Image preview - the first page of the document
![Panel_LiteMax_DLF1954_0_[DS]](/pics/5eafe97c8f361.gif)
>> Download Panel_LiteMax_DLF1954_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LITEMAX DLF/DLH1954
Sunlight Readable 19" LED B/L LCD
(1st Edition 6/6/2008 )
All information is subject to change without notice.
Approved by Checked by Prepared by
David Sharline Eric
LITEMAX Electronics Inc.
8F, No.137, Lane 235, Bau-chiau Rd.,
Shin-dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage: http://www.litemax.com.tw
Page 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Record Revision
Version and Date Page Old Description New Description Remark
Page 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Contents
Record Revision 2
Contents 3
Handling Precautions 4
General Description 5
Display Characteristics 5
Optical Characteristics 6
Optical Test 6
Test Mode 7
Functional Block Diagram 9
Absolute Maximum Ratings 10
Absolute Ratings of TFT LCD Module 10
Absolute Ratings of Backlight Unit 10
Absolute Ratings of Environment 10
Electrical Characteristics 11
TFT LCD Module 11
Pixel Format Image 12
The Input Data Format 13
Signal Description 14
Interface Timing 15
Power ON/OFF Sequence 17
Connector & Pin Assignment 18
TFT LCD Module 18
Page 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Handling Precautions
1) Since front polarizer is easily damaged, be extremely careful when handling panel.
2) Be sure to turn off power supply when inserting or disconnecting from input
connectors.
3) Wipe off water immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on a
hard surface.
6) Since CMOS LSI is used in this module, be careful of static electricity by grounding
those handling the display.
7) Do not open nor modify the module assembly.
8) Do not press or touch the panel surface with hands or tools.
9) Do not press or move the reflector sheet at the back of the module in any direction.
10) **At the insertion or removal of the signal Interface Connector, be sure not to rotate
nor tilt the interface connector of the TFT module.
11) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for
example), do not twist nor bend the TFT Module even momentarily. Design the
enclosure so that no bending/twisting forces are applied to the TFT module. Otherwise
the TFT module may be damaged.
Page 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
General Description
AU1954 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a
driver circuit, and a backlight system. The screen format is intended to support the SXGA
(1280(H) x 1024(V)) screen and 16.7M colors (RGB 6-bits + HiFRC data). All input signals
are LVDS interface compatible. Inverter card of backlight is not included. AU1954 is
designed for a display unit of outdoor display.
Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 482.6 (19.0" )
Active Area [mm] 376.32 (H) x 301.06 (V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.294 (per one triad) x 0.294
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance [cd/m2] 1000 (center, Typ)
Contrast Ratio 800 : 1 (Typ)
Optical ResponseTime [msec] 5 ms(Typ, on/off)
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt]
36.11W (Typ)
(PDD=5.11W, PBL=31 W )
Weight [Grams] 2100
Physical Size (H x V x D) [mm] 396 (H) x 324 (V) x 16.3(D) (Typ)
Electrical Interface Dual channel LVDS
Surface Treatment Hard-coating (3H), Non-Glare treatment
16.7M colors (RGB 6-bit data + HiFRC
Support Color
data)
Temperature Range
Operating 0 to +50
Storage (Non-Operating) [oC] [oC] -20 to +60
RoHS Compliance RoHS Compliance
Page 5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Optical Characteristics
The optical characteristics are measured under stable conditions at 25
(Room Temperature):
Optical Test
Test Conditions
