Image preview - the first page of the document
![Panel_LG_Display_LP173WF3-SLB2_0_[DS]](/pics/5eafe8138d813.gif)
>> Download Panel_LG_Display_LP173WF3-SLB2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
SPECIFICATION
FOR
APPROVAL
( ) Preliminary Specification
( ) Final Specification
Title 17.3" FHD TFT LCD
BUYER HP SUPPLIER LG Display Co., Ltd.
MODEL *MODEL LP173WF3
Suffix SLB2
*When you obtain standard approval,
please use the above model name without suffix
APPROVED BY SIGNATURE APPROVED BY SIGNATURE
S. R. Kim / S.Manager
/
REVIEWED BY
/
M. J. Lee / S.Manager
/ PREPARED BY
S. I. Joo / Engineer
J. P. Lee / Engineer
Please return 1 copy for your confirmation with
Products Engineering Dept.
your signature and comments.
LG Display Co., Ltd
Ver. 1.0 26. Apr. 2011 1 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
Contents
No ITEM Page
COVER 1
CONTENTS 2
RECORD OF REVISIONS 3
1 GENERAL DESCRIPTION 4
2 ABSOLUTE MAXIMUM RATINGS 5
3 ELECTRICAL SPECIFICATIONS
3-1 ELECTRICAL CHARACTREISTICS 6
3-2 INTERFACE CONNECTIONS 7
3-3 LVDS SIGNAL TIMING SPECIFICATIONS 8
3-4 SIGNAL TIMING SPECIFICATIONS 11
3-5 SIGNAL TIMING WAVEFORMS 11
3-6 COLOR INPUT DATA REFERNECE 12
3-7 POWER SEQUENCE 13
4 OPTICAL SFECIFICATIONS 14
5 MECHANICAL CHARACTERISTICS 18
6 RELIABLITY 27
7 INTERNATIONAL STANDARDS
7-1 SAFETY 28
7-2 EMC 28
8 PACKING
8-1 DESIGNATION OF LOT MARK 29
8-2 PACKING FORM 29
9 PRECAUTIONS 30
A APPENDIX. Enhanced Extended Display Identification Data 32-34
Ver. 1.0 26. Apr. 2011 2 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
RECORD OF REVISIONS
EDID
Revision No Revision Date Page Description
ver
0.0 10. Sep. 2010 - First draft 0.0
0.1 27. Oct. 2010 14, 32-34 Update Color Coordinates, EDID 0.1
0.2 23. Mar. 2011 6 Update Electrical Characteristics -
11 Update Timing Table -
14 Update Optical Characteristics -
15 Update Gray scale specification -
20-21 Update Mechanical Drawing -
1.0 26. Apr. 2011 - Final Specification 1.0
14 Update Optical Characteristics -
20-21 Update Mechanical Drawing -
29 Update Packing Form -
Ver. 1.0 26. Apr. 2011 3 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
1. General Description
The LP173WF3 is a Color Active Matrix Liquid Crystal Display with an integral RGB LED backlight system.
The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display
operating in the normally black mode. This TFT-LCD has 17.3 inches diagonally measured active display
area with Full HD resolution(1920 horizontal by 1080 vertical pixel array). Each pixel is divided into Red,
Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the
sub-pixel color is determined with a 10-bit gray scale signal for each dot, thus, presenting a palette of more
than 1.073G(True) colors.
The LP173WF3 has been designed to apply the interface method that enables low power, high speed, low
EMI. The LP173WF3 is intended to support applications where thin thickness, low power are critical factors
and graphic displays are important. In combination with the vertical arrangement of the sub-pixels, the
LP173WF3(SLB2) characteristics provide an excellent flat display for office automation products such as
Notebook PC.
17.3 TFT-LCD Panel
(1920 X 1080)
General Features
Active Screen Size 17.3 inches diagonal
Outline Dimension 398.1 (H, Typ) 234.3 (V, Typ) 7.2(D, Max) mm
Pixel Pitch 0.199mm 0.199 mm
Pixel Format 1920 horiz. by 1080 vert. Pixels RGB strip arrangement
Color Depth 10-bit, 1.073G colors
Luminance, White 300 cd/m2(Typ.), 5 point
Power Consumption 18.2W (Typ.) [4.10W (Logic, Typ.) + 14.1W (B/L, Typ.)]
Weight (Max.) 830g
Display Operating Mode Transmissive mode, Normally black
Surface Treatment Hard coating(3H), Anti-Glare treatment of the front polarizer
Ver. 1.0 26. Apr. 2011 4 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
2. Absolute Maximum Ratings
The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.
Table 1. ABSOLUTE MAXIMUM RATINGS
Values
Parameter Symbol Units Notes
Min Max
Power Input Voltage VCC -0.3 4.0 Vdc at 25 r 5qC
Operating Temperature TOP 0 50 qC 1
Storage Temperature HST -20 60 qC 1
Operating Ambient Humidity HOP 10 90 %RH 1
Storage Humidity HST 10 90 %RH 1
Note : 1. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be 39qC Max, and no condensation of water.
Note : 2. Storage Condition is guaranteed under packing condition.
90% 80%
60 60%
Wet Bulb 50
Humidity[(%)RH]
Temperature [ ] Storage
40 40%
30 Operation
20
20%
10
0
10%
-20 0 10 20 30 40 50 60 70 80
Dry Bulb Temperature [ ]
Ver. 1.0 26. Apr. 2011 5 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3. Electrical Specifications
3-1. Electrical Characteristics
The LP173WF3(SLB2)requires two power inputs. One is employed to power the LCD electronics and to
drive the TFT array and liquid crystal. The second input which powers the LED, is typically generated by an
LED Driver. The LED Driver is an internal unit to the LCD.
Table 2. ELECTRICAL CHARACTERISTICS
Values
Parameter Symbol Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VCC 3.0 3.3 3.6 VDC
Power Supply Input Current ICC 1.03 1.24 1.49 A 1
Power Consumption Pc - 4.1 4.92 Watt 1
Differential Impedance Zm 90 100 110 Ohm 2
LED Backlight :
Power Supply Input Voltage VBL+ 7.5 14.4 21 VDC
Operating Voltage VLED (R,G,B) - - 45 V 3
Operating Current per string ILED (R,G,B) - - 50 mA 3
Power Consumption PBL 14.1 16.2 Watt 4
Life Time 15,000 - - Hrs 5
Note)
1. The specified current and power consumption are under the Vcc = 3.3V , 25 , fv = 60Hz condition
whereas Mosaic pattern (8x6) is displayed and fv is the frame frequency.
2. This impedance value is needed to proper display and measured form LVDS Tx to the mating connector.
3. RGB LED Operating Voltage and Operating Current per string should be within Max. SPEC.
4. The LED power consumption ( Typ ) shown above does include power of internal LED driver circuit
for typical current condition. ( Luminance = 300nit condition )
The power consumption ( Max ) condition is R,G,B LED 100% Dimming.
5. The life time is determined as the time at which brightness of LED is 50% compare to that of initial value
at the typical LED current.
Ver. 1.0 26. Apr. 2011 6 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3-2. Interface Connections
This LCD employs two interface connections, a 50 pin connector is used for the module electronics interface
and the other connector is used for the integral backlight system.
Table 3. MODULE CONNECTOR PIN CONFIGURATION (CN1)
Pin Symbol Description Notes
1 GND Ground
2 AVDD Power Supply, 3.3V Typ.
3 AVDD Power Supply, 3.3V Typ.
4 AVDD Power Supply, 3.3V Typ.
5 AVDD Power Supply, 3.3V Typ.
6 AVDD Power Supply, 3.3V Typ.
7 AVDD Power Supply, 3.3V Typ.
8 AVDD Power Supply, 3.3V Typ.
9 DVDD Digital Power supply (3.3V Typ)
10 DVDD Digital Power supply (3.3V Typ)
11 BIST BIST
12 Clk EEDID Two wire serial interface clock 1, Interface chips
13 DATA EEDID Two wire serial interface data 1.1 LCD : LGE (MAKO)
14 GND Ground including LVDS Receiver,
15 RXinO0- - LVDS differential data input, Chan 0-Odd VESA LVDS 10bit Format
16 RXinO0+ + LVDS differential data input, Chan 0-Odd 1.2 System :
17 GND Ground
* Pin to Pin compatible with LVDS
18 RXinO1 - LVDS differential data input, Chan 1-Odd
19 RXinO1+ + LVDS differential data input, Chan 1-Odd
20 GND Ground 2.Connector
21 RXinO2- - LVDS differential data input, Chan 2-Odd 2.1 LCD : JAE FI-VHP50S-A-HF11
22 RXinO2+ + LVDS differential data input, Chan 2-Odd or equivalent
23 GND Ground 2.2 Mating: JAE or equivalent
24 RXOC- - LVDS Differential Clock input (Odd) 2.3 Connector pin arrangement
25 RXOC+ + LVDS Differential Clock input (Odd)
LCD rear view
26 GND Ground
27 RXinO3- - LVDS differential data input, Chan 3-Odd 50
28 RXinO3+ + LVDS differential data input, Chan 3-Odd
1
29 GND Ground
30 RXinO4- - LVDS differential data input, Chan 4-Odd
31 RXinO4+ + LVDS differential data input, Chan 4-Odd
32 GND Ground [LCD Module Rear View]
33 RXinE0- - LVDS differential data input, Chan 0-Even
34 RXinE0+ + LVDS differential data input, Chan 0-Even
35 GND Ground
36 RXinE1- - LVDS differential data input, Chan 1-Even
37 RXinE1+ + LVDS differential data input, Chan 1-Even
38 GND Ground
39 RXinE2- - LVDS differential data input, Chan 2-Even
40 RXinE2+ + LVDS differential data input, Chan 2-Even
41 GND Ground
42 RXEC- - LVDS Differential Clock input (Even)
43 RXEC+ + LVDS Differential Clock input (Even)
44 GND Ground
45 RXinE3- - LVDS differential data input, Chan 3-Even
46 RXinE3+ + LVDS differential data input, Chan 3-Even
47 GND Ground
48 RXinE4- - LVDS differential data input, Chan 4-Even
49 RXinE4+ + LVDS differential data input, Chan 4-Even
50 GND Ground
Ver. 1.0 26. Apr. 2011 7 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3-3. LVDS Signal Timing Specifications
3-3-1. DC Specification
Symb
Description Min Max Unit Notes
ol
LVDS Differential Voltage |VID| 100 600 mV -
LVDS Common mode Voltage VCM 0.6 1.8 V -
LVDS Input Voltage Range VIN 0.3 2.1 V -
3-3-2. AC Specification
Description Symbol Min Max Unit Notes
85MHz > Fclk
tSKEW - 400 + 400 ps
65MHz
LVDS Clock to Data Skew Margin
65MHz > Fclk
tSKEW - 600 + 600 ps
25MHz
LVDS Clock to Clock Skew Margin (Even
tSKEW_EO - 1/7 + 1/7 Tclk -
to Odd)
Maximum deviation
FDEV - 3 % -
of input clock frequency during SSC
Maximum modulation frequency
FMOD - 200 KHz -
of input clock during SSC
Ver. 1.0 26. Apr. 2011 8 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
< Clock skew margin between channel >
Freq.
Fmax
Fcenter
Fmin
Time
< Spread Spectrum >
3-3-3. Data Format
1) LVDS Data Port
< LVDS Data Format >
Ver. 1.0 26. Apr. 2011 9 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
Table 4. BACKLIGHT CONNECTOR PIN CONFIGURATION (CN2)
Pin Symbol Description Notes
1 GND Ground
2 VBL+ 7V - 20V LED Power 1. Connector
1.1 LCD : Hirose DF19KR
3 VBL+ 7V - 20V LED Power or equivalent
1.2 Mating : Hirose equivalent.
4 VBL+ 7V - 20V LED Power 1.3 Connector pin arrangement
5 VBL+ 7V - 20V LED Power 1 20
6 VBL+ 7V - 20V LED Power
7 VBL- Ground
[LCD Module Rear View]
8 VBL- Ground
9 VBL- Ground
10 VBL- Ground
11 VBL- Ground
12 NC No Connection
13 GND Ground
14 I2C_DATA DATA for RGB control
15 I2C_CLK CLK for RGB control
16 GND Ground
17 BL_Enable BL On/Off Control
(On: 3.0V ~ 3.6V, Off: 0V ~ 0.5V)
18 BLIM PWM for Luminance Control
(200~1KHz, 3.3V, 5~100%) or DC(0~3.3v)
19 Reserved Reserved
20 GND Ground
Ver. 1.0 26. Apr. 2011 10 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3-3. Signal Timing Specifications
This is the signal timing required at the input of the User connector. All of the interface signal timing should be
satisfied with the following specifications and specifications of LVDS Tx/Rx for its proper operation.
Table 5. TIMING TABLE
ITEM Symbol Min Typ Max Unit Note
DCLK Frequency fCLK 67.17 69.35 72.65 MHz LVDS 2 Port
Period tHP 1020 1040 1078
Hsync Width tWH 16 16 16 tCLK
Width-Active tWHA 960 960 960
Period tVP 1096 1111 1122
Vsync
Width tWV 5 5 5 tHP
Width-Active tWVA 1080 1080 1080
Horizontal back porch tHBP 34 40 50
tCLK
Data Horizontal front porch tHFP 10 24 52
Enable Vertical back porch tVBP 10 23 28
tHP
Vertical front porch tVFP 1 3 9
Appendix) 1) All reliabilities are specified for timing specification based on refresh rate of 60 Hz. Even though actual
performance in 50Hz and 48Hz for low power is displayed normally, remark and inform to user that display quality in
50 Hz and 48 Hz is out of guarantee range.
2) Timing is controlled by EEDID Timing at refresh rate of 60Hz. All display quality is guaranteed based on refresh rate
of 60Hz controlled by EEDID timing.
Condition : VCC =3.3V
3-4. Signal Timing Waveforms (Normal status)
High: 0.7VCC
Data Enable, Hsync, Vsync
Low: 0.3VCC
tCLK 0.5 Vcc
DCLK
tHP
Hsync t
WH
tHBP tWHA tHFP
Data Enable
tVP
tWV
Vsync tVFP
tVBP tWVA
Data Enable
Ver. 1.0 26. Apr. 2011 11 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3-5. Color Input Data Reference
The brightness of each primary color (red,green and blue) is based on the 10-bit gray scale data input for the
color ; the higher the binary input, the brighter the color. The table below provides a reference for color
versus data input.
Table 6. COLOR DATA REFERENCE
Ver. 1.0 26. Apr. 2011 12 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
3-6. Power Sequence
90% 90%
Power Supply Input
VCC
0V 10% 10%
T5 T6 T7
T1 T2 Valid Data
Interface Signal, Vi
LVDS
0V
T3 T4
LED input Voltage
VLED T8 T11
0V
Dimming control signal Valid Data
Of LED BL 0V (Low)
PWM
T9 T10
LED on/off control Signal
0V (Off)
LED_EN
Table 6. POWER SEQUENCE TABLE
Value
Parameter Units
Min. Typ. Max.
T1 0.5 - 10 ms
T2 0 - 50 ms
T3 300 - - ms
T4 300 - - ms
T5 0 - 50 ms
T6 3 - 10 ms
T7 400 - - ms
T8 10 - - ms
T9 10 - - ms
T10 10 - - ms
Note) T11 10 - - ms
1. Valid Data is Data to meet "3-3. LVDS Signal Timing Specifications"
2. Please avoid floating state of interface signal at invalid period.
3. When the interface signal is invalid, be sure to pull down the power supply for LCD VCC to 0V.
4. Lamp power must be turn on after power supply for LCD and interface signal are valid.
Ver. 1.0 26. Apr. 2011 13 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
4. Optical Specification
Optical characteristics are determined after the unit has been `ON' and stable for approximately 30 minutes in
a dark environment at 25qC. The values specified are at an approximate distance 50cm from the LCD surface
at a viewing angle of ) and 4 equal to 0q.
FIG. 1 presents additional information concerning the measurement equipment and method.
FIG. 1 Optical Characteristic Measurement Equipment and Method
LCD Module Pritchard 880 or
Optical Stage(x,y)
equivalent
50cm
Table 8. OPTICAL CHARACTERISTICS
Ta=25qC, VCC=3.3V, fV=60Hz, fCLK= 69.35MHz(LVDS 2Port), Finished Color Calibration
Values
Parameter Symbol Units Notes
Min Typ Max
Contrast Ratio CR 600 800 - 1
Surface Luminance, white LWH 250 300 - cd/m 2 2
Luminance Variation G WHITE - 1.4 1.6 3
Response Time 4
Rise Time+Decay Time (W to B) TrR +TrD - 35 50 ms
Color Coordinates
RED RX 0.652 0.682 0.712
RY 0.275 0.305 0.335
GREEN GX 0.169 0.199 0.229
GY 0.691 0.721 0.751
BLUE BX 0.121 0.151 0.181
BY 0.015 0.045 0.075
WHITE WX 0.283 0.313 0.343
WY 0.299 0.329 0.359
Viewing Angle 5
x axis, right()=0q) 4r 80 89 - degree
x axis, left ()=180q) 4l 80 89 - degree
y axis, up ()=90q) 4u 80 89 - degree
y axis, down ()=270q) 4d 80 89 - degree
Ver. 1.0 26. Apr. 2011 14 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
Note)
1. Contrast Ratio(CR) is defined mathematically as
Surface Luminance with all white pixels
Contrast Ratio =
Surface Luminance with all black pixels
2. Surface luminance is the 5point (1~5)average across the LCD surface 50cm from the surface
with all pixels displaying white Luminance (300nit). For more information see FIG 2.
3. Luminance % uniformity is measured for 13 point For more information see FIG 2.
WHITE = Maximum(LN1,LN2, ..... LN13) Minimum(LN1,LN2, ..... LN13)
4. Response time is the time required for the display to transition from white to black (rise time, TrR) and
from black to white(Decay Time, TrD). For additional information see FIG 3.
5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD surface. For more information see FIG 4.
6. Gray scale specification * fV=60Hz
Gray Level Luminance [%] (Typ)
L0 0.10
L63 0.23
L127 0.79
L191 2.13
L255 4.49
L319 7.70
L383 11.7
L447 16.3
L511 21.4
L575 27.9
L639 35.2
L703 43.1
L767 51.8
L831 62.1
L895 74.4
L959 87.6
L1023 100
-. L Reference Level : 16 steps from gray 0 to gray 1023
Ver. 1.0 26. Apr. 2011 15 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
FIG. 2 Luminance
H
10mm A
6 7 8 10mm
2 3
B H,V : ACTIVE AREA
V A : H/4 mm
9 1 10
B : V/4 mm
POINTS: 13 POINTS
4 5 13
11 12
Active Area
FIG. 3 Response Time
The response time is defined as the following figure and shall be measured by switching the input signal
for "black" and "white" In condition of RGB LED Duty 100%
TrR TrD
%
100
90
Optical
Response
10
0 white white
black
In other condition (For example, RGB LED Duty 80%), The response time defined as measurement data
which is not lack
Ver. 1.0 26. Apr. 2011 16 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
FIG. 4 Viewing angle
Normal
Eye Y
I = 90 q , Up
I = 180 q ,
Left T
I
I = 0q ,
Right
I = 270 q ,
Down
Ver. 1.0 26. Apr. 2011 17 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
5. Mechanical Characteristics
The contents provide general mechanical characteristics for the model LP173WF3(SLB2). In addition the
figures in the next page are detailed mechanical drawing of the LCD.
Horizontal 398.1 0.5 mm
Outline Dimension Vertical 234.3 0.5 mm
Depth (Max) 7.2 mm
Horizontal 386.70(H)
Bezel Area
Vertical 219.75(V)
Horizontal 381.90 mm
Active Display Area
Vertical 214.80 mm
Weight 830 g (MAX)
Surface Treatment Hard coating(3H), Anti-Glare treatment of the front polarizer
Ver. 1.0 26. Apr. 2011 18 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 26. Apr. 2011 19 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 26. Apr. 2011 20 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
[ DETAIL DESCRIPTION OF SIDE MOUNTING SCREW ]
Notes : 1. Screw plated through the method of non-electrolytic nickel plating is preferred
to reduce possibility that results in vertical and/or horizontal line defect due to
the conductive particles from screw surface.
Note) Unit:[mm], General tolerance: r 0.5mm
Ver. 1.0 26. Apr. 2011 21 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.(Appendix)
Gap check for securing the enough gap between LCM
1
and System cover.
Max Thickness
Sponge
LCM Reflector Side
System Cover
A Boundary Line
1.Rear side of LCM is sensitive against external stress,and previous check
about interference is highly needed.
Define 2.In case there is something from system cover comes into the boundary
above,mechanical interference may cause the FOS defects.
(Eg:Ripple,White spot..)
2 Check if antenna cable is sufficiently apart from T-CON of LCD Module.
Define
NO GOOD GOOD
1.If system antenna is overlapped with T-CON,it might be cause the noise.
Ver. 1.0 26. Apr. 2011 22 / 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
LP173WF3
Liquid Crystal Display
Product Specification
LGD Proposal for system cover design.
Gap check for securing the enough gap between LCM
3
and System hinge.
LCM Reflector Side
COF
(D-IC)
Hinge
Side Mount Screw Hole (4ea)
GAP:Min2.0mm ("I" TYPE) ("L" TYPE)
1.At least 2.0mm of gap needs to be secured to prevent the shock
Define related defects.
2."L" type of hinge is recommended than "I" type under shock test.
4 Checking the path of the System wire.
#3 #2
#1
Ok Bad Good
1.COF area needs to be handled with care.
2.GOOD ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
