Image preview - the first page of the document
![Panel_LiteMax_DLF1555_0_[DS]](/pics/5eafe94d8f742.gif)
>> Download Panel_LiteMax_DLF1555_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LITEMAX DLF/DLH1555
Sunlight readable 15" LED B/L LCD
(2st Edition 8/14/2007 )
All information is subject to change without notice.
Approved by Checked by Prepared by
David Sharline River,Eric
LITEMAX Electronics Inc.
8F, No.137, Lane 235, Bau-chiau Rd.,
Shin-dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage: http://www.litemax.com.tw
Page 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Record of Revision
0B
Version and Date Page Old Description New Description Remark
8/14/07" v.01 First Release
8/11/08" v2.1 7
Revision
9 Power Consumption 24.3W Power Consumption 14.95W
Connector Part: HD2505-02
11
Backlight Connector Part: or equivalent
Add
TBD Matching Connector Part
No.:TD2505-02or equivalent
15 TEST CONDITIONS
LED Driver Board : Litemax LED Driver Board : Litemax
LID15A01 LID15A02
OPTICAL SPECIFICATIONS
Color chromaticity Revision
Rx=0.613 Rx=0.603
Ry=0.334 Ry=0.371
Gx=0.302 Gx=0.375
Gy=0.567 Gy=0.541
Bx=0.144 Bx=0.165
By=0.102 By=0.084
Wx=0.313 Wx=0.341
Wy=0.329 Wy=0.329
Page 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
1B
Record of Revision ............................................................................................................ 2
U U
Contents ............................................................................................................................ 3
U U
GENERAL DESCRIPTION................................................................................................ 4
U U
OVERVIEW................................................................................................................ 4
U U
FEATURES ................................................................................................................ 4
U U
APPLICATION ........................................................................................................... 4
U U
GENERAL SPECIFICATI0NS .................................................................................... 4
U U
MECHANICAL SPECIFICATIONS ............................................................................. 5
U U
ABSOLUTE MAXIMUM RATINGS .................................................................................... 6
U U
ABSOLUTE RATINGS OF ENVIRONMENT .............................................................. 6
U U
ELECTRICAL ABSOLUTE RATINGS ........................................................................ 6
U U
ELECTRICAL CHARACTERISTICS ................................................................................. 8
U U
TFT LCD MODULE .................................................................................................... 8
U U
BACKLIGHT UNIT ..................................................................................................... 9
U U
BLOCK DIAGRAM .......................................................................................................... 10
U U
TFT LCD MODULE .................................................................................................. 10
U U
INPUT TERMINAL PIN ASSIGNMENT ............................................................................11
U U
TFT LCD MODULE ...................................................................................................11
U U
BACKLIGHT UNIT ....................................................................................................11
U U
COLOR DATA INPUT ASSIGNMENT ...................................................................... 12
U U
INTERFACE TIMING ...................................................................................................... 13
U U
INPUT SIGNAL TIMING SPECIFICATIONS ............................................................ 13
U U
POWER ON/OFF SEQUENCE ................................................................................ 14
U U
OPTICAL CHARACTERISTICS ...................................................................................... 15
U U
TEST CONDITIONS ................................................................................................ 15
U U
OPTICAL SPECIFICATIONS ................................................................................... 15
U U
PRECAUTIONS .............................................................................................................. 19
U U
HANDLING PRECAUTIONS.................................................................................... 19
U U
STORAGE PRECAUTIONS..................................................................................... 19
U U
OPERATION PRECAUTIONS ................................................................................. 19
U U
Page 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
GENERAL DESCRIPTION
2B
OVERVIEW
10B
CM1555E is a 15.0" TFT Liquid Crystal Display module with LED Backlight units and 20
pins LVDS interface. This module supports 1024 x 768 XGA mode and can display 16.2M
colors. The PSWG is to establish a set of displays with standard mechanical dimensions
and select electrical interface requirements for an industry standard 15.0" XGA LCD panel
and the inverter module for Backlight is not built in.
FEATURES
1B
- LED B/L
- 1000 nits
- Wide dimming range
- XGA (1024 x 768 pixels) resolution
- DE(data enable) only mode
- LVDS interface with 1pixel/clock
- PSWG (panel standardization working group)
- Wide operating temperature.
- RoHs compliance
APPLICATION
12B
- TFT LCD monitor
- Factory application
- Amusement
- Transportation
GENERAL SPECIFICATI0NS
13B
Item Specification Unit Note
Active Area 304.128 (H) x 228.096(V) (15.0"LED Backlight) mm
(1)
Bezel Opening Area 307.4(H) x 231.3(V) mm
Driver Element a-Si TFT active matrix - -
Pixel Number 1024 x R.G.B x 768 pixel -
Pixel Pitch 0.297(H) x 0.297(W) mm -
Pixel Arrangement RGB vertical stripe - -
Display Colors 16.2M color color -
Display Mode Normally white - -
Surface Treatment Hard Coating (3H), Anti-Glare ( Haze 25) - -
Page 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
MECHANICAL SPECIFICATIONS
14B
Item Min. Typ. Max. Unit Note
Horizontal(H) 326.0 326.5 327.0 mm
Module (1)
Size Vertical(V) 253.0 253.5 254.0 mm
Depth(D) - - 14.5 mm (1)(2)
Weight - - 1200 g -
Note (1) Please refer to the attached drawings for more information of front and back
outline dimensions. Note
(2) The depth is without connector.
Page 5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
ABSOLUTE MAXIMUM RATINGS
3B
ABSOLUTE RATINGS OF ENVIRONMENT
15B
Value
Item Symbol Unit Note
Min. Max.
Storage Temperature TST -40 80 C (1)
Operating Ambient Temperature TOP -20 60 C (1), (2), (6)
Shock (Non-Operating) SNOP - 50G G (3), (5)
Vibration (Non-Operating) VNOP - 1.5 G (4), (5)
-40 -20 -10 10 20 40 60 80
