3D] Low OPTION SELECT [3D] PWM Direct
#50
90% 90%
2D 3D 3D_sel 3D 2D
10% (from HP system) 10%
90%
Max 12ms Mode Max 12ms
10% selection
(T-con output)
90%
90%
LED_EN 10%
10% (from HP system) VBI 32%
VBI 32% 90%
90% Off On Off
Off On Off PWM (0%) (100%) (0%)
2D Duty
(0%) (100%) (0%) (from HP system)
T17
T16
Logic Value
Units
Parameter Min. Typ. Max.
T16 15 - - ms
T17 15 - - ms
Note) When it is out of T16 or T17 spec,it can happemed the phenomenon of Half Dark Screen or BL off.
Ver. 1.0 Dec. 14. 2010 14/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and stable for approximately 20 minutes in
a dark environment at 25qC. The values specified are at an approximate distance 50cm from the LCD surface
at a viewing angle of ) and 4 equal to 0q.
FIG. 1 presents additional information concerning the measurement equipment and method.
FIG. 1 Optical Characteristic Measurement Equipment and Method
LCD Module Equipment
Optical Stage(x,y)
500mm 50mm
Table 7. OPTICAL CHARACTERISTICS
Ta=25qC, VCC=5.0V, fV=60Hz, fCLK= 148.5MHz
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR 500 - - 1
Surface Luminance, white LWH 340 400 - cd/m2 2
Luminance Variation G WHITE - 1.4 1.6 3
Black to White TrR + TrD - 5 12 ms 4
Response Time
Gray to Gray TrR + TrD - 4 6 ms 5
Color Coordinates
RED RX 0.612 0.642 0.672
RY 0.315 0.345 0.375
GREEN GX 0.309 0.339 0.369
GY 0.590 0.620 0.650
BLUE BX 0.118 0.148 0.178
BY 0.032 0.062 0.092
WHITE WX 0.283 0.313 0.343
WY 0.299 0.329 0.359
Viewing Angle 6
x axis, right()=0q) 4r 60 - - degree
x axis, left ()=180q) 4l 60 - - degree
y axis, up ()=90q) 4u 50 - - degree
y axis, down ()=270q) 4d 50 - - degree
Gray Scale 7
Color Gamut C/G - 72 - %
Ver. 1.0 Dec. 14. 2010 15/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Note)
1. Contrast Ratio(CR) is defined mathematically as
Surface Luminance with all white pixels
Contrast Ratio =
Surface Luminance with all black pixels
2. Surface luminance is the average of 5 point across the LCD surface 50cm from the surface with
all pixels displaying white. For more information see FIG 1.
LWH = Average(L1,L2, ... L5)
3. The variation in surface luminance , The panel total variation (G WHITE) is determined by measuring LN
at each test position 1 through 13 and then defined as following numerical formula.
For more information see FIG 2.
Maximum(L1,L2, ... L13) - Minimum(L1,L2, ... L13)
G WHITE( =
Maximum(L1,L2, ... L13)
4. Response time is the time required for the display to transition from white to black (rise time, TrR) and
from black to white(Decay Time, TrD). For additional information see FIG 3.
5. The G to G (Gray to Gray) response time is defined as the following table and must be measured by switching
the input signal for "Gray To Gray" under "ODC on" state.
- Gray step : 5 step
- TGTG (Typ) is the typical specification of total average time at rising time and falling time for `Gray to Gray'.
- TGTG (Max) is the maximum specification of total average time at rising time and falling time for `Gray to Gray'.
Rising Time
Gray to Gray
G63 G47 G31 G15 G0
G63
G47
Falling Time G31
G15
G0
6. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD surface. For more information see FIG 4.
Ver. 1.0 Dec. 14. 2010 16/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
7. Gray scale specification * fV = 60Hz
Gray Level Luminance [%] (Typ)
L0 0.1
L7 0.8
L15 4.25
L23 10.9
L31 21
L39 34.8
L47 52.5
L55 74.2
L63 100
Ver. 1.0 Dec. 14. 2010 17/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
FIG. 2 Luminance
H
A D
L6 L7 L8
C
H,V : ACTIVE AREA
A : H/4 mm
L2 L3 B : V/4 mm
C : 10 mm
B
D : 10 mm
POINTS : 13 POINTS
V
L9 L1 L10
Center Point
L4 L5
L11 L12 L13
FIG. 3 Response Time
The response time is defined as the following figure and shall be measured by switching the input signal
for "black" and "white".
TrR TrD
%
100
90
Optical
Response
10
0 white white
black
FIG. 4 Viewing angle Normal
Eye Y
I = 90 q , Up
I = 180 q ,
Left T
I
I = 0q ,
Right
I = 270 q ,
Down
Ver. 1.0 Dec. 14. 2010 18/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
5. Mechanical Characteristics
The contents provide general mechanical characteristics for the model LP173WF2.
In addition the figures in the next page are detailed mechanical drawing of the LCD.
Horizontal (A) 398.1 r 0.50mm
Outline Dimension Vertical (B) 232.8 r 0.50mm
Thickness 6.5mm(Max.)
Horizontal 1.5mm Min.( Lager than Active Display Area )
Bezel Area
Vertical 1.5mm Min.( Lager than Active Display Area )
Horizontal 381.89mm
Active Display Area
Vertical 214.81mm
Weight 650g (Max.)
Surface Treatment Anti-Glare treatment of the front polarizer (Haze 44%)
Ver. 1.0 Dec. 14. 2010 19/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 Dec. 14. 2010 20/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 Dec. 14. 2010 21/ 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF2
Liquid Crystal Display
Product Specification
[ DETAIL DESCRIPTION OF SIDE MOUNTING SCREW ]
Notes : 1. Screw plated through the method of non-electrolytic nickel plating is preferred
to reduce possibility that results in vertical and/or horizontal line defect due to
the conductive particles from screw surface.
Ver. 1.0 Dec. 14. 2010 22/ 35
One step solution for LCD / ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
