Image preview - the first page of the document
![Panel_PANDA_LM215DA-T01_2_[DS]](/pics/5eb000d922919.gif)
>> Download Panel_PANDA_LM215DA-T01_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
PANDA LM215DA-T01 Tentative Spec
The information described in the specification is preliminary and can be
changed without prior notice
ACCEPTED BY
1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PANDA LM215DA-T01 Tentative Spec
- CONTENTS -
REVISION HISTORY ------------------------------------------------------- 3
1. GENERAL DESCRIPTION ------------------------------------------------------- 4
1.1 OVERVIEW
1.2 CHARACTERISTICS
2. ABSOLUTE MAXIMUM RATINGS ------------------------------------------------------- 4
2.1 ABSOLUTE RATINGS OF ENVIRONMENT (BASED ON CPL MODULE LM215DB-T01)
2.2 ABSOLUTE RATINGS OF ENVIRONMENT (OPEN CELL)
3. ELECTRICAL CHARACTERISTICS ------------------------------------------------------- 5
3.1 ABSOLUTE MAXIMUN RATING
3.2 CONTROL CIRCUIT DRIVING
4. INPUT TERMINAL PIN ASSIGNMENT --------------------------------------------------------7
5.1 TFT LCD OPEN CELL
5.2 BLOCK DIAGRAM (OPEN CELL)
5.3 LVDS INTERFACE
5.4 COLOR DATA INPUT ASSIGNMENT
5. INTERFACE TIMING -----------------------------------------------------11
5.1 INPUT SIGNAL TIMING SPECIFICATIONS
6. OPTICAL CHARACTERISTICS ----------------------------------------------------- 12
6.1 OPTICAL SPECIFICATION
6.2 FLICKER ADJUSTMENT
7. DEFINITION OF LABELS -----------------------------------------------------14
7.1 OPEN CELL LABEL
7.2 PACKING LABEL
8. PACKAGING ----------------------------------------------------- 14
9.1 PACKING SPECIFICATIONS
9.2 PACKING METHOD
9. PRECAUTIONS -----------------------------------------------------15
10. RELIABILITY TEST ITEMS -----------------------------------------------------16
11. MECHANICAL DRAWING ----------------------------------------------------- 17
2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PANDA LM215DA-T01 Tentative Spec
REVISION HISTORY
MODEL NO: LM215DA-T01
DATE NO. REVISED No. PAGE SUMMARY NOTE
1 T 1.0 1st issue Tentative
Add flicker adjust method on P14.
2011/7/22 2 T2.0 P14,P17 Tentative
Add ESD specification on P17
3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
PANDA LM215DA-T01 Tentative Spec
1. GENERAL DESCRIPTION
1.1 OVERVIEW
This module is color active matrix LCD Open-cell incorporating amorphous silicon TFT (Thin Film
Transistor). It is composed of a color TFT-LCD panel, driver ICs, PWB. Graphics and texts can be
