Image preview - the first page of the document
![Panel_QDI_QD15AL01_Rev-04_0_[DS]](/pics/5eb0032bf0ddd.gif)
>> Download Panel_QDI_QD15AL01_Rev-04_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 15.4" WSXGA+ Color TFT-LCD
Model Name B154SW01 V7
Customer Date Approved by Date
Jerry Chen 2007/05/23
Checked &
Prepared by
Approved by
Derrick Lee 2007/05/23
Note: This Specification is subject to change without MDBU Marketing Division /
notice. AU Optronics corporation
document version 0.0 1/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions....................................................................................... 4
2. General Description.......................................................................................... 5
2.1 Display Characteristics ...................................................................................................... 5
2.2 Optical Characteristics....................................................................................................... 6
3. Functional Block Diagram.............................................................................. 11
4. Absolute Maximum Ratings........................................................................... 12
4.1 TFT LCD Module ............................................................................................................. 12
4.2 Backlight Unit................................................................................................................... 12
4.3 Absolute Ratings of Environment..................................................................................... 12
5. Electrical characteristics ............................................................................... 13
5.1 TFT LCD Module ............................................................................................................. 13
5.2 Backlight Unit................................................................................................................... 15
6. Signal Characteristic ...................................................................................... 17
6.1 Pixel Format Image.......................................................................................................... 17
6.2 The input data format....................................................................................................... 18
6.3 Signal Description ............................................................................................................ 19
6.4 Interface Timing ............................................................................................................... 22
6.5 Power ON/OFF Sequence ............................................................................................... 24
7. Connector & Pin Assignment ........................................................................ 25
7.1 TFT LCD Module ............................................................................................................. 25
7.2 Backlight Unit................................................................................................................... 25
7.3 Signal for Lamp connector............................................................................................... 25
8. Vibration and Shock Test............................................................................... 26
8.1 Vibration Test ................................................................................................................... 26
8.2 Shock Test Spec: ............................................................................................................. 26
9. Reliability......................................................................................................... 27
10. Mechanical Characteristics ......................................................................... 28
10.1 LCM Outline Dimension ................................................................................................. 28
10.2 Screw Hole Depth and Center Position ......................................................................... 30
11. Shipping and Package ................................................................................. 31
11.1 Shipping Label Format................................................................................................... 31
11.2. Carton package............................................................................................................. 32
11.3 Shipping package of palletizing sequence ..................................................................... 32
12. Appendix: EDID description......................................................................... 33
document version 0.0 2/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2006/10/18 All First Edition for Customer
0.2 2007/05/23 1 First Edition for Customer Final Edition for Customer
1 B154SW01 V7 QD15AL01 (B154SW01 V7)
document version 0.0 3/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was
taken out from the container, do not press the center of the CCFL Reflector edge.
Instead, press at the far ends of the CFL Reflector edge softly. Otherwise the TFT
Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow
local ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source(, IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current
Circuit(IEC60950 or UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 0.0 4/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B154SW01 V7 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and backlight system. The screen format is intended to support the WSXGA+
(1680(H) x 1050(V)) screen and 262k colors (RGB 6-bits data driver). All input signals are
LVDS interface compatible. Inverter of backlight is not included.
B154SW01 V7 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 390.8 (15.4"W)
Active Area [mm] 331.38 X 207.11
Pixels H x V 1680 x 3(RGB) x 1050
Pixel Pitch [mm] 0.19725X0.19725
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ICCFL=6.0mA) [cd/m2] 200 typ. (5 points average)
Note: ICCFL is lamp current 180 min. (5 points average)
(Note1)
Luminance Uniformity 1.3 max. (5 points)
Contrast Ratio 400 typ
300 min.
Optical Rise Time/Fall Time [msec] 6/10 typ.
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 2.5 max.(without inverter)
Weight (with Inverter) [Grams] 620 max.
Physical Size [mm] 344.0 typ. x 222.0 typ. x 6.5 max.
Electrical Interface 2 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
document version 0.0 5/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
White Luminance [cd/m2] 5 points average 180 200 - 1, 4, 5.
ICCFL=6.0mA
Viewing Angle [degree] Horizontal (Right) 60 65 - 8
[degree] CR = 10 (Left)
60 65 -
[degree] Vertical (Upper) 40 45 -
[degree] CR = 10 (Lower)
50 55 -
Luminance Uniformity 5 Points 1.3 1
Luminance Uniformity 13 Points 1.52 2
CR: Contrast Ratio 300:1 400:1 - 6
Cross talk % 4 7
Response Time [msec] Rising - 6 8 8
[msec] Falling - 10 17
[msec] Rising + Falling 16 25
Color / Chromaticity Red x 0.556 0.576 0.596 2,8
Coordinates Red y
(CIE 1931) 0.310 0.330 0.350
Green x 0.292 0.312 0.332
Green y 0.530 0.550 0.570
Blue x 0.141 0.161 0.181
Blue y 0.128 0.148 0.168
White x 0.293 0.313 0.333
White y 0.309 0.329 0.349
document version 0.0 6/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Display area : 331.38mm x 207.11mm)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 and 13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
Note 4: Measurement method
document version 0.0 7/36
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight
for 30 minutes in a stable, windless and dark room.
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD Module
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
