Image preview - the first page of the document
![Panel_LiteMax_SSD1505_0_[DS]](/pics/5eafe9ebe69cb.gif)
>> Download Panel_LiteMax_SSD1505_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
LITEMAX
SSD1505
Spanpixel
Sunlight Readable 15" LCD Display
(2nd Edition 10/21/2010 )
All information is subject to change without notice.
Approved by Checked by Prepared by
Ming Hank Jacky
LITEMAX Electronics Inc.
8F, No.137, Lane 235, Bau-Chiau Rd.,
Shin-Dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage: http://www.litemax.com/
Page 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
RECORD OF REVISION
Version Date Description Remark
V1.0 1/21/2010 Initial Release
Page 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
CONTENTS
RECORD OF REVISION .................................................................................................. 2
1.0 GENERAL DESCRIPTION.......................................................................................... 4
1.1 OVERVIEW.......................................................................................................... 4
1.2 FEATURES .......................................................................................................... 4
1.3 APPLICATION...................................................................................................... 4
1.4 GENERAL SPECIFICATI0NS .............................................................................. 4
2.0 ELECTRICAL CHARACTERISTICS ........................................................................... 5
2.1 ELECTRICAL CHARACTERISTICS .................................................................... 5
2.2 LCD PANEL SIGNAL PROCESSING BOARD ..................................................... 6
2.3 BACKLIGHT CONNECTOR PIN CONFIGURATION ........................................... 7
2.4 SIGNAL TIMING SPECIFICATIONS .................................................................... 7
2.5 SIGNAL TIMING WAVEFORMS .......................................................................... 8
3.0 OPTICAL CHARACTERISTICS .................................................................................. 9
3.1 TEST CONDITIONS ............................................................................................ 9
3.2 OPTICAL SPECIFICATIONS ............................................................................... 9
4.0 MECHANICAL CHARACTERISTICS ........................................................................ 12
SSD1505 MECHANICAL SPECIFICATION ............................................................. 12
5.0 PRECAUTIONS ........................................................................................................ 13
5.1 HANDLING PRECAUTIONS.............................................................................. 13
5.2 STORAGE PRECAUTIONS............................................................................... 13
5.3 OPERATION PRECAUTIONS ........................................................................... 13
6.0 AD Board & OSD Functions ...................................................................................... 14
6.1 AD BOARD GENERAL SPECIFICATIONS ........................................................ 14
6.2 SUPPORTED TIMING (*by your panel resolution)............................................. 14
6.3 MEMBRANE CONTROL BUTTOM .................................................................... 15
6.4 OSD FUNCTIONS ............................................................................................. 15
Page 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
1.0 GENERAL DESCRIPTION
1.1 OVERVIEW
The SSD1505 is a 15 inch color TFT-LCD display with special aspect ratio 16:3 and XGA wide
resolution 1280 x 242 (1280 horizontal by 242 vertical pixel array). It is Litemax's Spanpixel
series product which designed for high brightness 1000 nits sunlight readable display, power
efficiency LED backlight system and fanless display. The SSD1505 build in AD board supports
input port VGA.
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in
vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit
gray scale signal for each dot. It is intended to support display where wide viewing angle, high
color saturation, and high color depth.
1.2 FEATURES
- 15" SXGA TFT LCD
- LED backlight
- 1000 nits Sunlight Readable
- Long Life Time
- Thin and Light
- DC 12V input
1.3 APPLICATION
- Out/Indoor Display
- Out/Indoor Digital Signage
- Quick Service Restaurant Display Product
- Transportation
1.4 GENERAL SPECIFICATI0NS
Model No. SSD1505
LCD Display 15" Wide LED Backlight LCD
Display Area (mm) 376.3 (H) x 71.2 (V)
Display Surface Non-glare hard coated
Luminance 1000 cd/m2
Resolution 1280 x 242
Contrast Ratio 1000 : 1 (Typ)
Display Colors 16.7M colors
Pixel Arrangement RGB (Red, Green, Blue) vertical stripe
Pixel Pitch (mm) 0.294mm
Response Time 5ms (Typ.)
Signal Connector 15 Pin D-sub
F/R Control Button Power Switch, Menu, Select (+,-)
OSD Menu Brightness, Contrast, H/V Position, Color, Phase, Clock,
Language, Management
Power Consumption At maximum luminance and checkered flag pattern
15W (Max)
Option Touch for customize (Resistive/ Capacitive)
Specifications subject to change without notice.
Page 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
2.0 ELECTRICAL CHARACTERISTICS
2.1 ELECTRICAL CHARACTERISTICS
